MF FIRE CATALYST Owner's Manual

Hide thumbs Also See for CATALYST:
Table of Contents

Advertisement

Quick Links

Download this manual
C
ATALYST
'
O
M
WNER
S
ANUAL
Safety Notice: Please save these instructions for future reference.
Please read this entire manual before you install and use your
new room heater. Failure to follow instructions may result in
property damage, bodily injury, or even death. Contact local
building or fire officials about restrictions and installation
inspection requirements in your area. Do not install in a mobile
home!
Conforms to UL 1482-11 (R2015)
Report # 055WS001S
Revision #0021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CATALYST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MF FIRE CATALYST

Summary of Contents for MF FIRE CATALYST

  • Page 1 ATALYST ’ WNER ANUAL Safety Notice: Please save these instructions for future reference. Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. Contact local building or fire officials about restrictions and installation inspection requirements in your area.
  • Page 2 This page intentionally left blank. Catalyst Owner’s Manual | © MF Fire 2017 1 | Page...

  • Page 3: Introduction

    If you ever have any questions, give us a call at 1-855-MFFire1 or shoot us an email at info@mffire.com. We’re happy to help at any time. Thank you for your purchase of the Catalyst and welcome to the MF Fire Family!

  • Page 4: Table Of Contents

    Controlling the Burn ............... 25 Reloading ..................26 Controlling the Blower ..............26 Wood Selection ................26 Ordinary Operating Sounds ............27 Operating Without Electricity ............27 Catalyst Smart App ................28 Catalyst Owner’s Manual | © MF Fire 2017 3 | Page...
  • Page 5 Exterior Paint ................. 35 Glass ....................35 Catalytic Combustor Replacement ............ 36 Lifetime Limited Warranty ..............38 A. If warranty service is needed ............ 38 B. Conditions and Exclusions ............38 Catalyst Owner’s Manual | © MF Fire 2017 Page | 4...

  • Page 6: Safety Precautions

    Catalyst. while it is in use.   This wood heater has a Do not use chemicals or manufacturer-set minimum fluids to start the fire. Catalyst Owner’s Manual | © MF Fire 2017 5 | Page...

  • Page 7: Maintenance

     Inspect the chimney  Empty the ash regularly and connector at least twice dispose of it in a metal monthly. container with tight lid. Catalyst Owner’s Manual | © MF Fire 2017 Page | 6...

  • Page 8: Features And Specifications

    Heating Specifications Catalyst is equipped with a 2.0 cubic foot firebox and accepts logs more than 18” in length. 2,000 sq. ft. (175 m ) approximate maximum heating capacity. Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature.

  • Page 9: Dimensions

    This single burn rate wood heater is not approved for use with a flue damper. Certified average emissions rate of 1.9 g/hr, tested to EPA Method 28R and ASTM E2515-11. Catalyst Owner’s Manual | © MF Fire 2017 Page | 8...

  • Page 10: Stove Installation

    Proper care and attention to service helps to protect you from unnecessary fires and carbon monoxide poisonings. To get the best service and wood stove installation for your Catalyst wood burning stove, we recommend Installers or Chimney Sweeps certified by the Chimney Safety Institute of America (CSIA).

  • Page 11: Stove Placement Requirements

    Stove Placement Requirements Catalyst must be placed in a room with a source of fresh air. Stove must be placed so that no combustibles are within, or can swing within 36" (914mm) of the front of the stove (drapes, doors, etc.).

  • Page 12: Standard Installation

    Connector to side wall 15” (381 mm) Connector to back wall 8” (200 mm) Floor protection, side and back 16” (407 mm) Floor protection, front 2” (51 mm) Floor protection, connector side Catalyst Owner’s Manual | © MF Fire 2017 11 | Page...

  • Page 13: Corner Installation

    Minimum Clearance Requirements 8” (203 mm) Corner wall to stovetop 18” (458 mm) Connector to corner wall 8” (200 mm) Floor protection, side and back 16” (407 mm) Floor protection, front Catalyst Owner’s Manual | © MF Fire 2017 Page | 12...

  • Page 14: Chimney Requirements

    Chimney Requirements Do not connect Catalyst to a chimney flue serving any other appliance or use in conjunction with any air distribution ductwork, unless specifically approved. This room heater must be connected to: 1. A 6” (150 mm) diameter, UL 103 HT chimney, from a single manufacturer 2.

  • Page 15: Chimney Connector Requirements

    Each joint in the chimney connector must be hermetically sealed to prevent smoke leakage using furnace cement, high temperature silicone sealant or other suitable sealing medium. Smoke leakage from the chimney pipe is a sign of improper sealing. Catalyst Owner’s Manual | © MF Fire 2017 Page | 14...

  • Page 16: Chimney Termination Requirements

    Must not be located where it will become plugged by snow or other material Must terminate at least 3' (914mm) above the roof and at least 2' (610mm) above any portion of the roof within 10' (3.048M) Catalyst Owner’s Manual | © MF Fire 2017 15 | Page...

  • Page 17: Special Installation: Exterior Factory-Built Chimney

    Special Installation: Exterior Factory-Built Chimney Catalyst may be used in conjunction with an exterior factory built chimney provided that the chimney meets UL 103 HT requirements. Special care must be taken regarding the wall thimble, or penetration from the chimney connector pipe to the exterior chimney, if the wall thimble must pass through an exterior wall.

  • Page 18: Special Installation: Masonry Chimney

    Catalyst may be used in conjunction with a masonry chimney provided all installation instructions are followed. We strongly recommend a full reline when installing the Catalyst in a masonry chimney. If the chimney does not have a clay tile liner, a full reline is required.

  • Page 19: Special Installation: Masonry Fireplace

    Special Installation: Masonry Fireplace Catalyst may be used in conjunction with a masonry fireplace provided all installation instructions are followed. The entire fireplace must be clean, undamaged, and meet all local building codes. This installation requires a full reline. The liner must be stainless steel chimney connector or flexible vent pipe.

  • Page 20: Installing The Soapstone

    Installing the Soapstone Catalyst’s soapstone pieces are designed to maintain a smooth even heating while effectively directing your blower air into the room. To install the soapstone, simply rest the two smaller soapstone side panels on top of the stove and then rest the larger top panel on top of the side pieces, as shown below.

  • Page 21: Connecting The Combustion Fan

    Connecting the Combustion Fan The combustion fan (AD-MF) is responsible for moving the air throughout your stove and is mounted on the exhaust of your Catalyst in the section of single wall chimney connector pipe directly adjacent to the stove.
  • Page 22 Step 1: Gather the combustion fan parts Each Catalyst comes with a combustion fan, four “U” nuts, four screws, rope gasket, and a paper template cutting your chimney connector. Catalyst does not come with the screws necessary to secure your chimney connector pipe to your stove or to the remainder of your chimney connector.

  • Page 23: Connecting The Electronics

    Connecting the Electronics Your Catalyst comes with all electrical components, except the combustion fan, pre-installed, so you don’t need to do anything except plug it in, and go. Special care should be taken when routing the primary power cord (the right cord), and the combustion fan cord (the middle cord), and the blower fan cord (the left cord).

  • Page 24: Connecting The Smart Sensors

    Connecting the Smart Sensors Catalyst is equipped with three temperature sensing thermocouples. Each sensor is plugged into the smart controller and help’s Catalyst to smoothly regulate your burn. Thermocouples These thin wires monitor temperature at their tip. They are very low voltage, and not dangerous to touch, but are somewhat fragile and should be handled with care.

  • Page 25: How Catalyst Works

    How Catalyst Works Catalyst is a whole lot easier to use than any wood stove you have ever used. Gone are dampers and catalytic combustor bypasses. Gone is keeping the door open to start the stove, spilling smoke into the room. Instead, Catalyst is 100% automatic, so you just build a fire and walk away, and the Catalyst goes to work automatically tending your fire and minimizing emissions.

  • Page 26: Turbo-Start

    Catalyst is the only wood stove in the world with a Turbo-start system, making Catalyst the easiest wood stove ever to start. To start Catalyst, simply press the power on button on your Catalyst smart app or on your Catalyst controller (the bottom button) once or twice until the combustion fan turns on.

  • Page 27: Reloading

    To test the moisture content, split a piece of wood and use your wood moisture meter on the interior center of the wood. Store this wood in a dry place and remote from your Catalyst. Do not dispose of ashes where near where fuel is stored to prevent accidental fires.

  • Page 28: Ordinary Operating Sounds

    Catalyst’s smart control, turbo-start fan, and blower fan don’t work, but Catalyst can still provide a smooth and steady heat to your home. Just build a fire as you normally would and allow it to burn. Catalyst has no manual controls, so no adjustment is possible. If you are having...

  • Page 29: Catalyst Smart App

    Catalyst Smart App Catalyst is the first wood stove that can be controlled directly from your smart phone. That means you can achieve your perfect burn with just the push of a button. Let’s show you how it works Downloading the Catalyst Smart App To get your Catalyst Smart App simply visit the Google Play Store, Amazon App Store, or iTunes and search “MF Fire Catalyst”, and...

  • Page 30: Stove Control Screen

    Stove Control Screen You can control your Catalyst from the stove control screen. Set your room temperature or adjust the room blower. Settings: Adjust stove settings or learn more about the Catalyst Smart App Room Temperature: Set your desired room...

  • Page 31: Setting The Temperature

    Controlling Your Blower In addition to the buttons on the back of Catalyst, you can control the blower from your Catalyst Smart App. Slide the slider all the way to the left to turn the blower up, all the way to the right to turn it off, or somewhere in the middle for your own perfect airflow rate.

  • Page 32: Notifications

    Catalyst. Notifications Catalyst will notify you when you of a few events during your fire. “Five Minute Start-Up” – When you start your Catalyst the combustion goes into high mode to rapidly deliver air to your fire.

  • Page 33: Regular Maintenance And Troubleshooting

    Door Gaskets Inspect all gaskets and door seals before each use. Catalyst should be operated with both front door and ash pan door tightly shut. The tightness of the front door may be adjusted by adjusting the position of the latch box on the stove.

  • Page 34: Catalytic Combustor

    500 °F. Following cleaning, the catalytic combustor does not function, it may need to be replaced. For replacement instructions refer to Catalytic Combustor Troubleshooting and Replacement section of this owner’s manual. Catalyst Owner’s Manual | © MF Fire 2017 33 | Page...

  • Page 35: Monthly Maintenance

    Soapstone (Optional) The optional soapstone top on the Catalyst can be removed of light scratches by lightly sanding the surface using a fine abrasive sandpaper or Grade 1 (medium) steel wool. Any soapstone dust created by sanding should be removed with a vacuum.

  • Page 36: Annual Maintenance

    Then carefully unscrew the interior doorframe, taking care to keep all screws. Replace the glass with official MF Fire replacement glass. The main pane is 0.1875” (5 mm) ceramic glass, 13.31” (416 mm) x 13.5” (349 mm). The left pane is 0.1875” (5 mm) ceramic glass, 13.31” (416 mm) x 4.25”...

  • Page 37: Catalytic Combustor Replacement

    (orange) may then be lifted up and removed from its ring holder. If any cracking or peeling is observed, the catalytic combustor must be immediately replaced. Please contact MF Fire for a replacement catalytic combustor. To replace the catalytic combustor, simply insert the new catalytic combustor inside the ring holder pictured.
  • Page 38 This page intentionally left blank. Catalyst Owner’s Manual | © MF Fire 2017 37 | Page...

  • Page 39: Lifetime Limited Warranty

    MF Fire WITHIN 30 DAYS, indicating model name and serial number. 2. MF Fire has the option of either repairing or replacing the defective component. 3. Any appliance or part thereof that is repaired or replaced during...
  • Page 40 10. Damage to the surfaces from over-firing (operation where the steel may glow red) is not covered in this warranty. 11. MF Fire is free of liability for any damages caused by the appliance, as well as inconvenience expenses and materials. Incidental or consequential damages are not covered by this warranty.
