area to prevent the formation of condensate. All ducting should be 150mm
or split into two 75-80mm ducts.
Picture 3

3.4 Siting Guidance

1. Decide upon the right route to be taken to move the unit in to the chosen
position.
2. Try to move the unit in its original case to avoid damage.
3. Be sure to have the unit and electrics fitted by qualified electrician.
4. Ensure that no building materials or debris are allowed to enter the air
ducts at the top of the unit or any extension of the ducts.
4.0 INSTALLATION
4.1 Ducting
Air ducts to and from the heat pump should be 150mm pipe.
The outlets should be fitted with a suitable gravity vent to prevent rain,
debris, animals and plants entering the ducts.
You can use rigid or flexible ducting. It is always best to use insulated ducting
so that condensation is avoided.
