Page 1: Installation Guide
SY-MSUHD-88 Installation Guide SY-MSUHD-88 18GPS 8x8 HDMI 4K Switcher SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom Tel: +44 (0) 161 868 3450 – Fax: +44 (0) 161 868 3459 – www.sy.co.uk... -
Page 2: Panel Descriptions
SY-MSUHD-88 The MSUHD-88 is an 8X8 true 4k HDMI matrix switcher that is capable is switching HDMI signals up to 18GBPS. HDMI2.0, HDCP2.2 and video resolutions up to 4K are all fully supported. It allows any source (BluRay player, HD DVD player, satellite receiver, game station, etc.) to be shown on the any of the displays simultaneously, no matter whether the source is HDCP compliant or not. -
Page 3: Installation
Operation Video Selections The SY-MSUHD-88 front panel controls allow for the selection of the inputs to the various outputs. First press the a button on the OUTPUT row to choose the output number to change, then press a button on the INPUT row to select the input signal for the selected output. - Page 4 SY-MSUHD-88 The factory default EDID is 1080p 2CH (PCM). The EDID setting can be set to any one of the following: 1：1080P 2CH (PCM) 2：1080P 6CH 3：1080P 8CH 4：1080P 3D 2CH (PCM) 5：1080P 3D 6CH 6：1080P 3D 8CH 7：4K30Hz 3D 2CH (PCM) 8：4K30Hz 3D 6CH...
- Page 5 SY-MSUHD-88 EDID setting to the HDMI source device, therefore only one EDID setting is active at any instant, but this setting can be different for each input. The following is an example of how to change the EDID setting for input 3:...
- Page 6 The left arrow button selects the next lowest numbered input port, and the right arrow selects the next highest numbered input port. The IR remote control for the SY-MSUHD-88 allows the user to increase or decrease all eight of the inputs source selections simultaneously with a single button press.
-
Page 7: System Information
SY-MSUHD-88 RS232 Commands The SY-MSUHD-88 switcher can also be controlled using RS232 commands. The following table lists all the available commands that can be used to control or configure the SY-MSUHD-88 switcher. The baud rate settings are: 57600, 8 data bits, no parity, 1 stop bit and no handshaking. -
Page 8: Edid Settings
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 67 Ideally, the above example would be placed into a text file and then sent to the SY-MSUHD-88 switcher using a serial emulation program. The data given above is only an example and may not be compatible with the display devices connected to the SY-MSUHD-88 switcher. -
Page 9: Network Settings
Get the router IP address Get the TCP/IP value GET TIP GET MAC Get the MAC address When shipped from SY the default IP settings are: DHCP = Off Host IP Address = 192.168.1.239 Subnet Mask = 255.255.255.0 Router IP Address = 192.168.1.1 TCP/IP Port = 23 www.sy.co.uk... -
Page 10: Safety Instructions
Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product 5. Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. www.sy.co.uk... - Page 11 SY-MSUHD-88 NOTES: www.sy.co.uk...
- Page 12 SY-MSUHD-88 NOTES: www.sy.co.uk...
