XtendLan xl-raid-2804issa Installation And Configuration Manual

Iscsi sata ii subsystem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XL-RAID-2804ISSA
iSCSI – SATA II SUBSYSTEM
Installation and Configuration
Manual
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xl-raid-2804issa and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XtendLan xl-raid-2804issa

Summary of Contents for XtendLan xl-raid-2804issa

  • Page 1 XL-RAID-2804ISSA iSCSI – SATA II SUBSYSTEM Installation and Configuration Manual Revision 1.0...

  • Page 2: Table Of Contents

    Technical Specifications..........................7 Terminology ................................ 9 RAID Concepts ..............................11 Chapter 2 Getting Started ...................16 Packaging, Shipment and Delivery ......................16 Unpacking the Subsystem.......................... 16 Identifying Parts of the XL-RAID-2804ISSA Subsystem ................. 17 2.3.1 Front View ..............................17 2.3.2 Rear View..............................17 2.3.3...
  • Page 3 3.4.5 Password ..............................34 3.4.6 Date................................34 3.4.7 Mail ................................35 3.4.8 SNMP................................35 3.4.9 Messenger ..............................36 3.4.10 System Log Server..........................36 3.4.11 Event Log ............................... 37 iSCSI Config ..............................38 3.5.1 Entity Property............................38 3.5.2 NIC................................39 3.5.3 Node................................
  • Page 4 4.4.2 Auto Snapshot............................75 4.4.3 Rollback ..............................75 Disk Roaming..............................76 Support Microsoft MPIO and MC/S....................... 76 Appendix ........................77 A. Certification List ..............................77 B. Event Notifications............................79 C. Known Issues..............................83 D. Microsoft iSCSI Initiator ..........................83 E. Trunking/LACP Setup Instructions ......................87 F.

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction The XL-RAID-2804ISSA RAID Subsystem XL-RAID-2804ISSA connects to the host system in iSCSI interface. It can be configured to any RAID level. XL-RAID-2804ISSA provides reliable data protection for servers and the RAID 6 function is available. The RAID 6 function allows two HDD failures without any impact on the existing data.

  • Page 6: Key Features

    1.1 Key Features 2 x GbE ports support independent access, fail-over or load-balancing (802.3ad port trunking, LACP) Supports iSCSI jumbo frame Supports Microsoft Multipath I/O (MPIO) Supports RAID levels 0, 1, 0+1, 3, 5, 6, 10, 30, 50, 60 and JBOD Local N-way mirror: Extension to RAID 1 level, N copies of the disk.

  • Page 7: Technical Specifications

    1.2 Technical Specifications Form Factor: 2U 19-inch rackmount chassis RAID processor: Intel IOP341 64-bit RAID Level: 0, 1, 0+1, 3, 5, 6, 10, 30, 50, 60 and JBOD N-way mirror (N copies of the disk) Cache memory: 512MB ~ 2GB DDR II No.
  • Page 8 New disk insertion / removal detection Auto volume rebuild Array roaming Audible alarm Password protection UPS connection Hot-swap power supplies: Two (2) 350W power supplies w/PFC Cooling fans: 2 Battery backup(Option) Power requirements: AC 90V ~ 264V full range, 8A ~ 4A, 47Hz ~ 63Hz Environmental Relative Humidity: 10% ~ 85% Non-condensing Operating Temp: 10...

  • Page 9: Terminology

    VG share the same RAID level, but may have different volume capacity. Cache Volume. XL-RAID-2804ISSA uses the on board memory as cache. All RAM (except for the part which is occupied by the controller) can be used as cache. User can divide the cache for one UDV or sharing among all UDVs.
  • Page 10 Set the volume to be Read-Only. Dedicated Spare disks. The spare disks are only used by one specific VG. Others could not use these dedicated spare disks for any rebuilding purpose. Global Spare disks. GS is shared for rebuilding purpose. If some VGs need to use the global spare disks for rebuilding, they could get the spare disks out from the common spare disks pool for such requirement.

  • Page 11: Raid Concepts

    1.4 RAID Concepts RAID Fundamentals The basic idea of RAID (Redundant Array of Independent Disks) is to combine multiple inexpensive disk drives into an array of disk drives to obtain performance, capacity and reliability that exceeds that of a single large drive. The array of drives appears to the host computer as a single logical drive.
  • Page 12 Definition of RAID Levels RAID 0 is typically defined as a group of striped disk drives without parity or data redundancy. RAID 0 arrays can be configured with large stripes for multi-user environments or small stripes for single-user systems that access long sequential records. RAID 0 arrays deliver the best data storage efficiency and performance of any array type.
  • Page 13 the information recorded on the remaining drives. Records typically span all drives, which optimizes the disk transfer rate. Because each I/O request accesses every drive in the array, RAID 3 arrays can satisfy only one I/O request at a time. RAID 3 delivers the best performance for single-user, single-tasking environments with long records.
  • Page 14 RAID 6 is similar to RAID 5 in that data protection is achieved by writing parity information to the physical drives in the array. With RAID 6, however, sets of parity data are used. These two sets are different, and each set occupies a capacity equivalent to that of one of the constituent drives.

  • Page 15: Raid Management

    RAID Management The subsystem can implement several different levels of RAID technology. RAID levels supported by the subsystem are shown below. RAID Level Description Min. Drives Block striping is provide, which yields higher performance than with individual drives. There is no redundancy.

  • Page 16: Chapter 2 Getting Started

    Chapter 2 Getting Started 2.1 Packaging, Shipment and Delivery Before removing the subsystem from the shipping carton, you should visually inspect the physical condition of the shipping carton. Unpack the subsystem and verify that the contents of the shipping carton are all there and in good condition.

  • Page 17: Identifying Parts Of The Xl-Raid-2804Issa Subsystem

    2.3 Identifying Parts of the XL-RAID-2804ISSA Subsystem The illustrations below identify the various parts of the subsystem. 2.3.1 Front View 2.3.2 Rear View...
  • Page 18 1. Power Supply Alarm Reset button You can push the power supply reset button to stop the power supply buzzer alarm. 2. Uninterrupted Power Supply (UPS) Port (APC Smart UPS only) The subsystem may come with an optional UPS port allowing you to connect a APC Smart UPS device.

  • Page 19: Environmental Status Leds

    2.3.3 Environmental Status LEDs Parts Function Power LED Green LED indicates power is ON. If a redundant power supply unit fails, this LED Power Fail LED will turn to RED and alarm will sound. When a fan fails, this LED will turn red and an Fan Fail LED alarm will sound.

  • Page 20: Smart Function Panel

    2.3.4 Smart Function Panel PARTS FUNCTION Up and Down Use the Up or Down arrow keys to go through Arrow buttons the information on the LCD screen. This is also used to move between each menu when you configure the subsystem. This is used to enter the option you have Select button selected.

  • Page 21: Powering On

    2.5 Powering On 1. Plug in all the power cords into the AC Power Input Socket located at the rear of the subsystem. 2. Turn on Power Switch 1 and 2. 3. The Power LED on the front Panel will turn green. 2.6 Installing Hard Drives This section describes the physical locations of the hard drives supported by the subsystem and give instructions on installing a hard drive.

  • Page 22: Hdd Status Indicator

    Slide the tray into a slot until it clicks into place. The HDD status LED will turn green if subsystem is on. Press the lever in until you hear the latch click into place. g. If the HDD power LED did not turn green, check the hard drive is in good condition. If the hard drive is not being accessed, the HDD access LED will not illuminate.

  • Page 23: Iscsi Introduction

    2.7 iSCSI Introduction iSCSI (Internet SCSI) is a protocol which encapsulates SCSI (Small Computer System Interface) commands and data in TCP/IP packets for linking storage devices with servers over common IP infrastructures. iSCSI provides high performance SANs over standard IP networks like LAN, WAN or the Internet.

  • Page 24: Management Methods

    There are three management methods to manage XL-RAID-2804ISSA, describe in the following: 2.8.1 Web GUI XL-RAID-2804ISSA support graphical user interface to manage the system. Be sure to connect LAN cable to your R-Link port. The default setting of management port IP is DHCP and the DHCP address displays on LCM;...

  • Page 25: Console Serial Port

    Terminal type: vt100 Login name: admin Default password: 00000000 2.8.3 Remote Control – Secure Shell SSH (secure shell) is required for XL-RAID-2804ISSA to remote login. The SSH client software is available at the following web site: SSHWinClient WWW: http://www.ssh.com/ Putty WWW: http://www.chiark.greenend.org.uk/...

  • Page 26: Enclosure

    2.9 Enclosure 2.9.1 LCD Control Module (LCM) There are four buttons to control XL-RAID-2804ISSA LCM (LCD Control Module). These are: (Escape) (Enter) c(up) d(down) After booting up the system, the following screen shows management port IP and model name: 192.168.10.50 XL-RAID-2804ISSA ←...

  • Page 27: System Buzzer

    The following is LCM menu hierarchy. [Firmware Version] [System Info] [RAM Size] [cYes Nod] [Alarm Mute] [Reset] [cYes Nod] [Reset/Shutdown] [Shutdown] [cYes Nod] RAID 0 (RAID Volume Size Adjust Volume 1/RAID 3/ RAID (xxxxxx G) Size [Quick Install] 5/RAID 6) Apply The [cYes Nod]...

  • Page 28: Chapter 3 Web Gui Guideline

    Chapter 3 Web GUI Guideline 3.1 XL-RAID-2804ISSA GUI Hierarchy The below table is the hierarchy of XL-RAID-2804ISSA GUI. Quick Install Step 1 / Step 2 / Step 3 / Confirm System Config System name System name IP address DHCP / Static / HTTP port / HTTPS port / SSH port...

  • Page 29: Login

    3.2 Login XL-RAID-2804ISSA supports graphic user interface (GUI) to operate the system. Be sure to connect the LAN cable. The default IP setting is DHCP; open the browser and enter: http://192.168.10.50 (Please check the DHCP address first on LCM) Click any function at the first time; it will pop up a dialog for authentication.

  • Page 30: Quick Install

    E.g., user chooses RAID 5 and the system has 6*200G HDD and 2*80HDD inserted. Then if using all 8 HDD for a RAID 5, the volume max size will be 560G (80G*7). But XL-RAID-2804ISSA will do a smarter check and find out the most efficient use of HDDs. This results in using only the 200G HDD (Volume size is 200*5=1000G).
  • Page 31 Step 2: Please select a LUN number. Access control of host would show as a wildcard “*”, which means every host can access this volume. In this page, the “Volume size” can be changed. The maximum volume size is shown. To re-enter the size be sure it has to be less or equal to maximum volume size.

  • Page 32: System Configuration

    “System config” selection is for the setup of “System name”, “IP address”, “Login config”, “Password”, “Date”, “Mail”, “SNMP” and view “Event log”. 3.4.1 System Name Select “System name” to change system name. Default system name composed by model name, ex: XL-RAID-2804ISSA.

  • Page 33: Ip Address

    3.4.2 IP address Select “IP address” to change IP address for remote administration usage. There are 2 selections, DHCP (Get IP address from DHCP server) or static IP. The default setting is DHCP enabled. User can change the HTTP, HTTPS, and SSH port number when the default port number is not allowed on host/server.

  • Page 34: Login Config

    3.4.4 Login Config Select “Login config” is to set only one admin and set the auto logout timing. The only one admin can prevent multiple users access the same controller in the same time. 1. Auto logout: Options are (1) Disable (2) 5 mins (3) 30 mins (4) 1 hour. When user is no response for a period of time, the system will logout automatically to allow another user to login.

  • Page 35: Mail

    3.4.7 Mail Select “Mail” to enter at most 3 mail addresses for receiving the event notification. Some mail servers would check “Mail-from address” and need authentication for anti-spam. Please fill the necessary fields and select “Send test mail” to check whether the email works fine. User can also select which levels of event logs are needed to be sent out by Mail.

  • Page 36: Messenger

    3.4.9 Messenger Select “Messenger” to set up pop-up message alert via Windows messenger (not MSN). User must enable the service “Messenger” in Windows (Start Control Panel Administrative Tools Services Messenger), and then event logs can be received. It allows up to 3 messenger addresses.

  • Page 37: Event Log

    Select “Event log” to view the event messages. Press “Filter” button to choose the display. Press “Download” button will save the whole event log as text file with file name “log-ModelName- SerialNumber-Date-Time.txt” (E.g., log-XL-RAID-2804ISSA-A00021-20061011-114718.txt). Press “Clear” button will clear event log. Press “Mute” button will stop alarm if system alerts.

  • Page 38: Iscsi Config

    “CHAP account”. 3.5.1 Entity Property Select “Entity property” to view the the entity name of the XL-RAID-2804ISSA, and setup “iSNS IP” for iSNS service. iSNS is the abbreviation of Internet Storage Name Service. Add an iSNS server IP address to the iSNS servers list which the iSCSI initiator service can send queries.

  • Page 39: Nic

    3.5.2 NIC Select “NIC” to change IP addresses of iSCSI data ports. There are two gigabit LAN ports to transmit data. Each of them must be assigned to one IP address in multi-homed mode unless the link aggregation or trunking mode has been selected. If they are set in link aggregation or trunking mode, the second line will not show in the screen.

  • Page 40: Node

    Multi-homed: The two LAN ports are connected to two different networks. Multi- homed is default. Trunking: Trunking links 2 LAN ports together to be a single link. Trunking could multiply the bandwidth. They will be aggregated to one IP. If clicking the blue square button at “No.

  • Page 41: Session

    NOTE: After setting CHAP, the initiator in host/server should be set the same Account/Password. Otherwise, user cannot login. Select “None” to disable the authentication method. 3.5.4 Session Enter “Session” function, it will display iSCSI session and connection information, including the following items: 1.

  • Page 42: Volume Configuration

    3.6 Volume Configuration “Volume config” selection is for the setup of volume configurations including “Physical disk”, “Volume group”, “User data volume”, “Cache volume”, and “Logical unit” functions. 3.6.1 Volume Relationship Diagram The below diagram describes the relationship of RAID components. One VG (Volume Group) consists of a set of UDVs (User Data Volume) and owns one RAID level attribute.

  • Page 43: Physical Disk

    LUN 1 LUN 2 LUN 3 UDV 1 UDV 2 Snap Global CV Dedicated PD 1 PD 2 PD 3 3.6.2 Physical Disk Enter “Physical disk” to view the status of hard drives inserted in the system. The following are operation tips: Multiple select.
  • Page 44 PD column description: The position of hard drives. The number of slot begins from left Slot to right at the front side. The blue square button next to the number of slot is “More Information” indication. It shows the details of the hard drive. World Wide Name.

  • Page 45: Volume Group

    DEDICATED Set hard drive(s) to dedicated spare of selected VGs. SPARES XL-RAID-2804ISSA also provides HDD auto spin down function to save power. The default value is disabled. User can set up in physical disk page, too. 3.6.3 Volume Group Enter “Volume group” to view the status of each volume group.
  • Page 46 Number of volume group. The blue square button next to the No. is “More Information” indication. It shows the details of the volume group. Name Volume group name. The blue square button next to the Name is “Rename” function. Total(GB) Total capacity of this volume group.

  • Page 47: User Data Volume

    3.6.4 User Data Volume Enter “User data volume” function to view the status of each user data volume. UDV column description: Number of this user data volume. The blue square button in below to the UDV No. is “More Information” indication. It shows the details of the User data volume.

  • Page 48: Cache Volume

    Ratio of initializing or rebuilding. RAID The RAID levels that user data volume is using. #LUN Number of LUN(s) that data volume is attaching. Snapshot(GB) The user data volume size that used for snapshot. The blue square button next to the snapshot is “Resize” function to decide the snapshot space.

  • Page 49: Logical Unit Number

    CV column description: Number of the Cache volume. The blue square button next to the CV No. is “More Information” indication. It shows the details of the cache volume. Size(MB) Total capacity of the cache volume The blue square button next to the CV size is “Resize”...

  • Page 50: Examples

    LUN operations description: ATTACH Attach a logical unit number to a user data volume. DETACH Detach a logical unit number from a user data volume. The matching rules of access control are from top to down by sequence. For example: there are 2 rules for the same UDV, one is “*”, LUN 0;...
  • Page 51 volume is created after system boots up automatically. So, no action is needed to set CV. Then set a global spare disk. The last, delete all of them. Step 1: Create VG (Volume Group). To create the volume group, please follow the procedures: Select “/ Volume config / Volume group”.
  • Page 52 Select “/ Volume config / User data volume”. Click Input a UDV name, choose a VG Name and input a size to the UDV; decide the stripe high, block size, read/write mode and set priority, finally click Done. A UDV has been created. Do one more time to create another UDV.
  • Page 53 Select a UDV. Input “Host”, which is an initiator node name for access control, or fill-in wildcard “*”, which means every host can access this volume. Choose LUN and permission, then click Done. NOTE: The matching rules of access control are from top to bottom by sequence.
  • Page 54 Step 5: Done. They can be used as iSCSI disks. Delete UDVs, VG, please follow the steps. Step 6: Detach LUN from UDV. In “/ Volume config / Logical unit”, Select LUNs by clicking the checkbox of the row, then click There will pop up a confirm page.
  • Page 55 Select “/ Volume config / User data volume”. Select UDVs by clicking the checkbox of the row. Click . There will pop up a confirm page. Choose “OK”. Done. Then, the UDVs are deleted. IMPORTANT! When deleting UDV, the attached LUN(s) related to this UDV will be detached automatically, too.
  • Page 56 cache volume. Or user can create a dedicated cache for indivifual UDV manually. Using dedicated cache volume, the performance would not be affected by the other UDV’s data access. The total cache size depends on the RAM size and set all to global cache automatically. To create a dedicated cache volume, first step is to cut down global cache size for the dedicated cache volume.
  • Page 57 Select “/ Volume config / User data volume”. Click Input a UDV name, choose a VG Name, select Dedicated cache which is created at Step 1, and input the size for the UDV; decide the stripe height, block size, read/write mode and set priority, finally click Done.
  • Page 58 Step 4: Attach LUN to UDV. Please refer to Step 3 of Example 1 to attach LUN. Step 5: Set dedicated spare disk. To set dedicated spare disks, please follow the procedures: Select “/ Volume config / Physical disk”. Select a VG from the list box, and then select the free disk(s), click to set as dedicated spare for the selected VG.
  • Page 59 Step 6: Done. The PDs can be used as iSCSI disks. Delete UDVs, VG, please follow the steps. Step 7: Detach LUN from UDV. Please refer to Step 6 of Example 1 to detach LUN. Step 8: Delete UDV (User Data Volume). Please refer to Step 7 of Example 1 to delete UDV.

  • Page 60: Enclosure Management

    3.7 Enclosure Management “Enclosure management” function allows managing enclosure information including “SES config”, “Hardware monitor”, “S.M.A.R.T.” and “UPS” functions. For the enclosure management, there are many sensors for different purposes, such as temperature sensors, voltage sensors, hard disks, fan sensors, power sensors, and LED status. And due to the hardware characteristics are different among these sensors, for different sensors, they have different polling intervals.

  • Page 61: Hardware Monitor

    For better data protection, please check “Auto Shutdown”. For better protection and to avoid single short period of high temperature triggering Auto shutdown, XL-RAID-2804ISSA use multiple condition judgments for Auto shutdown, below is the detail of when the Auto shutdown will be triggered.

  • Page 62: Hard Drive S.m.a.r.t. Function Support

    1. There are 3 sensors placed on controllers for temperature checking, on core processor, on PCI- X bridge, and on daughter board. XL-RAID-2804ISSA will check each sensor every 30 seconds. When one of these sensors is over the high temperature value for continuous 3 minutes, the Auto shutdown will be triggered immediately.

  • Page 63: Ups

    3.7.4 UPS Enter “UPS” function will set UPS (Uninterruptible Power Supply). Currently, the system only support and communicate with smart-UPS function of APC (American Power Conversion Corp.) UPS. Please check detail from http://www.apc.com/. First, connect the system and APC UPS via RS-232 for communication. Then set up the shutdown values when the power is gone.

  • Page 64: System Maintenance

    3.8 System Maintenance “Maintenance” function allows operation of the system functions including “Upgrade” to the latest firmware, “Info” to show the system version, “Reset to default” to reset all controller configuration values to origin settings, “Config import & export” to export and import all controller configuration except for VG/UDV setting and LUN setting, and “Shutdown”...

  • Page 65: Info

    NOTE: When upgrading FW, XL-RAID-2804ISSA can only accept the newer version and guarantee the compatibility issue which means, if customer changes FW to older version, the VG/UDV/LUN config may be lost. 3.8.2 Info Enter “Info” function will display system type, FW number, CPU type, RAM size, and serial number.
  • Page 66 Login config Admin account login config with (1) Auto logout setting, (2) Admin login lock Password Admin password value with (1) Current password, (2) Old password Date Time Zone setting Mail Event log mail setting with (1) Mail_from address, (2) SMTP server, (3) Authentication, (4) Mail account ID, (5) Mail password, (6) Mail_To_1 address, (7) Mail_To_2 address, (8) Mailt_To_3 address, (9) Event log filter setting...

  • Page 67: Shutdown

    3.8.5 Shutdown Enter “Shutdown” function; it will display “Reboot” and “Shutdown” buttons. Before power off, it’s better to press “Shutdown” to flush the data from cache to physical disks. The step is better for the data protection. 3.9 Logout For security reason, “Logout” function will allow logout while no user is operating the system. Re- login the system, please enter username and password again.

  • Page 68: Chapter 3 Advanced Operation

    XL-RAID-2804ISSA support Auto-Rebuild function. When the RAID level allows disk failures which the VG is protected, such as RAID 3, RAID 5, RAID 6, and etc, XL-RAID-2804ISSA starts Auto-Rebuild as below scenario: Take RAID 6 for example: 1.
  • Page 69 Sometimes, rebuild is called recover; these two have the same meaning. The following table is the relationship between RAID levels and rebuild. RAID 0 Disk striping. No protection of data. VG fails if any hard drive fails or unplugs. RAID 1 Disk mirroring over 2 disks.

  • Page 70: Vg Migration And Expansion

    4.2 VG Migration and Expansion To migrate the RAID level, please follow the below procedures. If the VG migrates to the same RAID level of the original VG, it is expansion. Select “/ Volume config / Volume group”. Decide which VG to be migrated, click the blue square button in the RAID column next the RAID level.
  • Page 71 INPORTANT! To do migration/expansion, the total size of VG must be larger or equal to the original VG. It does not allow expanding the same RAID level with the same hard disks of original VG. During setting migration, if user doesn’t setup correctly, controller will pop up warning messages.

  • Page 72: Udv Extension

    4.3 UDV Extension To extend UDV size, please follow the procedures. Select “/ Volume config / User data volume”. Decide which UDV to be extended, click the blue square button in the Size column next the number. Change the size. The size must be larger than the original,...

  • Page 73: Snapshot /Rollback

    4.4 Snapshot /Rollback XL-RAID-2804ISSA Snapshot-on-the-box captures the instant state of data in the target volume in a logical sense. The underlying logic is Copy-on-Write -- moving out the to-be-written data to certain location whenever a write action occurs since the time of data capture. The certain location, named as snap UDV, is essentially a new UDV,.which can be attached to a LUN thus provisioned...
  • Page 74 (GB)” column. These numbers mean “Free snapshot space” and “Total snapshot space”. Choose clicking checkbox then click A snapshot UDV is created with the date and time taken snapshot of the chosen UDV. The snapshot UDV size is the same as the chosen UDV no matter the actual snapshot UDV data occupies.

  • Page 75: Auto Snapshot

    4.4.2 Auto Snapshot The snapshot copies can be taken manually or by schedule such as hourly or daily. Please follow the procedures. Select “/ Volume config / User data volume”. Create a snapshot space. Please refer to section 4.4.1 for more detail. in “Snapshot (GB)”...

  • Page 76: Disk Roaming

    Microsoft iSCSI initiator supports multi-path function. Please follow the procedures to use MPIO feature. A host with dual LAN ports connects cables to XL-RAID-2804ISSA. Create a VG/UDV, attach this UDV to the host. When installing “Microsoft iSCSI initiator”, please install MPIO driver at the same time.

  • Page 77: Appendix

    Appendix A. Certification List RAM Spec: 184pins, DDR333(PC2700), Reg.(register) or UB(Unbufferred), ECC or Non- ECC, from 64MB to 1GB, 32-bit or 64-bit data bus width, x8 or x16 devices, 9 to 11 bits column address. Vendor Model Unigen UG732D6688KN-DH, 256MB DDR333 (UNBUFFERED) with Hynix Unigen UG732D6688KS-DH, 256MB DDR333 (UNBUFFERED, LOW PROFILE) with Hynix...
  • Page 78 For ATTO initiator, it is not free. Please contact your local distributor for ATTO initiator. iSCSI HBA card Vendor Model Adaptec 7211C (Gigabit, 1 port, TCP/IP offload, iSCSI offload) QLogic QLA4010C (Gigabit, 1 port, TCP/IP offload, iSCSI offload) Qlogic QLA4052C (Gigabit, 2 port, TCP/IP offload, iSCSI offload) For detailed setup steps of Qlogic QLA4010C, please refer to Appendix G: QLogic QLA4010C setup instructions.

  • Page 79: Event Notifications

    B. Event Notifications PD/S.M.A.R.T. events Level Type Description Info Disk inserted Info: Disk <slot> is inserted. Info Disk removed Info: Disk <slot> is removed. Warning S.M.A.R.T. Warning: Disk <slot> S.M.A.R.T. threshold threshold exceed exceed condition occurred for attribute of condition read error rate spin up time reallocated sector count...
  • Page 80 Environmental events Level Type Description Info Admin Login OK Info: Admin login from <IP or serial console> via <Web UI or Console UI>. Info Admin Logout OK Info: Admin logout from <IP or serial console> via <Web UI or Console UI>. Info iSCSI data port Info: iSCSI login from <IQN>...
  • Page 81 System config events Level Type Description Info Sys Config. Info: Default system configurations restored. Defaults Restored Info Sys NVRAM OK Info: The system NVRAM is active. Error Sys NVRAM IO Error: Can’t access the system NVRAM. Failed Warning Sys NVRAM is full Warning: The system NVRAM is full.
  • Page 82 Info UDV Init OK Info: UDV <name> completes the initialization. Warning UDV_OP Stop Warning: Fail to complete UDV <name> Initialization initialization. Warning UDV IO Fault Error: IO failure for stripe number <number> in UDV <name>. Warning VG Failed Error: Fail to access VG <name>. Warning UDV Failed Error: Fail to access UDV <name>.

  • Page 83: Known Issues

    Info Snapshot rollback Info: The snapshot of UDV <name> rollback start start. Info Snapshot rollback Info: The snapshot of UDV <name> rollback finish finish. C. Known Issues Microsoft MPIO is not supported on Windows XP or Windows 2000 Professional. Workaround solution: Using Windows Server 2003 or Windows 2000 server to run MPIO.
  • Page 84 Click “OK”. Click “Targets”.
  • Page 85 Click “Log On”. Check “Enable multi-path” if running MPIO. Click “Advance” if CHAP information is needed. Click “OK”. The status would be “Connected”. Done, it can connect to an iSCSI disk.
  • Page 86 The following procedure is to log off iSCSI device. a. Click “Details”. b. Check the Identifier, which will be deleted. c. Click “Log off”. d. Done, the iSCSI device log off successfully.

  • Page 87: Trunking/Lacp Setup Instructions

    E. Trunking/LACP Setup Instructions Here is the step by step to setup Trunking and LACP. There are 2 kinds of scenarios for Trunking/LACP. The setup instructions are in the following figures. Create a VG with RAID 5, using 3 HDDs. Create a UDV by using the RAID 5 VG.
  • Page 88 Run Microsoft iSCSI initiator 2.03 and check the Initiator Node Name. Attaching LUN to R5 UDV. Input the Initiator Node Name in the Host field. Done, please check the settings.
  • Page 89 Check iSCSI settings. The IP address of iSCSI data port 1 is 192.168.11.229. Using port 1 as Trunking or LACP. Click the blue square in “Aggregation” field to set Trunking or LACP. Select “Trunking”. If LACP is needed. Now, the setting is in Trunking mode.
  • Page 90 Enable switch Trunking function of port 21 and 23. Below is an example of Dell PowerConnect 5324. Go to Figure E.14 for next step. Select “LACP”. If Trunking is needed. Now, the setting is LACP mode.
  • Page 91 Enable switch LACP function of port 21 and 23. Below is an example of Dell PowerConnect 5324. Add Target Portals in Microsoft iSCSI initiator 2.03.
  • Page 92 Input the IP address of iSCSI data port 1 (192.168.11.229 as mentioned in previous page). Click “Targets” to log on. Log on.
  • Page 93 Click “Advanced”. Select Target Portal to iSCSI data port 1 (192.168.11.229). Then click “OK”.
  • Page 94 The setting is completed. Run “Computer Management” in Windows. Make sure the disks are available. Then the disks can be tested for performance by IOMETER.

  • Page 96: Mpio And Mc/S Setup Instructions

    F. MPIO and MC/S Setup Instructions Here is the step by step to setup MPIO. There are 2 kinds of scenarios for MPIO. Please see Figure F.1. XL-RAID-2804ISSA suggests using scenario 2 for better performance. Network diagram of MPIO. The setup instructions are in the following figures.
  • Page 97 Create a UDV by using RAID 5 VG. Run Microsoft iSCSI initiator 2.03 and check the Initiator Node Name. Attaching LUN to R5 UDV. Input the Initiator Node Name in Host field.
  • Page 98 The volume config setting is done. Check iSCSI settings. The IP address of iSCSI data port 1 is 192.168.11.229, port 2 is 192.168.12.229 for example. Add Target Portals on Microsoft iSCSI initiator 2.03.
  • Page 99 Input the IP address of iSCSI data port 1 (192.168.11.229 as mentioned in previous page). Add second Target Portals on Microsoft iSCSI initiator 2.03.
  • Page 100 Input the IP address of iSCSI data port 2 (192.168.12.229 as mentioned in previous page). The initiator setting is done.
  • Page 101 Log on. Enable “Enable multi-path” checkbox. Then click “Advanced”.
  • Page 102 Select Target Portal to iSCSI data port 1 (192.168.11.229). Then click “OK” Log on again.
  • Page 103 Enable “Enable multi-path” checkbox. Then click “Advanced”. Select Target Portal to iSCSI data port 2 (192.168.12.229). Then select “OK”...
  • Page 104 iSCSI device is connected. Click “Details”. Click “Device” tab, then click “Advanced”.
  • Page 105 Click “MPIO” tab, select “Load Balance Policy” to “Round Robin”. Click “Apply”.
  • Page 106 Run “Device Manager” in Windows. Make sure MPIO device is available. Then the disk can be tested performance by IOMETER. The MC/S setup instructions are very similar to MPIO, detail steps are in the following figures. For the target side setting, the steps are exactly the same as MPIO. Create a VG with RAID 5, using 3 HDDs.
  • Page 107 Log on. Then click “Advanced”. Select set Local Adapter, Source IP, and Target Portal to iSCSI data port 1 (192.168.11.229). Then click “OK”...
  • Page 108 After connected, click “Details”, then in the “Session” tab, click “Connections” Choose “Round Robin” for Load Balance Policy...
  • Page 109 “Add” Source Portal for the iSCSI data port 2(192.168.12.229) Select Local adapter, Source IP, and Target Portal to iSCSI data port 2 (192.168.12.229). Then select “OK”...
  • Page 110 The MC/S setting is done.

  • Page 111: Qlogic Qla4010C Setup Instructions

    G. QLogic QLA4010C Setup Instructions The following is the step by step setup of Qlogic QLA4010C. Log on the iSCSI HBA Manager and the current state shows “No Connection Active”. Click “Target settings”. Then select the target and click “Config Parameters”.
  • Page 112 Disable “Immediate Data” and enable “Initial R2T”. Click “OK”.
  • Page 113 Click “Save settings” and click “Yes” on next page. Click “Refresh” and find a new target with iSCSI name.
  • Page 114 Check the parameters which “Initial R2T” are enabled. Check “Target Information” again and the state changed to “Session Active”.
  • Page 115 Then, run “Computer Management” in Windows. Make sure the disk appears.

  • Page 116: Installation Steps For Large Volume (Tb)

    H. Installation Steps for Large Volume (TB) Introduction: XL-RAID-2804ISSA are capable to support large volumes (>2TB) on all product lines. When connecting XL-RAID-2804ISSA to 64bit OS installed host/server, the host/server is inherently capable for large volumes from the 64bit address. On the other side, if the host/server is installed with 32bit OS, user has to change the block size to 1KB, 2KB or 4KB to support volumes up to 4TB, 8TB or 16TB, for the 32bit host/server is not LBA (Logical Block Addressing) 64bit supported.
  • Page 117 Choose RAID Level and Disks Confirm VG Settings A RAID 6 (size 2793G) VG is created 2. Go to \Volume config\User data volume, create a UDV Create a UDV...
  • Page 118 Setup Capacity, Stripe Height, and Block Size for UDV NOTE: When the OS is 64bit, user can set the block size to any available value. If the OS is 32bit, user has to change the block size to larger values than 512B. There will be a confirmation pop-up when UDV size is over 2TB for reminding.
  • Page 119 block size = 512B, for 64bit OS setting block size = 4K, for 32bit OS setting Attach LUN for iSCSI controller Attach LUN...
  • Page 120 Step B: configure your host/server 1. User needs to setup software iSCSI initiator or iSCSI HBA first. 2. Below is the configuration for Windows Server 2003 R2 with Microsoft iSCSI initiator. Please install the latest Microsoft iSCSI initiator from below link. http://www.microsoft.com/downloads/details.aspx?FamilyID=12cb3c1a-15d6-4585-b385- befd1319f825&DisplayLang=en Run MS iSCSI initiator, go to “Discovery”...
  • Page 121 Go to “Targets” tab, click “Refresh”, and then “Log On…” the target. Status is “Connected”, the initiator setting is done. Step C: Initialize/Format/Mount the disk 1. Go to Control Panel \Computer Management\Device Manger\Disk drives 2. Go to Control Panel \Computer Management\Disk Management...
  • Page 122 New Disk Initialize Disk Convert to GPT Disk for over 2TB capacity. For more detail about GPT, please visit http://www.microsoft.com/whdc/device/storage/GPT_FAQ.mspx.
  • Page 123 Format disk. Format is done. The new disk is ready to go, available size = 2.72TB. NOTE: If user setup 512B block size for UDV and the host/server OS is 32bit, in the last step of formatting disk, user will find OS cannot format the area after 2048GB (2TB).
  • Page 124 Wrong setting result: OS cannot format area after 2048GB (2TB)! System information XL-RAID-2804ISSA SW version 1.1.0 Build 20080418...
