- Page 1 ESP ECOCENT 100L Installation and Operation Manual www.esavep.com 1 of 42 PASHW-003-100LD V 1.9...
- Page 2 READ THIS BEFORE INSTALLING THE UNIT. All un-vented water heating systems above 15 litres (this includes the ESP E c o c e n t Hot Water ASHP’s) MUST be installed to meet the requirements of the local area Building Regulations. It is a legal requirement that the local Building Control Officer be notified of any proposed installation of un-vented water heating systems over 15 litre capacity.
-
Page 3: Table Of Contents
Contents Page 1.0 Preface 2.0 General Notes 2.1 Safety Precautions 2.2 Installation Notes 2.3 Operating Notes 2.4 Moving and Repair Notes 2.5 Siting and Safety Notes 2.6 General Requirements 3.0 Siting the Unit 3.1 Heat Source 3.2 Dehumidification 3.3 Cooling 3.4 Siting Guidance 4.0 Installation 4.1 Ducting... - Page 4 9.1 Schematic Diagram 9.2 Pipe Fittings 9.3 Cold Water Supply 9.4 G3 Requirements 9.5 G3 Guidance 10.0 Moving the unit 10.1 Storage and Transport 10.2 Using a Forklift 10.3 Transporting for Installation 11.0 Hydraulic Connection 11.1 Connection Diagram 12.0 Wiring 12.1 Wiring Diagram 12.2 Earthing 13.0 Operating the Unit...
-
Page 5: General Notes
The manual may be altered and/or updated in any way at the sole discretion of the supplier and/or ESP without notice. 2.0 GENERAL NOTES 2.1 Safety Precautions Below you will find information that is critical for the safe and proper installation and use of the unit. -
Page 6: Installation Notes
2.2 Installation Notes Professional The heat pump must only be installed by a suitably qualified & qualified engineer. Failure to ensure this can cause damage to the unit and installer may cause serious injury. The warranty on the unit will also be is required invalidated if a suitably qualified engineer is not engaged to install Earthing... -
Page 7: Siting And Safety Notes
GUARANTEE. PLEASE NOTE THAT THERE ARE ESSENTIALLY 2 UNITS COMBINED INTO ONE IN THE ESP ECOCENT AND YOU MUST BE SURE TO UNDERSTAND BOTH ELEMENTS - THE INDIRECT HOT WATER CYLINDER AND THE AIR SOURCE HEAT PUMP. PLEASE ALSO NOTE THE... -
Page 8: Siting The Unit
MATTER HAS BEEN CAREFULLY CONSIDERED AND ADEQUATE DUCTING AND VENTILATION HAS BEEN PROVIDED FOR THE UNIT (THE DHW ASHP) AND THAT THE OPEN FLUED APPLIANCE IS FULLY CATERED FOR IN TERMS OF SUITABLE AIR SUPPLY. Please be sure to use appropriate lifting equipment when moving the unit. 3.0 SITING THE UNIT The unit is designed to be wall mounted. -
Page 9: Heat Source
3.1 Heat Source The Ecocent can receive ducted waste heat from another area in the building – duct work can be fixed to the top of the unit and may be up to 8m long without an additional in-line fan in the ductwork being needed. The Ecocent can also draw heat from the room in which it is sited. -
Page 10: Dehumidification
Picture 1 3.2 Dehumidification – The Ecocent can be used to dehumidify rooms that are hot and damp – e.g. Laundry room (See Picture 2). The unit is equipped with a condensate drain that must be properly directed to a suitable waste pipe where the condensate water (non acidic) can drain away. -
Page 11: Siting Guidance
area to prevent the formation of condensate. All ducting should be 150mm or split into two 75-80mm ducts. Picture 3 3.4 Siting Guidance 1. Decide upon the right route to be taken to move the unit in to the chosen position. - Page 12 When servicing the unit, ducting should be checked to make sure that it is clear and obstructions removed. 4.2 Water Supply Bear in mind that the mains water supply to the property will be supplying both the hot and cold water requirements simultaneously. Therefore, it is important that the maximum water demand be assessed and the water supply checked to ensure that it can meet peak demand.
- Page 13 If installing the unit in unvented configuration, an “unvented Pack”, containing the required safety valves must be supplied with the unit and there is likely to be an additional cost for this. 4.3 Outlet Fittings The unit can be used in conjunction with most types of terminal fittings. It is helpful in many mixer showers to have balanced hot and cold water supplies;...
-
Page 14: Installation
• In areas where the water contains a high proportion of solids, e.g. suspended matter that could block the strainer, unless adequate filtration can be ensured. • Where another appliance in the room is vented by way of an open flu. The installation must be carried out in accordance with the relevant requirements of: A) The appropriate Building Regulations: either The Building... - Page 15 5.0 SPECIFICATIONS 5.1 Appearance Air Inlet Air Outlet 5.2 Features Good Looking and Efficient The attractive design allows the unit to be placed in the open in finished utility spaces and basements; depending on ambient conditions, the cost of operation can be up to 75% less of that of an electric water heater, and can be used in locations unsuitable for solar hot water heating.
- Page 16 6.0 TECHNICAL SPECIFICATIONS www.esavep.com 16 of 42 PASHW-003-100LD V 1.9...
- Page 17 7.0 PERFORMANCE 7.1 Technical Performance Model ESP400-003-100L(D) Heating capacity Water tank capacity 100L 0.27 Power input Running current 230V~/50Hz Power supply Compressor number Rotary Compressor Type °C Rated outlet water temp. Noise dB(A) W ater inlet/outlet size inch Net dimensions see the diagram Shipping dimensions...
-
Page 18: Water Supply
7.2 Standing Heat Losses The amount of heat that the Ecocent loses through convection to the surrounding area (standing heat loss) is dependent on a number of things including, for example, the target temperature and the ambient air temperature surrounding the unit. The target temperature is an end user choice and the ambient temperature will depend on location;... - Page 19 But, because the Ecocent unit uses waste heat, the expected recovery times are likely to be much shorter and the following table is indicative of more normal recovery times: Volume Time 24 mins 36 mins 48 mins 72 mins 97 mins 157mins In fact, the recovery times could well be even better than this because the air source will probably warmer than used to calculate the above tables.
- Page 20 7.4 Performance Graphs www.esavep.com 20 of 42 PASHW-003-100LD V 1.9...
- Page 21 8.0 FUNCTIONS Heating Capacity The unit absorbs energy from the air taken in through the inlet ductwork. If the air inlet temperature is low, heating capacity will show a variation from standard conditions. 3 Minutes Protection When the unit stops, if you try to immediately restart the unit or turn on the manual switch, the unit will not run for 3 minutes.
- Page 22 9.3 Cold Water Supply Because water composition can vary greatly, it is not ESP’s policy to issue recommendations relating to water treatment. The user or the owner is responsible for contacting a specialised water treatment company to obtain water treatment advice appropriate to your location.
-
Page 23: Regulations
A 22mm cold water supply is recommended, however, if a 15mm (1/2”) supply exists which provides sufficient flow it may be used. More flow noise may be experienced from small bore pipes due to the increased water velocity through them. The Cold Water should be fitted with a full flow isolation valve which will enable the unit to be isolated from the mains supply for maintenance or servicing. -
Page 24: Specifications
than the nominal outlet size of the safety device, between 18 and 27m at least 3 sizes larger, and so on. Bends must be taken into account in calculating the flow resistance. Refer to Diagram 7 and Table 1 below. An alternative approach for sizing discharge pipes would be to follow BS6700:1987 Specification for design, installation, testing and maintenance of services supplying water for domestic use within buildings and their curtilages, Appendix E,... - Page 25 Examples of acceptable discharge arrangements are: i. ideally below a fixed grating and above the water seal in a trapped gully. ii. downward discharges at low level; i.e. up to 100mm above external surfaces such as car parks, hard standings, grassed areas etc. are acceptable providing that where children may play or otherwise come into contact with discharges a wire cage or similar guard is positioned to prevent contact, whilst maintaining visibility.
- Page 26 iv. where a single pipe serves a number of discharges, such as in blocks of flats, the number served should be limited to not more than 6 systems so that any installation discharging can be traced reasonably easily. The single common discharge pipe should be at least one pipe size larger than the largest individual discharge pipe (D2) to be connected.
- Page 27 11.0 Hydraulic Connection Please bear the following points in mind when connecting the water pipes: The inner surface of all pipes should be clean, with no oxidization or dirt to restrict flow. After connecting pipes, please check the whole system for leaks before applying insulation.
-
Page 28: Installation Diagram
11.1 Installation Diagram Accessories provided: safety release valve. ATTENTION ! After installing the pipework in accordance with the above diagram, open the closest hot water tap and stop valve to fill the vessel. This will purge the system of air and the process can take up to 20mins. - Page 29 12.2 Earthing The unit MUST be earthed and a facility is provided for this in the design. The unit MUST be installed by qualified engineers and electricians. ESP will not accept responsibility for units that are not fitted by appropriately qualified www.esavep.com...
- Page 30 installers. Failure to have the unit fitted by a suitably qualified installer will invalidate the warranty/guarantee of the unit. 13.0 OPERATING THE UNIT Control Panel Power On When the unit is powered on, the unit will either be in stand-by or running depending upon the state when it was turned-off.
- Page 31 Red and yellow lights Illuminated Green and Red lights Illuminated Two Red lights illuminated The three different modes operate as following: 1 Standard mode: When the ‘running’ and the ‘hybrid’ lights are illuminated, the unit is in the standard mode. This is the recommended mode and should be suitable year-round.
- Page 32 Modes can be selected according to the actual demand but it is strongly suggested that standard mode is used the majority of the time. Power on/Power off is the power switch. When the unit is operating, the indicator light is illuminated.
- Page 33 The unit is pre-set to the recommended setting for all parameters. Should you wish to change these settings, you would be advised to discuss your decision with the ESP technical team. The default settings are as follows: www.esavep.com 33 of 42 PASHW-003-100LD V 1.9...
- Page 34 ℃ Function Parameter Default ℃ Target set point ℃ Return temperature difference Set point for elec. Heater ℃ If temp is not reached within this time, elec heater will boost. Target temp. for weekly sterlilization 0min Time for sterilization ℃ 45min Defrosting time ℃...
-
Page 35: Performance
Maintenance should be carried out by a suitably qualified plumber/engineer and any replacement parts used must only be ESP recommended spare parts. It is recommended that maintenance is carried out every 12 months on the cylinder and includes the checks detailed in this manual. - Page 36 warranty/guarantee and the stainless steel cylinder may be seriously damaged. In hard water areas consideration should be given to periodically descaling the immersion heater elements. To do this the unit will need to be drained; Paragraphs 16.4 to and 16.6 below detail how to drain the unit and remove the immersion heater(s).
- Page 37 15.4 Draining the Unit Switch off the electrical supply to the unit. Turn off the mains water supply to the unit. Attach a hosepipe to the drain cock having sufficient length to take waste water to a suitable discharge point below the level of the unit, at least one metre below the unit is recommended.
-
Page 38: Functions
15.6 Refilling the System DO NOT switch on the immersion heater or heat pump part until the system has been completely refilled. Close the unit drain tap. With the hot tap open, turn on the mains water supply. When water flows from the hot tap allow time to purge all the air and to flush through any disturbed particles. - Page 39 16.0 FAULT FINDING The following table lists simple faults and actions that can be attempted to clear the fault. Please ensure that a suitably qualified and experienced engineer/plumber makes any diagnoses and carries out any testing and repair. Fault Possible Causes Remedy 1) Mains cold water supply shut Check and open isolation...
- Page 40 Any disinfection has been carried out in accordance with BS 6700. iii) It has not been modified in any way other than by ESP. iv) It has only been used for the storage of wholesome water. v) It has not been installed in a location liable to be subjected to frost, nor has it been tampered with or been subjected to misuse or neglect.
- Page 41 This warranty/guarantee is not valid for installations outside the United Kingdom or the Republic of Ireland. Any warranty/guarantee is for replacement parts only. The purchaser of the unit acknowledges that he/she has seen ESP’s conditions of supply and has understood them. All of our units are RoHS approved units.
- Page 42 19.0 SPARE PARTS Earth Save Products Limited carries spare parts for all the units that it supplies. We strive to ensure that spare parts are readily available at competitive prices. Please call on 00 44 (0)1865 40 77 69 us should you need any spare parts and we will be pleased to give you a quotation.
