- Page 1 SIO-200 Series Stainless Steel Panel PCs...
-
Page 2: Table Of Contents
User’s Manual SIO-200 Series Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision ………………………………………………..……………….…......…….. 04 Disclaimer ………………………………….………………………….…………………....04 Copyright Notice ………………………………………………………………………....04 Trademarks Acknowledgment …………..………………………………....... 04 Environmental Protection Announcement ………………….…………………..04 Safety Precautions …………………………………….…………….…………………………….. 05 Technical Support and Assistance ………………….…………….………………... 06 Conventions Used in this Manual ……………………………….….…………….... - Page 3 User’s Manual SIO-200 Series 3.1.11 SDIO Configuration ………………..………….………........28 3.1.12 USB Configuration …………….………….………...........29 3.1.13 Security Configuration ………………..………….……….........30 3.2 Chipset ………..………….………..............31 3.2.1 Northbridge Configuration ……..……………………………………..………………. 31 3.2.2 Southbridge Configuration …….…………………………………..………………….. 33 Security ………………………………………………………..…………………………………………. 34 3.3.1 Security Boot Menu ……..………………………………………….…..………………. 35 Boot …………...……….……………….…….…..….…..…………..…………………………..…..
-
Page 4: Prefaces
User’s Manual Preface SIO-200 Series Prefaces Revision Revision Description Date Manual Released 2023/09/06 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. -
Page 5: Safety Precautions
Preface l User’s Manual SIO-200 Series Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. -
Page 6: Technical Support And Assistance
User’s Manual Preface SIO-200 Series Technical Support and Assistance 1. Visit the C&T Solution Inc website at https://www.candtsolution.com/ where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. -
Page 7: Package Contents
Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty SIO-200 Series Stainless Steel Panel PC Waterproof Connector Cover Set Waterproof M12 S-CODE 4P PWR Cable(SUS316L) Type_ L=3M Ordering Information Model No. -
Page 8: Available Models
User’s Manual Preface SIO-200 Series Available Models Model No. Description 15" XGA Capacitive Touch Stainless Steel Panel PC with SIO-215C-J1900 Celeron Processor J1900, AC IN, M12 PWR Cord , Optical bonding 15" XGA Resistive Touch Stainless Steel Panel PC with... -
Page 9: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 10: Overview
Chapter 1: Product Introductions SIO-200 Series 1.1 Overview The SIO-200 series full IP66/IP69K Waterproof Touchscreen Computer for High-Pressure, High- Temperature Waterproof and Reliable connections resistant to humidity, water, dust, dirt and corrosion. The Rugged Stainless Steel Display for Hygienic Environments. -
Page 11: Hardware Specification
User’s Manual Chapter 1: Product Introductions SIO-200 Series 1.2 Hardware Specification SIO-W221- SIO-W224- Display SIO-215-J1900 SIO-W215-J1900 8365UE 8365UE LCD Size 15" (4:3) 15.6" (16:9) 21.5" (16:9) 23.8" (16:9) Max. Resolution 1024 x 768 1920 x 1080 (FHD) 1920 x 1080 (FHD) - Page 12 User’s Manual Chapter 1: Product Introductions SIO-200 Series Environment Physical • Operating Temp • Front Panel Construction -20°C to 55°C Stainless Steel SUS316 with Optical bonding • Dimension -20°C to 50°C (21.5” and 23.8”only) • Storage Temp -20°C to 70°C SIO-215 : 385 (W) x 310 (H) x 49.5 (D) mm...
-
Page 13: System I/O
User’s Manual Chapter 1: Product Introductions SIO-200 Series 1.3 System I/O Rear Panel SIO-215-J1900 SIO-W215-J1900 Power Power Supply Voltage 110 ~ 240V AC Input by 2x LAN by M12 X-Code 8-pin M12 S-Code 4pin 2x RS-232/422/485 by M12 A-Code 8-pin 4x USB 2.0 (2 port) by M12 A-code 8-pin... - Page 14 User’s Manual Chapter 1: Product Introductions SIO-200 Series Rear Panel SIO-W221-8365UE SIO-W224-8365UE Power Power Supply Voltage 110 ~ 240V AC Input by 2x LAN by M12 X-Code 8-pin M12 S-Code 4pin 2x RS-232/422/485 by M12 A-Code 8-pin 4x USB 2.0 (2 port) by M12 A-code 8-pin...
-
Page 15: Mechanical Dimension
User’s Manual Chapter 1: Product Introductions SIO-200 Series 1.4 Mechanical Dimensions Unit: mm SIO-215-J1900 SIO-W215-J1900... - Page 16 User’s Manual Chapter 1: Product Introductions SIO-200 Series Mechanical Dimensions Unit: mm SIO-W221-8365UE SIO-W224-8365UE...
-
Page 17: Front Panel Controls
Chapter 2 Front Panel Controls... -
Page 18: Users Controls
User’s Manual Chapter 2: Panel Controls SIO-200 Series 2.1 Users Controls Native touchscreen enable/disable Power On/Off Reset 2.1.1 Power Button System power on or off. 2.1.2 1. Yellow indicates power on. 2. Red indicates HDD access status. 2.1.3 Reset Button Reset system to reboot. -
Page 19: Chapter 3 Bios Setup
Chapter 3 BIOS Setup... -
Page 20: Bios Introduction
User’s Manual Chapter 3: BIOS Setup SIO-200 Series The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. Turn on the computer and press <DEL> to enter the setup screens. -
Page 21: Acpi Settings
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.1 ACPI Settings Enable ACPI Auto Configuration: Enables or Disables BIOS ACPI Auto Configuration. Enable Hibernation: Enable or Disable system ability to Hibernate. ACPI Sleep state: Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. - Page 22 User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.2.1 Serial Port 1 Configuration Device Type Select: Choose from RS-232, RS-422 and RS-485. 3.1.2.2 Serial Port 2-4 Configuration...
-
Page 23: Hardware Monitor
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.3 Hardware Monitor 3.1.4 Serial Port Console Redirection Serial port console redirection settings. -
Page 24: Cpu Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.5 CPU Configuration Intel Virtualization Technology: When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology Power Technology: Configure the power management features. -
Page 25: Sata Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.6 SATA Configuration The BIOS automatically detects the presence of SATA device and the hardware installed in the SATA ports will be showed in the configuration. Each port can be enabled or disabled individually. -
Page 26: Lpss & Scc Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.8 LPSS & SCC Configuration SCC SD Card Support: Options: Disable, Enable. LPSS I2C #2 Support: Options: Disable, Enable. 3.1.9 Network Stack Configuration... -
Page 27: Csm Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.10 CSM Configuration GateA20 Active: [Upon Request] – GA20 can be disabled using BIOS services. [Always] – do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. -
Page 28: Sdio Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.11 SDIO Configuration SDIO Access Mode: Auto Option: Access SD device in DMA mode if controller supports it, otherwise in PIO mode. DMA Option: Access SD device in DMA mode. PIO Option: Access SD device in PIO mode. -
Page 29: Usb Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.12 USB Configuration Legacy USB Support: Auto option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications. XHCI Hand-off: This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. -
Page 30: Security Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.1.13 Security Configuration XE EOP Message: Send EOP Message Before Enter OS. Intel® AT: Enable/Disable BIOS AT Code from Running. Intel® AT Platform PBA: Enable/Disable BIOS AT Code from Running. -
Page 31: Chipset
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.2 Chipset 3.2.1 Northbridge Configuration... - Page 32 User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.2.1.1 Intel IGD Configuration IGD Turbo Enable: Enable/Disable: IGD Turbo. GFX Boost: Enable/Disable GFX Boost. PAVC: Enable/Disable Protected Audio Video Control. DVMT Pre-Allocated: Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device.
-
Page 33: Southbridge Configuration
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.2.2 Southbridge Configuration High Precision Timer: Enable or Disable the High Precision Event Timer. Restore AC Power Loss: Select AC power state when power is re-applied after a power failure. 3.2.2.1 USB Configuration... -
Page 34: Security
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.2.2.2 PCI Express Configuration 3.3 Security Administrator’s and User’s passwords could be set. If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. -
Page 35: Security Boot Menu
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.3.1 Security Boot Menu Secure Boot: Secure Boot can be enabled if the System running in User mode with enrolled Platform Key (PK) and CSM function is disabled. Secure Boot Mode: Secure Boot mode selector. ‘Custom’ Mode enables users to change... -
Page 36: Boot
User’s Manual Chapter 3: BIOS Setup SIO-200 Series 3.4 Boot Setup Prompt Timeout: Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State: Select [Enable] or [Disable] for the keyboard NumLock state. -
Page 37: Chapter 4 Address Map
Chapter 4 Address Map... -
Page 38: I/O Port Address Map
User’s Manual Chapter 4: Address Map SIO-200 Series 4.1 I/O Port Address Map The assignments of the I/O port addresses for the CT-DBT0x under Windows® 7 Ultimate 64-bit are shown below. - Page 39 User’s Manual Chapter 4: Address Map SIO-200 Series I/O Port Address Map (cont'd)
- Page 40 User’s Manual Chapter 4: Address Map SIO-200 Series I/O Port Address Map (cont'd)
-
Page 41: Interrupt Controller (Irq) Map
User’s Manual Chapter 4: Address Map SIO-200 Series 4.2 Interrupt Controller (IRQ) Map The interrupt controller map for the CT-DBT0x under Windows® 7 Ultimate 64-bit is shown below. - Page 42 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 43 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 44 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 45 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 46 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 47 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
- Page 48 User’s Manual Chapter 4: Address Map SIO-200 Series Interrupt Controller (IRQ) Map (cont'd)
-
Page 49: Memory Map
User’s Manual Chapter 4: Address Map SIO-200 Series 4.3 Memory Map The memory map of DRAM for the CT-DBT0x under Windows® 7 Ultimate 64-bit is shown below. - Page 50 User’s Manual Chapter 4: Address Map SIO-200 Series Memory Map (cont'd)
- Page 51 Copyright © C&T Solution Inc. All Rights Reserved. www.candtsolution.com...
