ATALYST

WNER

ANUAL

Safety Notice: Please save these instructions for future reference.

Please read this entire manual before you install and use your

new room heater. Failure to follow instructions may result in

property damage, bodily injury, or even death. Contact local

building or fire officials about restrictions and installation

inspection requirements in your area. Do not install in a mobile

home!

Conforms to UL 1482-11 (R2015)

Report # 055WS001S

Revision #0013

Table of Contents

Need help?

Do you have a question about the CATALYST and is the answer not in the manual?

Questions and answers

Summary of Contents for MF FIRE CATALYST

Page 1 ATALYST ’ WNER ANUAL Safety Notice: Please save these instructions for future reference. Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. Contact local building or fire officials about restrictions and installation inspection requirements in your area.
Page 3: Introduction
If you ever have any questions, give us a call at 240.285.4225 or shoot us an email at info@mffire.com. We’re happy to help at any time. Thank you for your purchase of the Catalyst and welcome to the MF Fire Family!
Page 4: Table Of Contents
Controlling the Blower ..............23 Wood Selection ................23 Ordinary Operating Sounds ............24 Operating Without Electricity ............24 Catalyst Smart App ................25 Downloading the Catalyst Smart App ........... 25 Catalyst Owner’s Manual | © MF Fire 2017 3 | Page...
Page 5 Catalytic Combustor ..............31 Catalytic Combustor Troubleshooting and Replacement ..... 32 Lifetime Limited Warranty ..............33 A. If warranty service is needed ............ 33 B. Conditions and Exclusions ............33 Catalyst Owner’s Manual | © MF Fire 2017 Page | 4...
Page 6: Safety Precautions
Catalyst. while it is in use.   This wood heater has a Do not use chemicals or manufacturer-set minimum fluids to start the fire. Catalyst Owner’s Manual | © MF Fire 2017 5 | Page...
Page 7: Maintenance
 Inspect the chimney  Empty the ash regularly and connector at least twice dispose of it in a metal monthly. container with tight lid. Catalyst Owner’s Manual | © MF Fire 2017 Page | 6...
Page 8: Features And Specifications
Features and Specifications Features Catalyst is the world’s first smart wood stove – delivering an efficient, clean, and safe fire for you and your family. Catalyst’s unique smart technology continuously monitors and adjusts the fire to burn in the sweet spot, eliminating soot and smoke and giving you control at the touch of a button.
Page 9: Dimensions
This single burn rate wood heater is not approved for use with a flue damper. Certified average emissions rate of 1.9 g/hr, tested to EPA Method 28R and ASTM E2515-11. Catalyst Owner’s Manual | © MF Fire 2017 Page | 8...
Page 10: Getting To Know Your Catalyst
Ash pan: Don’t touch the ash pan handle while the stove is hot! But when the stove is cool, just unlatch, pull out the ash pan, and dispose of your ashes in a safe place. Catalyst Owner’s Manual | © MF Fire 2017 9 | Page...
Page 11: How It Works
Your Catalyst has a catalytic combustor (or catalyst, this part gets a little confusing) that scrubs the air just before the exhaust gases leave the stove. Catalyst’s catalyst (see) is a fine metal honeycomb, coated in platinum. Platinum lowers the activation energy...
Page 12: Stove Installation
Planning the Installation We suggest that you have a certified chimney sweep install your Catalyst. If you will be installing the stove yourself, we advise you consult a certified chimney sweep. Check with your local building officials and your home insurance company before installation.
Page 13: Stove Placement Requirements
Stove Placement Requirements Catalyst must be placed in a room with a source of fresh air. Stove must be placed so that no combustibles are within, or can swing within 36" (914mm) of the front of the stove (drapes, doors, etc.).
Page 14: Standard Installation
Connector to side wall 15” (381 mm) Connector to back wall 8” (200 mm) Floor protection, side and back 16” (407 mm) Floor protection, front 2” (51 mm) Floor protection, connector side Catalyst Owner’s Manual | © MF Fire 2017 13 | Page...
Page 15: Corner Installation
Minimum Clearance Requirements 8” (203 mm) Corner wall to stovetop 18” (458 mm) Connector to corner wall 8” (200 mm) Floor protection, side and back 18” (450 mm) Floor protection, front Catalyst Owner’s Manual | © MF Fire 2017 Page | 14...
Page 16: Chimney Requirements
Chimney Requirements Do not connect Catalyst to a chimney flue serving any other appliance or use in conjunction with any air distribution ductwork, unless specifically approved. This room heater must be connected to: 1. A 6” (150 mm) diameter, UL 103 HT chimney, from a single manufacturer 2.
Page 17: Chimney Connector Requirements
This prevents creosote from leaking to the exterior of the pipe. The chimney connector must be fastened to the stove and each adjoining section (and chimney) and kept clean. Catalyst Owner’s Manual | © MF Fire 2017 Page | 16...
Page 18: Chimney Termination Requirements
Must not be located where it will become plugged by snow or other material Must terminate at least 3' (914mm) above the roof and at least 2' (610mm) above any portion of the roof within 10' (3.048M) Catalyst Owner’s Manual | © MF Fire 2017 17 | Page...
Page 19: Special Installation: Exterior Factory-Built Chimney
Special Installation: Exterior Factory-Built Chimney Catalyst may be used in conjunction with an exterior factory built chimney provided that the chimney meets UL 103 HT requirements. Special care must be taken regarding the wall thimble, or penetration from the chimney connector pipe to the exterior chimney, if the wall thimble must pass through an exterior wall.
Page 20: Special Installation: Masonry Chimney
Catalyst may be used in conjunction with a masonry chimney provided all installation instructions are followed. We strongly recommend a full reline when installing the Catalyst in a masonry chimney. If the chimney does not have a clay tile liner, a full reline is required.
Page 21: Special Installation: Masonry Fireplace
Special Installation: Masonry Fireplace Catalyst may be used in conjunction with a masonry fireplace provided all installation instructions are followed. The entire fireplace must be clean, undamaged, and meet all local building codes. This installation requires a full reline. The liner must be stainless steel chimney connector or flexible vent pipe.
Page 22: Connecting The Electronics
Connecting the Electronics Your Catalyst comes with all electrical components pre-installed, so you don’t need to do anything except plug it in, and go. Special care should be taken when routing the primary power cord (the bottom-most cord), the blower fan cord (the second cord from the bottom), and the combustion fan cord (the top most cord).
Page 23: Using Catalyst: Stack To Stand
Using Catalyst: Stack to Stand Catalyst is a whole lot easier to use than any wood stove you have ever used. Gone are dampers and catalytic combustor bypasses. Gone is keeping the door open to start the stove, spilling smoke into the room.
Page 24: Controlling The Burn
Catalyst will automatically adjust to maintain the perfect room temperature. If you don’t do anything, Catalyst will automatically work to achieve a perfect F. If you’d like to set your ideal temperature, just use the Catalyst Smart App. Reloading Your Catalyst knows when you want to reload.
Page 25: Ordinary Operating Sounds
Catalyst’s smart control, turbo-start fan, and blower fan don’t work, but Catalyst can still provide a smooth and steady heat to your home. Just build a fire as you normally would and allow it to burn. Catalyst has no manual controls, so no adjustment is possible. If you are having...
Page 26: Catalyst Smart App
Let’s show you how it works Downloading the Catalyst Smart App To get your Catalyst Smart App simply visit the Google Play Store and search “MF Fire Catalyst”, and follow instructions to install. Having trouble? Shoot us an email and we’ll help.
Page 27: Connecting To Your Catalyst
“MF Fire”. If you do not see MF Fire as a device option, try unplugging and re-plugging in your Catalyst. If that fails, restart your smart device. If you’re still having problems, shoot us an email and we can help.
Page 28: Controlling Your Blower
Controlling Your Blower In addition to the buttons on the back of Catalyst, you can control the blower from your Catalyst Smart App. Slide the slider all the way to the left to turn the blower up, all the way to the right to turn it off, or somewhere in the middle for your own perfect airflow rate.
Page 29: Regular Maintenance
Glass The air wash on the Catalyst is designed to help keep the front glass clean. The glass may become dirtied in some spots when using unseasoned wood (please read Wood Selection section). To clean the glass, the unit should be allowed to cool.
Page 30: Monthly Maintenance
Soapstone The soapstone top on the Catalyst can be removed of light scratches by lightly sanding the surface using a fine abrasive sandpaper or Grade 1 (medium) steel wool. Any soapstone dust created by sanding should be removed with a vacuum.
Page 31: Annual Maintenance
Then carefully unscrew the interior doorframe, taking care to keep all screws. Replace the glass with official MF Fire replacement glass. The main pane is 0.1875” (5 mm) ceramic glass, 16.375” (416 mm) x 13.750” (349 mm). The side panes are 0.1875” (5 mm) ceramic glass, 16.375”...
Page 32: Catalytic Combustor
A properly functioning catalytic combustor maintains temperatures in excess of 500 °F. If catalyst temperatures are not in excess of 500 °F, refer to Catalyst Troubleshooting section of this owner’s manual. You can get an indication of whether the catalytic combustor is working...
Page 33: Catalytic Combustor Troubleshooting And Replacement
To replace the catalytic combustor, simply insert the new catalytic combustor inside the ring holder pictured. Replace and tightly secure the catalytic combustor panel and the back panel before operating the heater again. Catalyst Owner’s Manual | © MF Fire 2017 Page | 32...
Page 34: Lifetime Limited Warranty
MF Fire WITHIN 30 DAYS, indicating model name and serial number. 2. MF Fire has the option of either repairing or replacing the defective component. 3. Any appliance or part thereof that is repaired or replaced during...
Page 35 10. Damage to the surfaces from over-firing (operation where the steel may glow red) is not covered in this warranty. 11. MF Fire is free of liability for any damages caused by the appliance, as well as inconvenience expenses and materials. Incidental or consequential damages are not covered by this warranty.
