- Page 1 Manual No. ’06 . SC-T - 111 TECHNICAL MANUAL Collection data AIR CONDITIONING CONTROL SYSTEM SLA-3-ER (SC-SLA3-ER) CENTER CONSOLE SLB-3-ER (SC-SLB3-ER)
-
Page 2: Table Of Contents
CONTENTS 1. MODEL USED ALL SUPER LINK RELATED MODELS ......... 1 2. SPECIFICATIONS ................... 1 3. ACCESSORIES ....................1 4. EXTERNAL VIEW .................... 2 5. INSTALLATION ....................2 6. FUNCTIONS ....................4 7. ELECTRIC WIRING ..................9 8. SELECTING A NEW PULSE UNIT ..............10 These technical manual cover Center Consoles SLA-3-ER and SLB-3- ER. -
Page 3: Model Used All Super Link Related Models
Center Console SLA-3-ER, SLB-3-ER MODEL USED ALL SUPER LINK RELATED MODELS Name Model Remark Center Console SC-SLA3-ER If the SLA-3-ER and SLB-3-ER is buried, it SLA-3-ER SC-SLA3-ER must be installed in a separately sold box (SLA3R-BX). SLB-3-ER SPECIFICATIONS Model SLA-3-ER, SLB-3-ER Item 0 ~ 40 °C... -
Page 4: External View
4 EXTERNAL VIEW 7-inch wide color LCD touch panel Wall surface Upper case mounting screws(2 screws) Terminal block Paint color:Pearl white 5 INSTALLATION Before the installation, shut off the power supply to avoid an electric shock. Please locate or protect so that the unit will not be forced against wiring. (1) Installation place Install this unit indoors without the influence of the electromagnetic wave, or splashing such as water and dust. - Page 5 <No partition> Inner wall SLA3R-BX (Sold separately) Beam of building more than 105mm SLA3R-BX 48 17 17 48 15 2-ø35 <With partition> (Knock out) 4-ø6 Partition Center console Inner wall Space(m a(Height)(mm) b(Width)(mm) c(Depth)(mm) Example1 0.08 180 0 Example2 0.08 100 0 Example3 0.08...
-
Page 6: Functions
Electric wires M4 screws, 4 pieces (accessory of the unit) Beam of building Fix the SLA3R-BX to the Unit beam in the building Inner wall Unit Fix the unit to the SLA3R-BX with the M4 screws.(4 places) More than 105mm Wire separately the power supply wire and the signal wire for preventing malfunctions. - Page 7 (3) Setting the schedule The operation schedule can be set in group units. In one day, up to 16 schedules can be registered for operation time, run/stop, mode, operation enable, and temperature settings. Operation time settings can be set in minute units.
- Page 8 (5) Energy consumption calculation data (SLB-3-ER) SLB-3-ER outputs energy consumption calculation data using USB memory. These data can be edited using commercial spreadsheet software. Energy consumption calculation data are created for each individual month. <Calculation procedure> 1 The cumulative operating time is calculated for each air conditioner. (in minutes) 2 The total operating time (Ki) for each air conditioner, and the operating time in each time band (regular hours, irregular hours) are calculated (in minutes).
- Page 9 Different from 1, the fixed value is accumulated irrespective of the answer Hz. Accumulation is not performed when the thermo is OFF and during the Fan mode operation. Indoor unit A Indoor unit B Indoor unit C 30Hz 50Hz 70Hz Total value of operating volume (capacity equivalent Hz thermo ON time) Operating volume of indoor unit A = accumulated pulse counts power consumption per pulse 30 /150...
- Page 10 <Flow of data processing> Pulse input (Max. 8 systems) Power consumption meter The energy consumption caculated by this equipment close not with pulse signal transmitter conform to OIML. Pulse width: 100ms and above Pulse parameter: 0.01 - 300.00kWh / pulse (electrical) This unit calculates only energy consumption (gas,electric power).
-
Page 11: Electric Wiring
7 ELECTRIC WIRING For safety's sake, use the round crimping terminal with the insulation sleeve for wiring to the unit. • Perform ground wiring. Please do not connect the ground wire to the gas pipe,the water pipe, the lightning rod, and the telephone ground wire. -
Page 12: Selecting A New Pulse Unit
(b) The lower tier of terminal block Power input from gas meter or wattmeter (8 points) (in case of SLB-3-ER) Note (1) Do not connect power supply wire to another terminal block.When you connect by mistake,damage and damage by fire of the electric part are caused, and it is very dangerous. - Page 13 (b) Pulse unit selection 1 Find the total capacity of all connected air conditioners 2 Assume that the correct electricity meter is being used 3 Air conditioners operating at full load: assume summer overload power consumption 1.2 For example, Set the total electricity consumption = 100kW, power rate = 90% Operating at full load = 100 1.2 = 120kW With 3 in conjunction, 1 = 120 1000/ (1.732 200 0.9) = 385A →...
- Page 14 (c) Largest gas pulse input value 0.5m Gas amount pulse unit 0.01m 0.05m 0.1m 21,6000m 4,320m 21,600m 4,3200m Largest measurable flow volume 180m 900m 1,800m 9,000m 900/7=128 times 9000/120=75 times Largest used flow Largest used flow gas meter example 10~120m 2~7m 0.05m3/P time: If you use 2m...
- Page 15 Air-Conditioning & Refrigeration Systems Headquarters 16-5, 2-chome, Kounan, Minato-ku, Tokyo, 108-8215, Japan Fax : (03) 6716-5926 No.042(2A) R...
