AEOEZW100
Routing Multisenor
Firmware Version : 1.4

Quick Start

A
This is a Z-Wave actuator.
Power on the MultiSensor. The MultiSensor's LED will blink slowly when you short press the Action Button. Set the primary controller into
inclusion mode (If you don't know how to do this, refer to its manual). Press the Action Button. If the inclusion is successful, the
MultiSensor's LED will be kept turning on for 8 seconds when you short press the Action Button. If the LED is still in slow blink, you need to
repeat the process from setting the controller into inclusion mode onward.
Please refer to the chapters below for detailed information about all aspects of the products usage.
What is Z-Wave?
This device is equipped with wireless communication complying to the Z-Wave standard. Z-Wave is the international standard for
wireless communication in smart homes and buildings. It is using the frequency of 868.42 MHz to realize a very stable and secure
communication. Each message is reconfirmed (two-way communication) and every mains powered node can act as a repeater for other
nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEOEZW100 and is the answer not in the manual?

Questions and answers

Related Manuals for Aeon Labs AEOEZW100

Summary of Contents for Aeon Labs AEOEZW100

  • Page 1: Quick Start

    AEOEZW100 Routing Multisenor Firmware Version : 1.4 Quick Start This is a Z-Wave actuator. Power on the MultiSensor. The MultiSensor’s LED will blink slowly when you short press the Action Button. Set the primary controller into inclusion mode (If you don’t know how to do this, refer to its manual). Press the Action Button. If the inclusion is successful, the MultiSensor’s LED will be kept turning on for 8 seconds when you short press the Action Button.

  • Page 2: Product Description

    Product description Aeon Labs MultiSensor is a routing binary sensor device based on Z-Wave routing slave library V6.51.06. The MultiSensor can be included and operated in any Z-wave network with other Z-wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.

  • Page 3: Behavior Within The Z-Wave Network

    The unit is operated by batteries. Use only batteries of correct type. Never mix old and new batteries in the same device. Used batteries contain hazardous substances and should not be disposed of with household waste! Battery Type: 2 * CR123A Installation Guidelines You can install the Multisensor wherever you want thanks to the enclosed accessories.

  • Page 4: Operating The Device

    Operating the device Once you installed the Multisensor and included it into your Z-Wave network the sensor will begin to send its data to the controller. The data will be shown in the interface of your controller but you can also use it to control your home. Simply define scenes that use the transmitted data from the Multisensor as input and control other devices based upon this data.

  • Page 5: Configuration Parameters

    Configuration Parameters Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features. IMPORTANT: Controllers may only allow to configure signed values. In order to set values in the range 128 … 255 the value sent in the application shall be the desired value minus 256.
  • Page 6 enable, the current PIR sensitivity level = 2. enable, the current PIR sensitivity level=3. enable, the current PIR sensitivity level=4. enable, the current PIR sensitivity level=5. (maximum level) command sent when the motion sensor triggered. (Parameter Number 5, Parameter Size 1)Which command would be sent when the motion sensor triggered.
  • Page 7 Value Description Threshold change in luminance to induce an automatic report. (Parameter Number 43, Parameter Size 2)Default Value = 100 LUX Value Description Threshold change in battery level to induce an automatic report. (Parameter Number 44, Parameter Size 2)The accuracy is 0.1. The high byte is the part of integer, the low byte is the fractional part.

  • Page 8: Command Classes

    0-7 = reserved 0-7 = reserved 0-7 = reserved 0 = Battery 1-3 = reserved 4 = ultraviolet 5 = temperature 6 = Humidity 7 = Luminance (Parameter Number 103, Parameter Size 4)Which report needs to be sent in Report group 3 Value Description 0-7 = reserved...

  • Page 9: Technical Data

     Binary Sensor (version 1)  Multilevel Sensor (version 5)  Association Group Information (version 1)  Configuration (version 1)  Alarm (version 3)  Powerlevel (version 1)  Firmware Update Meta Data (version 2)  Battery (version 1)  Association (version 2) ...

  • Page 10: Explanation Of Z-Wave Specific Terms

    Firmware Version Explanation of Z-Wave specific terms  Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways, Remote Controls or battery operated wall controllers.  Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
