Summary of Contents for Ozito PRL-072
-
Page 2: Specifications
SPECIFICATIONS – MODEL NO. PRL-072 Motor: 7.2V Input: 220-240V ~ 50Hz Cutting capacity: 14mm Charge time: 5 hours Run time: 500 x 14mm branches (approx.) Weight: 0.80kg KNOW YOUR PRODUCT 1. Fixed blade 2. Cutting blade 3. Soft grip handle 4. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ……………………………………….. Page 1 INTRODUCTION………………………………………… Page 3 ELECTRICAL SAFETY…………………………………… Page 3 GENERAL POWER TOOL SAFETY WARNINGS…….. Page 4 BATTERY SAFETY WARNINGS………………………… Page 6 LITHIUM ION PRUNER SAFETY WARNINGS………… Page 7 BATTERY CHARGING…………………………………… Page 8 OPERATION……………………………………………… Page 9 PRUNING TIPS……………………………………………... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. -
Page 5: General Power Tool Safety Warnings
SAFETY INSTRUCTIONS Warning! A battery operated tool with individual batteries or a separate battery pack must be recharged only with the specific charging unit for the battery. A charging unit that may be suitable for one type of battery may create a risk of fire when used with another battery type. - Page 6 General Power Tool Safety Warnings - Personal Safety 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
-
Page 7: Battery Safety Warnings
General Power Tool Safety Warnings - Personal Safety g) Use the power tool, accessories and tool bits etc. in accordance with these instructions and in the manner intended for the particular type of power tool, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. -
Page 8: Lithium Ion Pruner Safety Warnings
Battery Safety Warnings (cont.) • DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as outside sheds or metal buildings in summer). • The charger is designed to operate on standard household electrical power (240 volts). -
Page 9: Battery Charging
BATTERY CHARGING Battery The length of service between each charge will depend on the type of work you are doing. The battery in this tool has been designed to provide maximum trouble free life. However, like all batteries, it will eventually wear out. To obtain the longest possible battery life, we suggest the following: •... -
Page 10: Operation
OPERATION 1. To perform the cutting action pull back the safety lock- Fig. 2 off switch (8) (Fig.2) whilst holding the lock-off switch depress the on/off trigger switch (9). Release the trigger switch (9) to retract the cutting blade (2). 2. -
Page 11: Pruning Tips
PRUNING TIPS Pruning can be done all year round. It is advisable to prune lightly when the shrub/plant is in full bloom or in its peak. Prune more heavily when the plant is less active and dormant. Types of pruning Tip pruning •... -
Page 12: Maintenance
Warning! Ensure that the lock-off switch and trigger are not accidentally depressed during cleaning/maintenance. Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the pruner by an unauthorised person or by mishandling of the pruner. -
Page 13: Description Of Symbols
DESCRIPTION OF SYMBOLS Volts Hertz Alternating current Watts ø Direct current Diameter Milliamperes No load speed Revolutions or Electrical Emissions reciprocation per minute Conformity (EMC) Read instruction manual Warning Indoor use only Double insulated Polarity Isolation transformer Thermal cut-out Transformer Energy protection at 130ºC Rating (MEPS) Lithium Ion-cadmium battery... -
Page 14: Contents
1 x 7.2V Cordless Lithium Ion Pruner 1 x Blade Cover 1 x AC Charging Adaptor 1 x Instruction Manual OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175 Telephone: 1800 069 486 Facsimile: +61 3 9238 5588 Website: www.ozito.com.au... -
Page 15: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 2 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 24 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
