C T

OVA

AND

OVA

OWER

WNER

ANUAL

Safety Notice: Please save these instructions for future reference.

Please check our website for the most up to date version of this

manual. Please read this entire manual before you install and use

your new room heater. Failure to follow instructions may result in

property damage, bodily injury, or even death. Contact local

building or fire officials about restrictions and installation

inspection requirements in your area. Do not install Nova C in a

mobile home!

Manufactured by: MF Fire, Inc. 3031 Washington Blvd STE G, Baltimore, MD, USA. Report Number 0552WS003E, 0552WS003S

Table of Contents

Need help?

Do you have a question about the NOVA C and is the answer not in the manual?

Questions and answers

Summary of Contents for MF FIRE NOVA C

Page 1 Contact local building or fire officials about restrictions and installation inspection requirements in your area. Do not install Nova C in a mobile home! Manufactured by: MF Fire, Inc. 3031 Washington Blvd STE G, Baltimore, MD, USA. Report Number 0552WS003E, 0552WS003S...
Page 2: Table Of Contents
Installing the Bypass Handle ............23 Insulation and Fire Brick ..............24 Catalytic Combustor............... 27 Ash Retainer .................. 30 Stove Top Thermometer ..............31 Initial Curing ................... 31 Operation ................... 32 1 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 3 Annual Maintenance ................38 Exterior Paint ................. 38 Glass ....................38 Catalytic Combustor Replacement ..........39 Appendix A: Nova C Tower Assembly ..........40 Appendix B: Lifetime Limited Warranty ..........45 Nova C Owner’s Manual | © MF Fire 2023 Page | 2...
Page 4: Safety Precautions
C in conjunction with any air and CO detectors. distribution ductwork unless specifically approved for such - Do not connect this unit to a installations. chimney flue serving another appliance. 3 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 5: Operation
- The viewing door of Nova C instructions in this manual, or must be shut and latched during if the catalytic element is operation. deactivated or removed. Nova C Owner’s Manual | © MF Fire 2023 Page | 4...
Page 6: Maintenance
- Never attempt to modify or repair the appliance beyond instructions - Inspect the chimney given in this manual. connector at least twice monthly. - Inspect the catalytic combustor at least monthly. 5 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 7: Features And Specifications
6”, or 9” legs. Nova C Tower is available with no legs (standard, shown above) or 6” legs. Additionally, both Nova C and Nova C Tower can be used in either a rear vent or a top vent configuration, to best fit your home and preferences.
Page 8: Dimensions
Nova C has a 25,174 BTU per hour (7 kW) EPA certified heat release rate, with actual heat release rates ranging from 9,000 to 50,000 BTU per hour (2.5 to 15 kW) depending on user loading and reloading.
Page 9: Emissions And Efficiency
ULC S628-93 (R2016) Label Nova C comes with a metal certification label on a chain affixed to the bottom back of the stove. This label is in English and French. For safekeeping, the label may be affixed to the air duct of the stove during installation.
Page 10: Stove Installation
Proper care and attention to service helps to protect you from unnecessary fires and carbon monoxide poisonings. To get the best service and wood stove installation for your Nova C wood stove, we recommend Installers or Chimney Sweeps certified by the National Fireplace Institute (NFI) or the Chimney Safety Institute of America (CSIA).
Page 11: Stove Placement Requirements
Stove Placement Requirements Nova C must be placed in a room with a source of fresh air. The minimum room height that the stove can be installed in is 8 feet. Nova C must be placed so that no combustibles are within or can swing within 36"...
Page 12: Minimum Clearance And Floor Protection Requirements
Minimum Clearance and Floor Protection Requirements Nova C may be installed as a top vent with a ceiling exit in either a standard or corner configuration, or as a rear vent with a direct rear exit. The minimum clearance requirements are listed in the table below.
Page 14: Chimney Connector Requirements
This prevents creosote or condensation from leaking to the exterior of the pipe. The chimney connector must be fastened to the stove and each adjoining section and kept clean. 13 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 15: Chimney Requirements
Chimney Requirements The minimum chimney height, as measured from the stove top, is 15 feet. Do not connect Nova C to a chimney flue serving any other appliance or use in conjunction with any air distribution ductwork, unless specifically approved.
Page 16: Chimney Termination Requirements
The chimney must terminate at least 3' (914 mm) above the roof and at least 2' (610 mm) above any portion of the roof within 10' (3 m). 15 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 17: Exterior Factory-Built Chimney: Special Installation
Exterior Factory-Built Chimney: Special Installation Nova C may be used in conjunction with an exterior factory-built chimney provided that the chimney meets UL 103 HT requirements. Special care must be taken regarding the wall thimble, or penetration from the chimney connector pipe to the exterior chimney, if the wall thimble must pass through an exterior wall.
Page 18: Masonry Chimney: Special Installation
Nova C may be used in conjunction with a masonry chimney provided all installation instructions are followed. We strongly recommend a full reline when installing the Nova C in a masonry chimney. If the chimney does not have a clay tile liner, a full reline is required.
Page 19: Hearth Mount In Masonry Fireplace: Special Installation
Hearth Mount in Masonry Fireplace: Special Installation Nova C may be used in conjunction with a masonry fireplace provided all installation instructions are followed. The entire fireplace must be clean, undamaged, and meet all local building codes. This installation requires a full reline. The liner must be a stainless steel chimney connector or flexible vent pipe.
Page 20: Installing Legs And Ash Lip (Optional)
Installing Legs, Tower, and Ash Lip (Optional) Nova C will arrive bolted to a pallet with legs and leg bolts packed separately. The leg securement bolts are located inside the firebox and labeled “Leg Pad Bolts”. If ordered with the optional ash lip, the ash lip will contain two spacer plates for the rear legs, four longer bolts, and two filler pieces for the ash lip when used in the 6”...
Page 21 Rotate the leg so the solid sides are parallel to the outside edges of the stove. Use a wrench tighten the bolt. Repeat for all four legs. Nova C Owner’s Manual | © MF Fire 2023 Page | 20...
Page 22: Configuring The Optional Top Or Rear Vent
Configuring the Optional Rear Vent Nova C can be configured as either a top venting or a rear venting stove. Nova C will arrive in the top vent configuration. To switch to the rear vent configuration, the following procedure may be followed.
Page 23 If necessary, gasket cement can be placed between the plate and the top of the stove. Step 4: Replace the access plate and install the flue collar, as shown below. Nova C Owner’s Manual | © MF Fire 2023 Page | 22...
Page 24: Installing The Bypass Handle
Installing the Bypass Handle Nova C comes with the bypass handle detached for safety during transport. Step 1: Remove the set screw from the bypass handle. Step 2: To install the bypass handle simply slide the handle over the bypass rod on the back of the right side of the stove such that the handle is pointed towards the rear of the stove, with the bent portion of the handle angled away from the stove as shown below.
Page 25: Insulation And Fire Brick
Gloves and safety glasses should be worn during installation. Step 1: Unpack the fire bricks that accompany your Nova C, and ensure all pieces are present. The fire bricks received with your stove may not have the corresponding numbers in the steps below.
Page 26 To hold this row of bricks in place, the two T-bar retainers need to be inserted on top of the vertical row of fire bricks on both sides of the stove. 25 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 27 This includes slight gaps or a tight fit. In the event some bricks are tight, some adjustment or manual force may be needed to install these pieces. Slight gaps will be filled with ash from your first few fires. Nova C Owner’s Manual | © MF Fire 2023 Page | 26...
Page 28: Catalytic Combustor
Catalytic Combustor The Nova C catalytic combustor (Part # N11) is a long rectangular piece with a honeycomb-like structure. It can easily be installed as a final step prior to using your stove. Nova C may not be operated without the catalytic combustor properly installed.
Page 29 Next, lay the flame shield flat with the two tabs pointed towards the rear of the stove. Nova C Owner’s Manual | © MF Fire 2023 Page | 28...
Page 31: Ash Retainer
Ash Retainer Your Nova C comes standard with a removable ash retainer to extend the number of burns between emptying the ash. The 6” L- shaped ash retainer is placed directly on the brick on the firebox floor, and flush with the front inside of the stove, as shown below.
Page 32: Stove Top Thermometer
The stove top thermometer is an accessory that can be used to help determine when to close the catalytic combustor bypass on your Nova C. The thermometer should be placed on the stove top, 8” from the front of the stove and 11.25” from the side of the stove. For most uses, when the thermometer reads “ENGAGE CATALYST”, the...
Page 33: Operation
Operation Nova C is built to be simple and easy to use. It just works. We designed Nova C with no dampers to play with. Just build a fire, sit back and enjoy. Below are written operation instructions. We also highly recommend watching our series of videos on how to best operate your stove by scanning this QR code.
Page 34 Leave the door open just a crack, being sure to monitor the fire at all times when the door is open. Ignite the newspaper knots. This can be done quickly with a long match or stick lighter. 33 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 35: Controlling The Burn
Controlling the Burn Your Nova C has only one burn mode – perfect. If you would like more or less heat out of your Nova C, simply load more or less wood into your stove. Reloading The best time to reload your wood stove is when there are hot coals remaining and there is none or limited active flaming.
Page 36: Regular Maintenance And Troubleshooting
Regular Maintenance and Troubleshooting Wood stoves, even those as clean as Nova C, must be cleaned frequently because soot, ash, and creosote may accumulate. Establish a routine for the fuel, wood burner and firing technique. Check daily for creosote build-up until experience shows how often you need to clean to be safe.
Page 37: Door Gaskets
Door Gaskets Inspect all gaskets and door seals before each use. Nova C should be operated with the front door tightly shut. Catalytic Combustor This wood heater contains a catalytic combustor to help achieve a clean burn. It is important to periodically monitor the operation of the catalytic combustor to ensure it is properly functioning, and not clogged.
Page 38: Monthly Maintenance
The gasket in these areas should be visually inspected for any signs of deterioration or smoke leakage into the room. If the gasket is deteriorating, contact MF Fire for a replacement gasket. 37 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 39: Annual Maintenance
Remove large shards with gloves and dispose of appropriately. Then carefully unscrew the interior door frame, taking care to keep all screws. Replace the glass with official MF Fire replacement glass. Do not use unauthorized substitute materials. Contact your place of purchase if replacement glass is needed.
Page 40: Catalytic Combustor Replacement
Safety Notice: Burn untreated wood only. Burning materials such as treated wood, metal foil, coal, plastic, garbage, sulphur, or oil may damage the catalytic combustor. Excessive smoking indicates the combustor has failed and requires replacement. 39 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 41: Appendix A: Nova C Tower Assembly
Step 1: If installing the optional Nova C Tower 6” legs, carefully rotate the Nova C Tower Pedestal on to its side on a soft surface, such as a blanket or carpet as shown below.
Page 42 Step 3: Carefully rotate Nova C Tower Pedestal into the upright position and place in its final position. Follow all requirements in the Stove Placement Requirements section.
Page 43 Step 4: Carefully place Nova C on top of the Nova C Tower Pedestal ensuring the leg pad holes are aligned with the holes on top of the pedestal. The front of the Nova C should face the same direction as the wood storage opening of the pedestal.
Page 44 Then, using your other hand, slide the two clips into place as shown in the pictures below. The metal shield can then be set down on top of the clips. 43 | Page Nova C Owner’s Manual | © MF Fire 2023...
Page 45 The same handle can be used to push the tray back into place. When not in use, the ash tray handle may be stored inside the pedestal base. Nova C Owner’s Manual | © MF Fire 2023 Page | 44...
Page 46: Appendix B: Lifetime Limited Warranty
A and B. Mileage/labor charges, unless specified below, are not covered by warranty. Labor charges are subject to defined maximum limits by MF Fire. Additional service charges above the defined maximum limits may be charged by the service technician.
Page 47 WITHIN 30 DAYS, indicating model name and serial number. 2. MF Fire has the option of either repairing or replacing the defective component. 3. Any appliance or part thereof that is repaired or replaced during...
Page 48 15. MF Fire will not cover the cost of the removal or re-installation of hearths, facing, mantels, venting or other components. 16. This lifetime warranty is the only warranty supplied by MF Fire, the manufacturer of the appliance.
