SPLIT SCREENS

A split screen allows the operator to view two separate
data displays at the same time on one LCD screen.
Viewing split screen data — From the Main Menu of
either gauge, press the DOWN button until the Split
Screen menu appears. Press ENTER. The bar at the
top of the split screen appears in reverse color. The
display can now be customized to output any data
combination desired. The UP button will scroll the
available data displays on the left side of the screen.
The DOWN button will scroll the available data dis-
plays on the right side of the screen. Once the desired
displays appear, press ENTER to set the combination.
Tachometer data displays available in split screen
mode:
• Barometric Pressure
• Engine Temperature
• Fuel Consumption Rate
• Oil Tank Level
Speedometer data displays available in split screen mode:
• Depth
• Estimated Fuel Left
• Fuel Consumption Rate
• Fuel Economy
26
• RPM
• Engine Trim
• Battery Voltage
• Water Pressure
• Fuel Level (Tank 1 or 2)
• Speed (SOG or SOW)
• Water Temperature
Tachometer Speedometer
