Body
POWDER
DETERGENT BOX
MAGIC FILTER
Clean regularly to
prevent lint accumulation
on the clothes load.
SOFTENER
INLET
BLEACH
DISPENSER
FUNCTION
SELECTOR
TUB
START/PAUSE
BUTTON
Use to start or
stop the washing
machine
temporarily.
ADJUSTABLE LEGS
Use to level the washing
machine for correct
balance & spin
operation.
Accessories
Water supply hoses
For COLD water
NOTE
NOTE
"
" Parts can be different according to the model.
Please do not match this figure with model as it may be different from your model .These are schematic diagrams only.
Due to continuous improvements at LG, specification of washing machine are subject to change without prior notice.
Drain hose
Snap Ring
10
WATER SUPPLY
HOSE
Make sure the
water does not
leak.
POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
JET SPRAY NOZZLE
Depending upon the Inlet
water Pressure, performance
of Jet spray may vary.
CASTORS
Use for easy
translocation
(at rear bottom edge)
DRAIN HOSE
Keep the drain hose
flipped down while
washing is in progress.
BASE
Anti-rat cover
