Standard Installation

Minimum Clearance Requirements
A Side wall to stovetop
B Back wall to stovetop
D Connector to side wall
E Connector to back wall
G Floor protection, side and back
H Floor protection, front
I Floor protection, connector side
13 | Page
Catalyst Owner's Manual | © MF Fire 2017
20" (508 mm)
12" (305 mm)
30" (762 mm)
15" (381 mm)
8" (200 mm)
16" (407 mm)
2" (51 mm)
