C&T Solution VIO-100 PC300 Series User Manual

Industrial panel pcs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VIO-100/PC300 Series
VIO-200/PC300 Series
Industrial Panel PCs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIO-100 PC300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for C&T Solution VIO-100 PC300 Series

Summary of Contents for C&T Solution VIO-100 PC300 Series

  • Page 1 VIO-100/PC300 Series VIO-200/PC300 Series Industrial Panel PCs...

  • Page 2: Table Of Contents

    l User’s Manual VIO-100(200)/PC300 Table of Contents Prefaces …………………………………………………….……………………………………………. 05 Revision …………………………………………………………………………………………..……………….……….. 05 Disclaimer ………………………………………………………..…….…….………………………….……………….. 05 Copyright Notice …………………………………….…………………….…………………………………………… 05 Trademarks Acknowledgment …………..………………………………………………………....05 Environmental Protection Announcement …………………………….………………….……………….. 05 Safety Precautions ………………………………………….……………………………….…………….………….. 06 Technical Support and Assistance …………………………………….…………….…………….…………….07 Conventions Used in this Manual ………………………………………………………………….….………..07 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 l User’s Manual VIO-100(200)/PC300 1.4.11 VIO-W115R(C)/PC300 …………………..….…....……………………….…41 1.4.12 VIO-W115R(C)/PC311E(P) ………………….…....……………………….… 41 1.4.13 VIO-W215R(C)/PC300 ………………….…....……………………….…42 1.4.14 VIO-W215R(C)/PC311E(P) ……………….…....……………………….… 42 1.4.15 VIO-117R(C)/PC300 ………………….….......……………………….… 43 1.4.16 VIO-117R(C)/PC311E(P) ………………….…....……………………….… 43 1.4.17 VIO-217R(C)/PC300 ………………….….......……………………….… 44 1.4.18 VIO-217R(C)/PC311E(P) ………………….…....……………………….… 44 1.4.19 VIO-119R(C)/PC300 ………………….….......……………………….… 45 1.4.20 VIO-119R(C)/PC311E(P) ………………….…....……………………….… 45 1.4.21 VIO-219R(C)/PC300 ………………….….......……………………….…...
  • Page 4 l User’s Manual VIO-100(200)/PC300 Chapter 5 BIOS Setup ……………………..…………………………………………………….85 BIOS Introduction ………………………………………..…….…………………………………..86 Main Setup ………………………………………..…….…………….……………………………..87 5.2.1 System Language …….……………………………………..……..……………………..87 5.2.2 System Date …….……………………………………………..……..……………………..87 5.2.3 System Time ………..…………………………………………..……….…………………... 87 Advanced Setup ………………………………………………………..…………………………….. 88 5.3.1 CPU Configuration……..…………………………………………………..………………. 88 5.3.2 Trusted Computing (Option) ……………..…….………..…..……………..……... 89 5.3.3 ACPI Settings ……………….………..…………………………….………………..……...

  • Page 5: Prefaces

    Preface l User’s Manual VIO-100(200)/PC300 Prefaces Revision Revision Description Date Manual Released 2016/10/06 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of C&T Solution Inc.

  • Page 6: Safety Precautions

    l User’s Manual Preface VIO-100(200)/PC300 Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...

  • Page 7: Technical Support And Assistance

    l User’s Manual Preface VIO-100(200)/PC300 Technical Support and Assistance 1. Visit the C&T Solution Inc website at www.candtsolution.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 8: Package Contents

    l User’s Manual Preface VIO-100(200)/PC300 Package Contents Before installation, please ensure all the items listed in the following table are included in the package. VIO-110/PC300 | VIO-110/PC311E(P) VIO-112/PC300 | VIO-112/PC311E(P) Item Description Q’ty Item Description Q’ty VIO-110/PC300 Series Panel PC VIO-112/PC300 Series Panel PC Panel Mount Kit Panel Mount Kit...

  • Page 9: Ordering Information

    l User’s Manual Preface VIO-100(200)/PC300 VIO-215/PC300 | VIO-215/PC311E(P) VIO-W215/PC300 | VIO-W215/PC311E(P) Item Description Q’ty Item Description Q’ty VIO-215/PC300 Series Panel PC VIO-W215/PC300 Series Panel PC Panel Mount Kit Panel Mount Kit Utility DVD Driver Utility DVD Driver Screw Pack Screw Pack VIO-217/PC300 | VIO-217/PC311E(P) VIO-219/PC300 | VIO-219/PC311E(P) Item...
  • Page 10 l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description VIO-110R/PC311E-5350U 10.4" SVGA Resistive Touch Panel PC with Intel® i5-5350U Processor, 1x PCIe x4 Expansion VIO-110C/PC311E-5350U 10.4" SVGA Capacitive Touch Panel PC with Intel® i5-5350U Processor, 1x PCIe x4 Expansion VIO-110R/PC311E-5010U 10.4"...
  • Page 11 l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description VIO-115R/PC300-3765U 15" XGA Resistive Touch Panel PC with Intel® Celeron® 3765U Processor VIO-115C/PC300-3765U 15" XGA Capacitive Touch Panel PC with Intel® Celeron® 3765U Processor VIO-115R/PC311E-5350U 15" XGA Resistive Touch Panel PC with Intel® i5-5350U Processor, 1x PCIe x4 Expansion VIO-115C/PC311E-5350U 15"...
  • Page 12 l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description VIO-117R/PC300-5010U 17" SXGA Resistive Touch Panel PC with Intel® i3-5010U Processor VIO-117C/PC300-5010U 17" SXGA Capacitive Touch Panel PC with Intel® i3-5010U Processor VIO-117R/PC300-3765U 17" SXGA Resistive Touch Panel PC with Intel® Celeron® 3765U Processor VIO-117C/PC300-3765U 17"...

  • Page 13: Product Description

    Preface l User’s Manual VIO-100(200)/PC300 Model No. Product Description VIO-W121R/PC300-5350U 21.5" 16:9 FHD Resistive Touch Panel PC with Intel® i5-5350U Processor VIO-W121C/PC300-5350U 21.5" 16:9 FHD Capacitive Touch Panel PC with Intel® i5-5350U Processor VIO-W121R/PC300-5010U 21.5" 16:9 FHD Resistive Touch Panel PC with Intel® i3-5010U Processor VIO-W121C/PC300-5010U 21.5"...
  • Page 14 l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description 12.1" XGA Resistive Touch Thin Frame Panel PC with Intel® i5-5350U Processor, VIO-212R/PC311P-5350U 1x PCI Expansion 12.1" XGA Capacitive Touch Thin Frame Panel PC with Intel® i5-5350U Processor, VIO-212C/PC311P-5350U 1x PCI Expansion 12.1"...
  • Page 15 Preface l User’s Manual VIO-100(200)/PC300 Model No. Product Description VIO-W215R/PC300-5010U 15.6" 16:9 FHD Resistive Touch Thin Frame Panel PC with Intel® i3-5010U Processor VIO-W215C/PC300-5010U 15.6" 16:9 FHD Capacitive Touch Thin Frame Panel PC with Intel® i3-5010U Processor VIO-W215R/PC300-3765U 15.6" 16:9 FHD Resistive Touch Thin Frame Panel PC with Intel® Celeron® 3765U Processor VIO-W215C/PC300-3765U 15.6"...
  • Page 16 l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description 17" SXGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® 3765U Processor, VIO-217R/PC311E-3765U 1x PCIe x4 Expansion 17" SXGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® 3765U Processor, VIO-217C/PC311E-3765U 1x PCIe x4 Expansion 17"...

  • Page 17: Optional Accessories

    l User’s Manual Preface VIO-100(200)/PC300 Model No. Product Description VIO-W221R/PC300-5350U 21.5" 16:9 FHD Resistive Touch Thin Frame Panel PC with Intel® i5-5350U Processor VIO-W221C/PC300-5350U 21.5" 16:9 FHD Capacitive Touch Thin Frame Panel PC with Intel® i5-5350U Processor VIO-W221R/PC300-5010U 21.5" 16:9 FHD Resistive Touch Thin Frame Panel PC with Intel® i3-5010U Processor VIO-W221C/PC300-5010U 21.5"...

  • Page 18: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 19: Overview

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.1 Overview The VIO-100/PC300 and VIO-200/PC300 series Panel PC is based on 5 Gen. Intel® Core™ i5-5350U (2.9GHz) / i3-5010U (2.1GHz) or Celeron® 3765U (1.9GHz) Dual Core processor. Designed with flat surface, IP 65 dust/waterproof front panel, and aluminum die-casting front frame with rugged body structure, it is a versatile I/O connections, and rugged reliability industrial panel PC.

  • Page 20: Hardware Specification

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2 Hardware Specification 1.2.1 VIO-110R(C)/PC300 | VIO-110R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 10.4” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 800 x 600 (SVGA) •...

  • Page 21: Vio-112R(C)/Pc300 | Vio-112R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.2 VIO-112R(C)/PC300 | VIO-112R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 12.1” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) •...

  • Page 22: Vio-212R(C)/Pc300 | Vio-212R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.3 VIO-212R(C)/PC300 | VIO-212R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 12.1” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) •...

  • Page 23: Vio-115R(C)/Pc300 | Vio-115R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.4 VIO-115R(C)/PC300 | VIO-115R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 15” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) •...

  • Page 24: Vio-215R(C)/Pc300 | Vio-215R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.5 VIO-215R(C)/PC300 | VIO-215R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 15” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) •...

  • Page 25: Vio-W115R(C)/Pc300 | Vio-W115R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.6 VIO-W115R(C)/PC300 | VIO-W115R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 15.6” (16:9) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1920 x 1080 (Full HD) •...

  • Page 26: Vio-W215R(C)/Pc300 | Vio-W215R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.7 VIO-W215R(C)/PC300 | VIO-W215R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 15.6” (16:9) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1920 x 1080 (Full HD) •...

  • Page 27: Vio-117R(C)/Pc300 | Vio-117R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.8 VIO-117R(C)/PC300 | VIO-117R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 17” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1280 x 1024 (SXGA) •...

  • Page 28: Vio-217R(C)/Pc300 | Vio-217R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.9 VIO-217R(C)/PC300 | VIO-217R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 17” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1280 x 1024 (SXGA) •...

  • Page 29: Vio-119R(C)/Pc300 | Vio-119R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.10 VIO-119R(C)/PC300 | VIO-119R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 19” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1280 x 1024 (SXGA) •...

  • Page 30: Vio-219R(C)/Pc300 | Vio-219R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.11 VIO-219R(C)/PC300 | VIO-219R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 19” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1280 x 1024 (SXGA) •...

  • Page 31: Vio-W121R(C)/Pc300 | Vio-W121R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.12 VIO-W121R(C)/PC300 | VIO-W121R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 21.5” (16:9) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1920 x 1080 (Full HD) •...

  • Page 32: Vio-W221R(C)/Pc300 | Vio-W221R(C)/Pc311E(P)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.2.13 VIO-W221R(C)/PC300 | VIO-W221R(C)/PC311E(P) Hardware Specification Display • VGA: 1x VGA (or 1x DVI-D by Order) • LCD Size: 21.5” (16:9) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1920 x 1080 (Full HD) •...

  • Page 33: System I/O

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.3 System I/O 1.3.1 Front Antenna hole Removable HDD Bay Used to connect an antenna for optional Mini- Used to insert a 2.5” HDD or SSD PCIe WiFi module 1.3.2 Rear DC IN LAN port Used to plug a DC power input with terminal Used to connect the system to a local area...

  • Page 34: Side (Left)

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.3.3 Side (Left) Mic-in PC/CAR mode select switch Used to connect a microphone Used to select PC or CAR power mode COM port 12V/24V mode select switch COM2 support RS232/422/485 serial device Used to select Car power input voltage Digital I/O Terminal Block DELAY TIME switch...

  • Page 35: Top

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.3.5 T0P VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm)

  • Page 36: Mechanical Dimension

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4 Mechanical Dimensions 1.4.1 VIO-110R(C)/PC300 Unit: mm 1.4.2 VIO-110R(C)/PC311E(P) Unit: mm...

  • Page 37: Vio-112R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.3 VIO-112R(C)/PC300 Unit: mm 1.4.4 VIO-112R(C)/PC311E(P) Unit: mm...

  • Page 38: Vio-212R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.5 VIO-212R(C)/PC300 Unit: mm 1.4.6 VIO-212R(C)/PC311E(P) Unit: mm...

  • Page 39: Vio-115R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.7 VIO-115R(C)/PC300 Unit: mm 1.4.8 VIO-115R(C)/PC311E(P) Unit: mm...

  • Page 40: Vio-215R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.9 VIO-215R(C)/PC300 Unit: mm 1.4.10 VIO-215R(C)/PC311E(P) Unit: mm...

  • Page 41: Vio-W115R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.11 VIO-W115R(C)/PC300 Unit: mm 1.4.12 VIO-W115R(C)/PC311E(P) Unit: mm...

  • Page 42: Vio-W215R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.13 VIO-W215R(C)/PC300 Unit: mm 1.4.14 VIO-W215R(C)/PC311E(P) Unit: mm...

  • Page 43: Vio-117R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.15 VIO-117R(C)/PC300 Unit: mm 1.4.16 VIO-117R(C)/PC311E(P) Unit: mm...

  • Page 44: Vio-217R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.17 VIO-217R(C)/PC300 Unit: mm 1.4.18 VIO-217R(C)/PC311E(P) Unit: mm...

  • Page 45: Vio-119R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.19 VIO-119R(C)/PC300 Unit: mm 1.4.20 VIO-119R(C)/PC311E(P) Unit: mm...

  • Page 46: Vio-219R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.21 VIO-219R(C)/PC300 Unit: mm 1.4.22 VIO-219R(C)/PC311E(P) Unit: mm...

  • Page 47: Vio-W121R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.23 VIO-W121R(C)/PC300 Unit: mm 1.4.24 VIO-W121R(C)/PC311E(P) Unit: mm...

  • Page 48: Vio-W221R(C)/Pc300

    l User’s Manual Chapter 1: Product Introductions VIO-100(200)/PC300 1.4.25 VIO-W221R(C)/PC300 Unit: mm 1.4.26 VIO-W221R(C)/PC311E(P) Unit: mm...

  • Page 49: Chapter 2 Jumpers And Connectors

    Chapter 2 Switches and Connectors...

  • Page 50: Switch And Connector Locations

    l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 2.1 Switch and Connector Locations 2.1.1 Top View 2.1.2 Bottom View...

  • Page 51: Connector / Switch Definition

    l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch CAR_PWR1 PC / CAR Power Mode Switch 12-24V_SEL1 Car Power input voltage Switch DELAY_TIME1...

  • Page 52: Switch Definitions

    l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode（Default） CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS CAR_PWR1: PC / CAR Power Mode Switch Switch...
  • Page 53 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 Step of Setting Power Ignition Step 1: To select power ignition by PC/CAR switch. Step 2: To select battery input voltage by 12V / 24V switch. Step 3: To configure the power off delay time, please check the Delay Time Setting Options in advance. Step 4: To connect the power and ignition power Step 1...

  • Page 54: Connector Definitions

    l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 2.4 Connectors Definitions PWR_SW1 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button RESET1 : Reset Button Definition RESET USB1_2_1: USB3.0 Connector, Type A Definition Definition USB2_D0- USB2_D1-...
  • Page 55 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 SIM1, SIM2：SIM Card Socket Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK COM1_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD1...
  • Page 56 l User’s Manual Chapter 2: Switches and Connectors Chapter 2: Switches and Connectors VIO-100(200)/PC300 COM3_1: : RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD3 TX3- DATA3- RXD3 TX3+...
  • Page 57 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 LAN1, LAN2: RJ45 with LEDs Port Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Definition Definition LAN2_MDI0P LAN2_MDI2N LAN2_MDI0N LAN2_MDI1N LAN2_MDI1P LAN2_MDI3P LAN2_MDI2P LAN2_MDI3N Link LED Status Definition Act LED Status Definition Steady Orange 1Gbps Network Link...
  • Page 58 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 VGA1: VGA Input Connector Definition Definition GREEN BLUE DDC_SDA HSYNC RED_GND VSYNC GREEN_GND DDC_SCL BLUE_GND DP1: DisplayPort Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P DP_PWR...
  • Page 59 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 SPK_OUT1 : Speaker-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition...
  • Page 60 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 PWR_SW2 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 61 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 CN1: Mini PCI-Express / mSATA Socket Definition Definition Definition WAKE# +3.3V +3.3V USB_D4+ +3.3V MINIPCIE RST# MINIPCIE_RXN6_0 +3.3V (SATA_RXN3) +1.5V +3.3V MINIPCIE_RXP6_0 CLKREQ4# (SATA_RXP3) USIM2_PWR USIM2_DATA +1.5V MINIPCIE_CLKN1 USIM2_CLK SMB_CLK +1.5V MINIPCIE_TXN6_0 MINIPCIE_CLKP1 (SATA_TXN3)
  • Page 62 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 SATA1, SATA2: SATA with Power Connector SATA1 SATA1 SATA2 SATA2 Definition Definition Definition Definition SATA_TXP0 SATA_TXP1 SATA_TXN0 SATA_TXN1 SATA_RXN0 SATA_RXN1 SATA_RXP0 SATA_RXP1 +3.3V +3.3V +3.3V +12V +3.3V +12V +3.3V +12V +3.3V +12V +12V +12V...
  • Page 63 l User’s Manual Chapter 2: Switches and Connectors VIO-100(200)/PC300 PWR_LED1: Power LED Status Definition POWER LED+ POWER LED- HDD_LED1: HDD Access LED Status Definition HDD LED+ HDD LED- TEMP_LED1: Temperature LED Status Definition TEMP LED+ TEMP LED- WDT_LED1: Watchdog LED Status Definition WATCHDOG LED+ WATCHDOG LED-...

  • Page 64: Chapter 3 Front Panel Controls

    Chapter 3 Front Panel Controls...

  • Page 65: Users Controls

    l User’s Manual Chapter 3: Front Panel Controls VIO-100(200)/PC300 3.1 Users Controls POWER MENU INCREASE DECREASE AUTO 3.1.1 Power Button Turns the monitor on or off. 3.1.2 1. Blue indicates power on. 2. Yellow indicates HDD access status. 3.1.3 MENU / Enter Button Press to view the OSD menu.

  • Page 66: Osd Operation

    l User’s Manual Chapter 3: Front Panel Controls VIO-100(200)/PC300 3.2 OSD Operation 3.2.1 Luminance ■ Brightness Adjust the luminance level of the screen. ■ Contrast Adjusts the contrast level of the screen. ■ Gamma This item allows you to on or off the Gamma function. ■...

  • Page 67: Picture

    l User’s Manual Chapter 3: Front Panel Controls VIO-100(200)/PC300 3.2.2 Picture ■ Phase Adjust the monitor internal signal phase. ■ Clock Adjust the monitor internal sampling clock rate. ■ H. Position Adjusts the position of the screen image left and right. ■...

  • Page 68: Setup

    l User’s Manual Chapter 3: Front Panel Controls VIO-100(200)/PC300 3.2.5 Setup ■ Language Selects the language in which the OSD menu is displayed. The factory default is English. ■ Mute Allows the user to turn the Mute On or Off. ■...

  • Page 69: Chapter 4 System Setup

    Chapter 4 System Setup...

  • Page 70: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 4.2 Removing PC module from the display module. In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 71: Removing Chassis Top Cover

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.3 Removing chassis top cover 1. Unscrew the 6 screws (M3x5L) below. 2. Now you can remove the top cover of PC module.

  • Page 72: Installing Sodimm

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.4 Installing SODIMM 1. Insert memory module from 45 degree direction. 2. Press the memory module vertically downward until you hear the “click” sound. Make sure the memory module is firmly in place.

  • Page 73: Installing Mini Pcie Card / Msata

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.5 Installing mini PCIe card / mSATA 1. Two mini PCIe slots are available for PC300 series; the second one can be seen when the HDD bay is removed. They both also support mSATA. 2.

  • Page 74: Installing Antenna

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.6 Installing antenna 1. Three antenna holes are available for PC300 series. 2. Remove antenna hole cover on the system panel. 3. Have antenna jack penetrate through the hole.
  • Page 75 l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4. Put on washer and fasten the nut with antenna jack. 5. Attach the RF connector at the cable-end onto the communication module. 6. Assemble the antenna and antenna jack together.

  • Page 76: Installing Pcie/Pci Expansion Card (Only For Pc311E & Pc311P)

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.7 Installing PCIe/PCI expansion card (Only for PC311E & PC311P) 1. PCIe or PCI card with FHHL dimension is supported by PC311 series. 2. Unscrew the two screws (M3x5L) to remove the expansion window bracket. 3.
  • Page 77 l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4. Install the PCIe/PCI card according to the below direction and then push the card towards the slot to ensure the gold finger is firmly inserted into the slot. 5. Fasten the two screws (M3x5L) on the panel back to lock the card and expansion window bracket.

  • Page 78: Assembly Chassis Top Cover

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.8 Assembly chassis top cover 1. Ensure thermal pad is in place on the CPU thermal block. 2. Close the chassis top cover following the below direction and make sure the aluminum part on the top cover is touching the thermal pad on CPU thermal block.

  • Page 79: Installing Hdd On Removable Sata Hdd Bay

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 3. Fasten the six screws (M3x5L) to lock the system body with top cover. 4.9 Installing HDD on removable SATA HDD bay 1. One removable SATA HDD bays are available for PC300 Series.
  • Page 80 l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 2. Unscrew the two sun screws circled below to take out the removable SATA HDD bay. 3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).

  • Page 81: Installing Sim Card

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4. Slide the HDD bracket back and then fasten the sun screws. 4.10 Installing SIM card 1. For PC300 Series, SIM card slots are located on the side of the system inside protective bracket.
  • Page 82 l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 2. Now you can insert SIM card into the socket. 3. Please note that the installation of SIM 1 and SIM 2 has to match the installation of mini PCIe slots. SIM Card Socket Number Matching Mini PCIe Slot SIM 1 Mini PCIe / mSATA (CN2)

  • Page 83: Connecting Pc Module With Vio Display Module

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.11 Connecting PC module with VIO display module 1. Hold the PC module with its connector facing towards the connector on the back of VIO display module. 2. Press the PC module downward to ensure two modules are firmly connected. 3.

  • Page 84: Screw Location For Pc311 Series Top Cover

    l User’s Manual Chapter 4: System Setup VIO-100(200)/PC300 4.12 Screw location for PC311 series top cover 1. Screw location on the top cover of PC311 series is different from PC300. Highlighted as below.

  • Page 85: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup...

  • Page 86: Bios Introduction

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 87: Main Setup

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 5.2.1 System Language Set the system language.

  • Page 88: Advanced Setup

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3 Advanced Setup 5.3.1 CPU Configuration...

  • Page 89: Trusted Computing (Option)

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ Hyper Threading Technology This item allows you to enable or disable Intel Hyper Threading technology. ■ Active Processor Cores This setting specifies the number of active processor cores. ■ Execute Disable Bit This item allows you to enable or disable the No-Execution page protection technology.

  • Page 90: Acpi Settings

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.3 ACPI Settings Enable or disable ACPI Auto Configuration. ■ Enable ACPI Auto Configuration This item allows you to enable or disable BIOS ACPI Auto Configuration. ■ Enable Hibernation This item allows you to enable or disable system ability to hibernate. 5.3.4 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option.
  • Page 91 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ Serial Port 1 Configuration  Serial Port This item will allow you to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ...
  • Page 92 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ Serial Port 3 Configuration  Serial Port This item will allow you to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ...

  • Page 93: Hardware Monitor

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ Watch Dog Timer You can setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it.

  • Page 94: Serial Port Console Redirection

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.6 Serial Port Console Redirection  Console Redirection This item allows you to enable or disable console redirection.  Legacy Console Redirection Settings Select a COM port to display redirection of legacy OS and legacy OPROM messages. 5.3.7 SATA Configuration...

  • Page 95: Network Stack Configuration

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ SATA Controller(s) This item allows you to enable or disable SATA Controller. ■ SATA Mode Selection This item allows you to select AHCI or RAID Mode. ■ SATA Controller Speed The item is for you to set the maximum speed the SATA controller can support. Change the SATA Speed.

  • Page 96: Csm Configuration

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.9 CSM Configuration ■ CSM Support This item allows you to enable or disable CSM support. ■ GateA20 Active This item allows you to select <Upon Request> or <Always>. Upon Request: GA20 can be disabled using BIOS services. Always: Do not allow GA20 disabling.

  • Page 97: Usb Configuration

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.10 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 98: Intel(R) Ethernet Connection I218-Lm-Xx:xx:xx:xx:xx:xx

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.11 Intel(R) Ethernet Connection I218-LM-XX:XX:XX:XX:XX:XX ■ NIC Configuration Press enter to configure the network device port.  Link Speed Use this item to specify the port speed used for the selected boot protocol. Select <Auto Negotiate>, <10 Mbps Half>, <10 Mbps Full>, <100Mbps Half>...

  • Page 99: Intel(R) I210 Gigabit Network Connection- Xx:xx:xx:xx:xx:xx

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.3.12 Intel(R) I210 Gigabit Network Connection- XX:XX:XX:XX:XX:XX ■ NIC Configuration Press enter to configure the network device port.  Link Speed Use this item to specify the port speed used for the selected boot protocol. Select <Auto Negotiated>, <10 Mbps Half>, <10 Mbps Full>, <100Mbps Half>...

  • Page 100: Chipset

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.4 Chipset 5.4.1 System Agent (SA) Configuration...
  • Page 101 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ▶ Graphics Configuration Use this item to configure internal graphics controller.  GTT Size This item allows you to change the GTT size.  Aperture Size This item allows you to change the Aperture size. ...

  • Page 102: Pch-Io Configuration

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.4.2 PCH-IO Configuration ▶ PCI Express Configuration...
  • Page 103 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300  PCI Express Root Port 1 / 2 / 3 / 5  PCI Express Port 1 / 2 / 3 / 5 This item allows you to enable or disable PCI Express Port 2 / 4 / 5 / 6 in the chipset. ...
  • Page 104 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ▶ USB Configuration  XHCI Mode Mode of operation of XHCI controller. ▶ PCH Azalia Configuration  Azalia Control Detection of the Azalia device. This item allows you to select <Enabled>, <Disabled> or <Auto>. Disabled: Azalia will be unconditionally be disabled.
  • Page 105 l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 ■ PCH LAN Controller This item allows you to enable or disable the onboard PCH integrated ethernet controller. ■ Wake on LAN This item allows you to enable or disable wake on LAN function. ■...

  • Page 106: Security

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.5 Security This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 5.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 5.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility.

  • Page 107: Boot

    l User’s Manual Chapter 5: BIOS Setup VIO-100(200)/PC300 5.6 Boot This section allows you to configure the boot settings. 5.6.1 Setup Prompt Timeout User Password controls access to the system at boot and to the BIOS Setup utility. 5.6.2 Bootup NumLock State Select the Power-on state for Numlock.

  • Page 108: Save & Exit

    l User’s Manual Chapter 4: BIOS Setup VIO-100(200)/PC300 5.7 Save & Exit This section allows you to configure the boot settings. 5.7.1 Save Changes and Reset This item allows you to reset system setup after saving changes. 5.7.2 Discard Changes and Reset This item allows you to reset system setup without saving any changes.
  • Page 109 Copyright 2016 C&T Solution Inc. All Rights Reserved www.candtsolution.com...
