- Page 1 Technical manual Version 01/10 FD-PAC Controlkit, R410A (FDC71-250V/FD-PAC)
- Page 2 Read this user manual carefully before installation and operation of this equipment. Store this manual together with the other user and technical manuals of the Airconditioning equipment! All mentioned measures and safety instructions must be strictly complied with. The outdoor unit and connected equipment does contain refrigerant R410a. Safety instructions General Information, Risks in Non-Compliance with the Safety Instructions The instructions contain basic notes to be followed during installation and operation.
- Page 3 The electric connections must always be made with suitable cables, and it must be ensured that the cables are properly secured to prevent any mechanical forces on the cables from affecting the cable connections inside the machine. A faulty cable connection can develop heat inside the machine and/or cause fires.
-
Page 4: Table Of Contents
Content 1 Descripton FD-PAC / Warranty exclusion 2 Technical specifications 3 Installation 3.1 Safety instructions 3.2 Installation FD-PAC 3.3 Lay out plate heat exchanger 3.4 Lay out heat exchanger 3.5 Lay out electrical wiring diagram 4 Troubleshooting... -
Page 5: Descripton Fd-Pac / Warranty Exclusion
1. Descripton FD-PAC / Warranty exclusion Control kit for connecting an optional heat exchanger on a FDC outdoor unit for cooling and heating (refrigerant R410A).The control kit is fully wired and contain the electronics with microprocessor for communication with the FDC outdoor unit. The selfdiagnose system provides a fast recognition of problems and provides alpha numeric codes on the remote controller. -
Page 6: Technical Specifications
2. Technical specifications Model FD-PAC / FDC71VN Model Control kit Outdoor unit Technical specifications FD-PAC FDC71VN Nominal coolingcapacity (1) 7100 (3200 ~ 8000) Nominal heating capacity (1) 8000 (3600 ~ 9000) Power source 1 fase, 220/230/240V, 50Hz, N, PE Cooling power consumption 2,01/2,01 Running current (cooling) 8,9/9,2... - Page 7 Model FD-PAC / FDC100VS Model Control kit Outdoor unit Technical specifications FD-PAC FDC100VS Nominal coolingcapacity (1) 10000 (6100 ~ 11200) Nominal heating capacity (1) 11200 (5600 ~ 12500) Power source 1 fase, 220/230/240V, 50Hz, N, PE Cooling power consumption 2,85/2,85 Running current (cooling) 12,5/13,1 Power factor (cooling)
- Page 8 Model FD-PAC / FDC125VS Model Control kit Outdoor unit Technical specifications FD-PAC FDC125VS Nominal coolingcapacity (1) 12500 (5000 ~ 14000) Nominal heating capacity (1) 14000 (4000 ~ 16000) Power source 1 fase, 220/230/240V, 50Hz, N, PE Cooling power consumption 4,10/4,10 Running current (cooling) 18,0/18,8 Power factor (cooling)
- Page 9 Model FD-PAC / FDC140VS Model Control kit Outdoor unit Technical specifications FD0-PAC FDC140VS Nominal coolingcapacity (1) 14000 (5000 ~ 14500) Nominal heating capacity (1) 16000 (4000 ~ 16500) Power source 1 fase, 220/230/240V, 50Hz, N, PE Cooling power consumption 4,98/4,98 Running current (cooling) 22,0/23,0 Power factor (cooling)
- Page 10 Model FD-PAC / FDC200VS Model Control kit Outdoor unit Technical specifications FD-PAC FDC200VS Nominal coolingcapacity (1) 20000 (7000 ~ 22400) Nominal heating capacity (1) 22400 (7600 ~ 25000) Power source 3 fase, 380/400/415V, 50Hz, N, PE Cooling power consumption 6,47/6,47 Running current (cooling) 9,7/10,1 Power factor (cooling)
- Page 11 Model FD-PAC / FDC250VS Model Control kit Outdoor unit Technical specifications FD-PAC FDC250VS Nominal coolingcapacity (1) 25000 (10000 ~ 28000) Nominal heating capacity (1) 28000 (9500 ~ 31500) Power source 3 fase, 380/400/415V, 50Hz, N, PE Cooling power consumption 9,01/9,01 Running current (cooling) 13,5/14,1 Power factor (cooling)
-
Page 12: Installation
Installation SAFETY PRECAUTIONS • Read the “SAFETY PRECAUTIONS” carefully first of all and then strictly follow it during the installation work in order to protect yourself.The precautionary items mentioned below are distinguished into two levels, WARNING and CAUTION. WARNING: Wrong installation would cause serious consequences such as injuries or death. CAUTION: Wrong installation might cause serious consequences depending on circumstances. - Page 13 • Make sure there is no dust or clogging on both the plug and the socket nor loose connection of the socket before plugging, and plug in securely to the end of the blade. Accumulation of dust, clogging on the socket or plug, or loose installation of the socket could cause electric shock and fire.
-
Page 14: Installation Fd-Pac
Installation FD-PAC All the required components for the FD-PAC in accordance with this delivery will be connected to the terminal on the FD-PAC. The control kit can be switched on/off via an external 230V AC signal. Due to the invertercontrol of the outdoor unit it is recommended to control an external fan via the connections of the FD-PAC. -
Page 15: Lay Out Plate Heat Exchanger
3.3 Lay out plate heat exchanger... -
Page 16: Lay Out Heat Exchanger
Lay out heat exchanger... -
Page 17: Lay Out Electrical Wiring Diagram
Lay out wiring diagram... -
Page 18: Troubleshooting
Troubleshooting...
