Manual No.'13•SC-T-192
updated May 17 ,2013
TECHNICAL MANUAL
AIR CONDITIONING CONTROL SYSTEM
CENTRAL CONTROL
SC-SL4-AE
SC-SL4-BE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-SL4-AE and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Heavy Industries SC-SL4-AE

Summary of Contents for Mitsubishi Heavy Industries SC-SL4-AE

  • Page 1 Manual No.'13•SC-T-192 updated May 17 ,2013 TECHNICAL MANUAL AIR CONDITIONING CONTROL SYSTEM CENTRAL CONTROL SC-SL4-AE SC-SL4-BE...

  • Page 2: Table Of Contents

    SC-SL1N-E 3 ( 3) Notes (1) In case of previous SL, since SC-SL4-AE, BE is for connection of 3 Super Link systems, one unit of SC-SL2NA-E,SC-SL1N-E can be connected to each system. (2) Number of units in combination as shown above is applicable to when the indoor units being controlled by each central control are not duplicated.

  • Page 3: Specifications

    ’13 • SC-T-192 1. SPECIFICATIONS Description CENTRAL CONTROL SC-SL4-AE CENTRAL CONTROL SC-SL4-BE SC-SL4-AE SC-SL4-BE Model name Super Link compatible indoor unit Applicable model Ambient temperature at operation 0 ~ 40˚C Power supply 1 phase 100 V, 200 ~ 240 V 50/60 Hz Power consumption External dimensions (H×W×D)

  • Page 4: Operation And Setting

    ’13 • SC-T-192 2. OPERATION AND SETTING Operation and setting is implemented in group or in a batch for the maximum 8 groups (44 for previous SL). Item Description RUN/STOP Performs operation or stop control. Operation mode Sets Auto Cool, Dry, Fan or Heat.

  • Page 5: Control Selection Setting

    ’13 • SC-T-192 3. CONTROL SELECTION SETTING It is possible to change the setting as follows by setting on the “Function Setting” Item Description Time from the last operation on the touch panel until the monitor backlight turns Backlight timeout time OFF can be selected.

  • Page 6: Status Monitor

    ’13 • SC-T-192 4. STATUS MONITOR Status monitor can be applied in the unit of block, group or air-conditioner. Item Description It displays “RUN” if any units are running or displays “STOP” if all units are RUN/STOP status stopped. Operation mode Displays the operation mode of the representative air-conditioner.
  • Page 7 ’13 • SC-T-192 Item Description Sets the calculation type and capacity of air-conditioners connected to this unit. Unit definition Time and date setting Sets the clock (Hour (24-hour basis)/minute/date/month/year) used for schedule, etc. Displays a maximum of 300 cases for the history of error occurrence and restora- tion in the unit of air-conditioner.

  • Page 8: Web Monitering Function

    ’13 • SC-T-192 7. WEB MONITORING FUNCTION This web monitoring system monitors and operates air conditioner connected to central control SC-SL4-AE or SC-SL4-BE from a web browser on your PC. The following figure shows the basic system configuration. The SL4 central control connected to the air conditioner is linked directly to the monitoring and operating PC.

  • Page 9: External Dimensions

    ’13 • SC-T-192 8. EXTERNAL DIMENSIONS (1) Central control 9 inches wide color LCD touch panel 22.5 Reset switch hole (φ2) Wall surface USB port Resin : ABS Upper case setting Color of resin : Clear pearl screw (×2) Service space Front : 500mm or larger Bottom : 200mm or larger Power supply...

  • Page 10: Installation Work

    ’13 • SC-T-192 9. INSTALLATION WORK Please install the central control after turning off the power for fear of electric shock. Please arrange or protect the wiring so that excessive force is not applied to the electrical wires. Installation Place Please install in an indoor location that is not exposed to electromagnetic waves, water, dust, or other foreign substances.

  • Page 11: Electric Work

    ’13 • SC-T-192 Installation outline Installation procedure Be sure to use the attached installation   ● (1) Remove the upper case brackets. ①  Take out two screws using a ③ Wall cross slot screwdriver. (Do not Central M3 pan head screw × 4 positions control lose the screws) Upper...

  • Page 12: Other Information

    ’13 • SC-T-192 System Wiring The back of the central control Ground position “b” for Super Link system signal wire L1 L2 Ground Terminal block (two tiers) position “a” FG FG The upper tier of Terminal Block (*) Please be sure to use the accessory terminals (S). (Same for A2, B2, A3, B3) DO1 DO1- DO2 DO2- COM (*1)

  • Page 13: Accounting Calculation

    ’13 • SC-T-192 11. ACCOUNTING CALCULATION (a) Selection of watt-hour meter To calculate the account, it is necessary to procure a watt-hour meter at site. Select a meter according to the following items. (b) Selecting the pulse unit 1) Restrictions on the pulse input receiving side 100 ms Restriction on the device side or over...
  • Page 14 9 inches wide color LCD touch panel ’13 • SC-T-192 (c) Energy consumption calculation method The SL4-BE integrates operation data from each indoor unit and watt-hour meter’s pulses and exports this information to Calculating data files. A USB memory can be used to transfer the data files to a computer where proportional distribution calculations can be performed for energy used using the included software.
  • Page 15 ’13 • SC-T-192 ① In case of MULTI  setting: Conduct proportional distribution according to the results of a accumulated answer Hz. Accumulation is not performed when the thermo is OFF or during the Fan mode operation. Indoor unit A Indoor unit B Indoor unit C Hz...
  • Page 16 ’13 • SC-T-192 (d) Software overview (SL3N-BE Utility) SL3N-BE Utility calculates the amount of energy consumption with air conditioner’s running data saved by SC-SL4-BE. The amount of energy consumption is divided proportionally day by day according to the operating ratio of the air conditioner, and it is calculated as the group total amount of energy consumption for every period.
  • Page 17 Small font size 4) End user agreement This software is for using SC-SL4-BE. Mitsubishi Heavy Industries, Ltd. (MHI) permits you to use two or more copies of this software on two or more computers. This software and SC-SL4-BE do not warrant the contents of the calculation result.
  • Page 18 ’13 • SC-T-192 (e) Starting and quitting the software 1) Starting the SL3N-BE Utility ® Double-click the short-cut icon displayed on Windows desktop or select the program displayed on the Start menu. The Main Menu screen shown in Fig.5 will appear. Fig.5 Main Menu screen 2) Quitting SL3N-BE Utility Click [Exit] button, or [x] button of a title bar.
  • Page 19 ’13 • SC-T-192 3) Screen changes The screen changes are shown in Fig.6. Import Accounting Import Data File Start BIN to CSV Import Conversion Main Menu Accounting Data File screen Back Back Exit Meter Group Meter Group Definition Definition Meter Group Definition screen Back Back...
  • Page 20 ’13 • SC-T-192 6) Calculating energy consumption a) Start the SL3N-BE utility ® Double-click the short-cut icon displayed on Windows desktop or select the program displayed on the Start menu. The Main Menu screen shown in Fig.7 will appear. Step 1: Click [Import Accounting Data File] button on this screen. Step 2: Click [Meter Group Definition] button on this screen.
  • Page 21 ’13 • SC-T-192 Step 1: Import Accounting Data File (1) Beforehand, export monthly data files to a USB memory by SC-SL4-BE. (2) Insert the USB memory in your personal computer. (3) Click a check box. Select the drive name of a USB memory, and the folder name, which exported monthly data files. (4) Specify the year and the month to calculate.
  • Page 22 ’13 • SC-T-192 ◦ Importing Accounting Data Files SL3N-BE Utility reads a group definition file and the monthly data file of the month specified to the "year" and the "month", and the previous month, and converts them into the CSV files. The converted CSV files are the following.
  • Page 23 ’13 • SC-T-192 Step 2: Set the Meter Group Definition SL3N-BE Utility memorizes the Meter Group Definition last time, and reads it when starting. You may skip this menu, as long as there is no change. Meter Group Definition defines to which energy system (electricity or gas) the air conditioner belongs. It is possible to assign two or more meter numbers to one air conditioner's indoor unit.
  • Page 24 ’13 • SC-T-192 ◦First time (1) Click [New] button and input the Meter number. (2) Click [Save] button and input the file name. (3) Click [Back] button. ◦2nd hereafter You don’t have to select this menu. However, we recommend that you check the contents of the setting whenever you calculate.
  • Page 25 ’13 • SC-T-192 Step 3: Set the Pulse Constant Definition SL3N-BE Utility memorizes the Pulse Constant Definition last time, and reads it when starting. You may skip this menu, as long as there is no change. Pulse Constant Definition defines a pulse constant and the energy type (electricity) for every meter. Fig.13 Pulse Constant Definition screen [New]: Push this button when you make a new definition f ile.
  • Page 26 ’13 • SC-T-192 Step 4: Calculate Energy Consumption SL3N-BE Utility carries out proportional division calculation based on the Monthly Data Files that imported, the Meter Group Definition and the Pulse Constant Definition. And it calculates the energy consumption for every group. Fig.14 Calculate Energy Consumption screen [Calculate]: calculates the energy consumption.
  • Page 27 ’13 • SC-T-192 2) When you click the check box “The electric energy consumption”, Fig.16 dialog box will appear. If you want to change the file name, the folder name and the drive name, select another drive name and the folder, and type another file name that you want.
  • Page 28 ’13 • SC-T-192 Appendix 1. The image of the Monthly Energy Consumption file *** C:¥Program Files¥SLB3EUtility¥db¥MonthE0503. csv (02/05 - 03/14) Group No Group Name Basic Period [H] Overtime [H] Basic Period [kWh] Overtime [H] 1F ENTRANCE GATE 0.000 0.000 1F ENT. HALL STH 0.000 0.000 1F ENT. HALL NRTH 0.000 0.000 1F ENT.
  • Page 29 ’13 • SC-T-192 ® Appendix 2. Dividing and Reading out the CSV file using Microsoft Excel 1) Open a new file and move a cursor to the position where you want to locate. 2) Choose the “Import External Data” menu and the “Import Data…” menu in the menu bar.
  • Page 30 ’13 • SC-T-192 3) Select “All Files (*.*)” in the the “Files of type” and choose the CSV file which you want to read. Click the “Open” button. 4) Select the “Delimited” option button and the file format “Western European” in the “File origin” drop-down, and click [Next >] button.
  • Page 31 ’13 • SC-T-192 6) Click the head column to exclude under the “Data preview”. 7) Click the last column to exclude, pressing [Shift] key (on keyboard), under the “Data preview”. Click the "Do not import column (skip)" in the “Column data format”, and click [Finish] button. 8) Click [OK] button.

  • Page 32: Troubleshooting

    ’13 • SC-T-192 12.TROUBLESHOOTING (1) SC-SL4-AE,BE. PJZ012A099 “Each group status display” is A malfunction has occurred with the unit. The malfunctioning unit is stopped. displayed in red Contact your dealer. The shop will need the following information: “Each group status display”, “malfunction situation”, “model name of the malfunctioning unit”, “Error No.
  • Page 33 ’13 • SC-T-192 When you select “Valid” for This function can be applied to the indoor units, which are the model KXE4 or later, and to the remote the Individual Lock/Unlock on controller, which is the model RC-E1 or later. the Function Setting screen, Make sure to select “Invalid”...
  • Page 34 ’13 • SC-T-192 (2) Web function PJZ012A102 Forgot the IP address Forgot the IP address, made an incorrect setting Refer to the SL4 central control setting. Forgot the ID/password Check whether the entered address was correct. A connection error occurs Click the "Refresh" button in Internet Explorer. If this will not fix the problem, restart Internet Explorer.

  • Page 35: Connection Example

    ’13 • SC-T-192 13.CONNECTION EXAMPLE Example : Up to 128 groups, which are set optionally with the central control SC-SL4-AE, BE can be controlled on the basis of each group. Note (1) A pair of center consol SC-SL4-AE, BE may be connected on the Super Link.

  • Page 36: Id And Password

    ’13 • SC-T-192 14. ID AND PASSWORD In order to prevent unauthorized settings changes, user access levels are established. This restricts access to screens and operations depending on the level. The factory default IDs and passwords below can be changed. Building manager access level Default ID : OPERATOR Default Password : 123456 Maintenance User access level Default ID : MHI...
  • Page 37 AIR CONDITIONING CONTROL SYSTEM Air-Conditioning & Refrigeration Systems Headquarters 16-5, 2-chome, Kounan, Minato-ku, Tokyo, 108-8215, Japan Fax : (03) 6716-5926 Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. Copyright MITSUBISHI HEAVY INDUSTRIES.LTD...
