WIRING DIAGRAMS:

FIG. 5 — 4-CYLINDER
FIG. 6 — 6-CYLINDER
FIG. 7 — 8-CYLINDER
FIGS. 8–11 — 12-CYLINDER
NOTE: With unit 791070-12,
follow FIG. 10 if the first
engine firing angle is 60
degrees or less (for example,
30°–90°). Use FIG. 11
first engine firing angle is
greater than 60 degrees
(for example, 90°–30°).
See section 9.20 for pro-
gramming the slave firing
angle with unit 791070-12.

4.0 IGNITION COILS

4.
USE ONLY THE ALTRONIC COILS INDICATED HERE:
•
UNSHIELDED:
•
FLANGE:
•
SHIELDED:
•
INTEGRAL:
4.2
Mount the ignition coils as close to the spark plugs as possible keep-
ing the high-tension lead length to a minimum but also keeping
temperatures below 200°F. (95°C.) during operation.

5.0 PRIMARY WIRING

5.
The CD200 system requires a battery or other DC power source
providing 12-28 Vdc for running and a minimum of 8 volts for en-
gine starting. Refer to
power source.
5.2
Primary wiring hookup is shown in the wiring diagrams –
THROUGH
WARNING:
Use the tables below to record the actual firing order and wiring.
791070-6, 791070-8*
ENGINE CYL. NO.
791080-6, 791080-8*
if the
ENGINE CYL. NO.
791070-12
ENGINE CYL. NO.
The common coil ground lead on -6 and -8 units is the J harness
lead. On -12 units, the common coil ground leads are J1 and H2.
ALTRONIC CD200 IGNITION SYSTEM
501061, 591010, 591040
591012, 591018
501061-S, 591010-S
591007, 591011A, 591011B
FIG. 3
for details of the connection to the DC
11.
THE HOOKUP SHOWN IS FOR THE MOST COMMON ENGINE
FIRING ORDER. CONNECT TO THE IGNITION COILS ACCORD-
ING TO THE ACTUAL ENGINE FIRING ORDER.
A B
A B
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2
C D E F
C D E F
www.altronicinc.com
FIGS. 5
H* K*
H* I*
