- Page 1 ZETA TOUCHSCREEN REPEATER INTERFACE (ZT-TSRI) Installation Manual Doc No: GLT-281-7-1 Issue: 1.0 Author: TE DATE: 16/11/2016...
-
Page 2: Table Of Contents
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 Index 1 – Introduction – System Planning and Design………………….......………………………3 – Personnel.……………………………………….......…………………………...3 – Setup……………………………………………………………........………………………….3 Connecting the Power..................3 Connections to the Quatro Panel..............3 Connection to a Screen/Monitor...............4 Connections to a Web Server................5 Connections Checks & Start-up.................5 –... -
Page 3: Introduction
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 1. Introduction 1.1 System Planning and Design It is understood that the system, of which this device is part, has been designed by an expert in fire alarm systems, and is in accordance with the requirements of British Standard BS 5839- 1:2013 and other applicable standards. -
Page 4: Connection To A Screen/Monitor
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 ICP-DAS Wiring (USB TO SERIAL ADAPTER) (QT-NC Modbus (Cannot be RS485) powered from the Quatro 24v AUX supply) Full manual here: ftp://ftp.icpdas.com/pub/cd/8000cd/napdos/7000/manual/7520.pdf If No ICP-DAS is used: The connection to be made between the QT-NC Modbus and ZT-TSRI (repeater) are as follows: The USB A to serial converter can then be inserted into any of the 4 USB slots on the ZT-TSRI. -
Page 5: Connections To A Web Server
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 2.4 Connections to Web Server There are two options to access your Web Server: Connect the ZT-TSRI directly to a PC via RJ-45 connectors through an Ethernet cable. Connect the Repeater to a LAN (via Ethernet connection) and access from any PC connected to it. -
Page 6: User Interface
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 3.2 User Interface The digital repeater has two user interfaces: the display itself connected to the equipment which, if it is not a touch, can be operated through a keyboard and a mouse connected to the USB inputs of the repeater, and an integrated Web Server. -
Page 7: Repeater Network Configuration
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 Connect the repeater to a LAN (via the Ethernet connection) and access from any PC connected to it. If there is a DHCP server on the network, the repeater will auto configure its network options (as long as this option is turned on in the Configuration). -
Page 8: Master-Slave Configuration
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 4.3.2 Master-Slave Configuration In an installation, we will configure only one of the repeaters as a Master, which will be the one that will communicate with the panel. All other devices will be Slaves and will be managed by the Master. -
Page 9: Miscellaneous
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 4.4.4 Miscellaneous During an alarm and/or fault, the repeater has the ability to send an email to one or more recipients. The parameters we must configure are: Enable SMTP Server authentication: Some mail servers may need authentication (for example, Gmail). -
Page 10: Registering An Area
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 4.6.1 Registering an Area An area is an area of a map in a building or facility (the same as a zone). It can be formed by drawing one or more polygons on a map. The area can belong to a panel zone, or can be used as a Parent Area to related maps. -
Page 11: To Remove A Map/Image
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 To exit the Zones menu, press the button to return to the repeater main screen. 4.6.4 To Remove a Map/Image Choose a map from the map list. Click on the delete button on the right. 4.7 Uploading of Zone Maps, Drawings and Images This process must be done from webserver “Map files”... -
Page 12: Devices
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 To restore a backup of data on a computer, click on "Choose file", select the file of Backup data to restore. Finally click on "Upload Config/Data". To perform a Configuration Backup / Restore: This includes the settings of the repeater itself (except network settings). -
Page 13: Add/Delete/Modify A Device
PREMIER QUATRO ZT-TSRI Installation Manual Firmware Version: 2_0z3 4.9.2 Add/Delete/Modify a Device Add - If we press on "Add", the repeater will add one device and will locate it in the part Bottom of the list of devices. After modifying the parameters of the new device, click on "Modify"...
