Technical Specifications - Aeon Labs MultiSensor 6 User Manual

Security -
Command
Supported Report
Frame

2. Technical Specifications

Operating distance: Up to 500 feet/150 metres outdoors.
Operating temperature: 0
Relative humidity: 8%RH to 80%RH.
3. Familiarize Yourself with Your MultiSensor
3.1 Interface
4. All Functions of Each Trigger
4.1 Function of Z-Wave Button
Trigger
Click one time 1. Send non-security Node Info frame.
2. Add MultiSensor into z-wave network:
1. Power on MultiSensor. The MultiSensor's LED will blink slowly when you short press the Action Button.
2. Let the primary controller into inclusion mode (If you don't know how to do this, refer to its manual).
3. Press the Action Button.
4. If the inclusion is success, MultiSensor's LED will be kept turning on for 8 seconds when you short press the
Action Button. If the LED is still in slow blink, in which you need to repeat the process from step 2.
℃ to 40 . ℃
COMMAND_CLASS_ZWAVEPLUS_INFO,
COMMAND_CLASS_VERSION,
COMMAND_CLASS_MANUFACTURER_SPECIFIC,
COMMAND_CLASS_WAKE_UP,
COMMAND_CLASS_ASSOCIATION_GRP_INFO,
COMMAND_CLASS_ASSOCIATION,
COMMAND_CLASS_POWERLEVEL,
COMMAND_CLASS_NOTIFICATION_V3,
COMMAND_CLASS_BATTERY,
COMMAND_CLASS_SENSOR_BINARY,
COMMAND_CLASS_SENSOR_MULTILEVEL_V5,
COMMAND_CLASS_CONFIGURATION,
COMMAND_CLASS_SECURITY,
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
Description
