SD-LEAD:

When red, indicates that a shutdown has occurred which was the
result of a grounded G-lead condition.
0.28

SD-REMOTE:

When red, indicates that a shutdown has occurred as a result of a
remote serial shutdown command.
0.29

SD-OVERSPEED:

When red, indicates that a shutdown has occurred as a result of the
engine reaching the Overspeed setting.
0.30
WDOG1:
When red, indicates that the microprocessor has re-booted since
the ignition has been powered-up.
0.3
WDOG2:
When red, indicates that the microprocessor is currently re-boot-
ing. Disregard the first blink when first connecting.
0.32

CHKSUM:

When red, indicates a microprocessor checksum error.
0.33
LOW VOLT:
When red, indicates that the input DC voltage is at or below the Low
Voltage setting input.
0.34
NO CHARGE:
When red, indicates that the primary storage capacitor has failed to
charge properly within the last ~2 seconds.
0.35
PRIMARY OPEN:
When red, indicates that an open primary condition has been de-
tected within the last ~2 seconds.
0.36
PRIMARY SHORT:
When red, indicates that a shorted primary condition has been de-
tected within the last ~2 seconds.
0.37
SECONDARY OPEN:
When red, indicates that an open secondary condition has been de-
tected within the last ~2 seconds.
0.38
CRANKS LOG:
Indicates the total number of crank attempts seen by the CD200.
0.39
STARTS LOG:
Indicates the total number of successful starts seen by the CD200
as defined by the Run Speed setting input.
0.40
CYCLE LOG:
Total number of engine cycles seen by the CD200.
