Configuring the MVI56-DNPSNET Module
User Manual
2.2

[Backplane Configuration]

This section of the file describes the database setup and module level
parameters.

2.2.1 Module Name

0 to 80 characters
This parameter assigns a name to the module that can be viewed using the
configuration/debug port. Use this parameter to identify the module and the
configuration file.

2.2.2 Read Register Start

0 to 8899
This parameter specifies the starting register in the module where data will be
transferred from the module to the processor. Valid range for this parameter is 0
to 8899.

2.2.3 Read Register Count

0 to 9000
This parameter specifies the number of registers to be transferred from the
module to the processor. Valid entry for this parameter is 0 to 9000.

2.2.4 Write Register Start

0 to 8899
This parameter specifies the starting register in the module where the data will be
transferred from the processor to the module. Valid range for this parameter is 0
to 8899.

2.2.5 Write Register Count

0 to 9000
This parameter specifies the number of registers to transfer from the processor to
the module. Valid entry for this parameter is 0 to 9000.

2.2.6 Failure Flag Count

0 through 65535
This parameter specifies the number of successive transfer errors that must
occur before halting communication on the application port(s). If the parameter is
set to 0, the application port(s) will continue to operate under all conditions. If the
value is set larger than 0 (1 to 65535), communications will cease if the specified
number of failures occur.
