Telescope Features
EclipseView 60
FIGURE 1A
9 8 7
22
24
5
4
3
2
1
Always use the EclipseView Solar Filter when viewing at or near the Sun or irreversible eye damage may occur.
Image A
18
6 11
10
1. Tripod leg lock
15
2. Leg brace supports
3. Accessory tray
4. Alt-Az mount
5. Azimuth lock knob
23
6. Altitude lock knobs
7. Optical tube assembly
(OTA)
17
16
8. Objective lens
9. Solar Filter
*Required for viewing the
Sun.
10. SunFinder
11. Finder mounting knobs
12. Red-dot finder
13. Red-dot finder On/Off
1
switch
14. Red-dot finder adjust-
ments
15. Eyepiece
19 21
8
5
20
16. Focuser
17. Focus knobs
18. Focuser thumbscrews
19. Slow-motion control rod
20. Slow-motion lock knob
21. OTA mounting knobs(2)
22. Front dust cap (not visible)
23. Erect-image prism
24. Dew shield
Image B
12
14 13
Image C
10
Image D
9
7
6
