Engine Position

IMPORTANT: In multiple engine installations, there is data on the I-Com-
mand network for each engine. Each tachometer needs to be set to corre-
spond to the appropriate engine.
Setting an engine position — From the System Set-Up screen, scroll to
the Set-Up Engine Position display. Press ENTER. "SET" appears in the
upper right corner of the LCD screen. Using the UP / DOWN buttons, select
the engine position.
For dual outboards — port = 0, starboard =1
For triple outboards — port = 0, center = 1, starboard = 2
Press ENTER to set the display.
NOTE: If only one outboard is installed, the engine position must be set to
port (0).

Display Units

Data can be displayed in English or Metric, depending on user preference.
Setting display units — From the System Set-Up screen, scroll to the
Set-Up Units screen. Press ENTER. "SET" appears in the upper right corner
of the LCD screen. Using the UP / DOWN buttons, select English or Metric.
Press ENTER to set the display.
MEASUREMENT
Barometric
Pressure
Water Pressure
Fuel
Temperature
Water Depth
DISPLAY UNITS TABLE
ENGLISH
in. Hg
(inches of mercury)
PSI (per square inch)
g (U.S. gallons)
°F (Fahrenheit)
ft. (feet)
METRIC
kPa (kilopascals)
kPa (kilopascals)
l (liters)
°C (Celsius)
mtrs (meters)
9
