Page 1: Installation Guide
SY-HD-S41 Installation Guide HDMI 4x1 Switcher SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom Tel: +44 (0) 161 868 3450 – Fax: +44 (0) 161 868 3459 – www.sy.co.uk... - Page 2 SY-HD-S41 The SY-HD-S41 is a four-input, single-output HDMI video switcher with both a manual and an auto selection mode. This switcher is useful for switching up to four HDMI sources to a single display device. The switcher can be controlled manually from the front panel or from the included IR remote controller or through the RS232 interface.
-
Page 3: Manual Selection Mode
HDMI input of the SY-HD-S41. Connect a HDMI cable from the HDMI output of the SY-HD-S41 to the HDMI display device. Whenever the SY-HD-S41 is powered up, it will restart in the last state it had before being switched off. -
Page 4: Rs232 Control Commands
SY-HD-S41 RS232 Control Commands The following RS232 commands provide control of the SY-HD-S41 from a PC, laptop or programmable control panel. The RS232 settings are: 9600 baud, 8 bits, no parity, and 1 stop bit. Action Command Response 1B1. AV: 1 -> 1 Select input 1 2B1. - Page 5 SY-HD-S41 Figure 1 – SY-HD-S41 Connection Diagram www.sy.co.uk...
-
Page 6: Specifications
SY-HD-S41 Specifications General HDMI Resolutions 480i, 480p, 720i, 720p, 1080i, 1080p, 1920 x 1200 HDMI Standard HDMI 1.4a – Supports 3D Power Supply 5V DC Power Consumption 1.4 W max RS232 9600, 8 data bits, 1 stop bit, no parity – No handshaking... - Page 7 Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product 5. Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. www.sy.co.uk...
