PURGE COUNTER:

During a startup, indicates the number of purge cycles remaining
before the outputs are activated.
0.3

SUPPLY VOLTAGE:

Indicates the measured DC voltage supply level to the CD200.
0.4
SPARK REF. (A, B, C, ETC.):
Indicates the current spark reference number for each cylinder.
0.5

SYNCING:

When red, indicates that engine rotation has been sensed and the
synchronization process is taking place.
0.6
INSYNC1:
When red, indicates that the index input has been recognized once.
0.7
INSYNC2:
When red, indicates that the index has been recognized a second
time and the ignition is ready to proceed.
0.8

PURGING:

When red, indicates that synchronization has been completed and
the purge cycle countdown is taking place.
0.9
TRYING:
When red, indicates that the CD200 is trying to fire outputs, but a
proper primary discharge event has not yet occurred.
0.20
FIRING:
When red, indicates that CD200 is successfully firing primary outputs.
0.2
LOCKOUT:
When red, indicates that firings are locked out until engine rotation
has ceased for a minimum of 5 seconds.
0.22
CRANKING:
When red, indicates engine rotation below the Run Speed setting.
0.23
RUNNING:
When red, indicates engine rotation above the Run Speed setting.
0.24
DISC ERROR:
When red, indicates that the Test Disc status flag is activated and
the timing disc pattern being sensed did not match the DISC TYPE
selected.
0.25
G-LEAD:
When red, indicates that the G-lead is grounded.
0.26
REMOTE:
When red, indicates a remote serial shutdown command is active.
