MVI56-DNPSNET ♦ ControlLogix Platform
DNP 3.0 Server over Ethernet Communication Module
2.5

[DNP Slave Analog Inputs]

This area is to override the class (3) and deadband for the integer analog input
database. The point # is the offset from the start of the analog input database.

2.5.1 Point #

This is the information object address of the point.

2.5.2 Class

1 - Highest priority
C
LASS
2 - Middle priority
C
LASS
3 - Lowest priority
C
LASS
0 - Disable.

2.5.3 Deadband

The module will generate events only if the data value changes by an amount
greater than or equal to the configured deadband value.
