INTRODUCTION

The I-Command gauge series uses CANBus technology, allowing the shar-
ing of information between different electronic devices which are connected
to an electrical network.
CANBus is a Controller Area Network ("CAN") pathway ("Bus"), allowing
multiple components to communicate with each other via a central network.
®
The CANBus collects and manages information from the Evinrude
™
E-TEC
outboard through a central processing unit within the tachometer
and then sends that information to the other instrument displays.
The CANBus is also connected to the boat's larger electronics network—the
†
NMEA 2000 Network—which allows it to communicate with other boat
instruments, displays, and engine and accessory functions beyond the
scope of the engine instruments. This information is displayed on I-Com-
mand tachometer and speedometer LCD screens.
The I-Command gauge series provides the benefit of sharing more informa-
tion. Additionally, the wiring system is reduced and simplified, resulting in a
reduction of weight and complexity.

Types of Gauges

The I-Command gauge series is designed to enhance the engine monitoring
capabilities of the boater. Each gauge has a different monitoring function.
Required gauge:
• Tachometer
IMPORTANT: The tachometer is the master gauge. If it is removed or dis-
connected, all I-Command gauges will stop operating.
Optional gauges:
• Speedometer
• Fuel level
• Oil level
• Water pressure
• Engine trim position
• Voltmeter
