Page 1: Installation Guide
HDBaseT PoC Outputs 4 HDMI in to 4 HDBaseT + 2 mirrored HDMI out SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom Tel: +44 (0) 161 868 3450 – Fax: +44 (0) 161 868 3459 –... -
Page 2: Connectors And Controls
SY-MHDBT-44P The SY-MHDBT-44P is a HDMI matrix switcher with four HDMI inputs and four HDBaseT outputs, of which outputs one and two also have mirrored HDMI outputs. This 1U rack-mountable 4 x 4 matrix switcher provides a very powerful and tidy matrix solution, with built-in HDBaseT transmitters which can directly power up to 4 remote SY-HDBT-70P-R receivers. -
Page 3: Using The Front Panel Controls
Connect the input HDMI sources to the matrix HDMI INPUTS - connect the HDBaseT extenders to the connectors in the OUPTUT group. Connect the power supply provided with the SY-MHDBT-44P. To ensure safety and as a good practice, be sure to connect an earth bonding strap to the earthing point on the rear of the SY-MHDBT-44P unit to a good local earthing point. -
Page 4: Rs232 Control Commands
SY-MHDBT-44P Using IR Remote Controls Point the IR remote control key pad at the SY-MHDBT-44P and use the key pad buttons in the same sequence as for using the front panel controls. RS232 Control Commands The following RS232 commands provide control of the SY-MHDBT-44P from a PC, laptop or programmable control panel. - Page 5 HDCP Management %0801. Set HDCP Management to automatic %0800. Set HDCP Management to manual Send data from PC to SY-HDBT-70P-R or SY-HDBT-100-R via /+x/y:******. output x at baud rate y See below for more details %9971. Check the connection status of the inputs %9972.
-
Page 6: Specifications
The EDID upgrade command requires careful consideration because there is a ten second time out period within which the new EDID binary image must be sent to the SY-MHDBT-44P. If no data arrives within that ten second window, then the command is automatically aborted. - Page 7 SY-MHDBT-44P Figure 1 – SY-MHDBT-44P Connection Diagram www.sy.co.uk...
-
Page 8: Safety Instructions
Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product 5. Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. www.sy.co.uk...
