4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need to
manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such situations.
In addition, the chart on the last page of this manual has a section for the particular features and
options installed in your vehicle as well as the override method selected. Valet Switch manual
override is pre-selected from the factory, however, the system can be configured for "Custom
Code" operation. Confirm the override mode selected on the last page of this manual and
familiarize yourself with the selection on it's operation.
FEATURES :
2 Four Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Four Channel Receiver
Anti Code Grabbing Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override Code
7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Starter Disable (Optional relay required)
Additional Engine Immobilizer Output (optional relay required)
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds /1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi-Tone Siren
RF Inhibit with ignition on
Parking Light Flasher
Plug In Dual Stage Shock Sensor
OPTIONS :
Starter Disable
Remote Trunk Release (must have electronic trunk release)
Remote Keyless Entry (must have power door locks)
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Two Step Unlock Configurable
Model APS-410
Owner's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox Prestige Platinum APS-410
Summary of Contents for Audiovox Prestige Platinum APS-410
- Page 1 Starter Disable Remote Trunk Release (must have electronic trunk release) Remote Keyless Entry (must have power door locks) Multiple Vehicle Capable Remote Starter Remote Power Window Roll Up Remote Garage Door Interface Two Step Unlock Configurable Model APS-410 Owner’s Manual...
-
Page 2: Arming The System - Active
YOUR “ANTI CODE GRABBING” TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re transmit at a later time to disarm your system. -
Page 3: Protection While The System Is Armed
Red dash mounted LED begins to flash rapidly, indicating 30 second passive arming has begun. 2. Opening any protected entry point during the 30 second passive arming cycle will immediately suspend automatic arming, and the 30 second passive arming cycle will restart when all doors are closed. At the end of the passive arming cycle;... -
Page 4: Silent Disarming
LED will start flashing rapidly, indicating that the system is re- arming automatically. Open any door to suspend the auto- matic arming. Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. -
Page 5: While The System Is Sounding
pressing the unlock button a second time will cause all doors to unlock. If your transmitter has a separate lock/unlock buttons, pre ssing the unlock button anytime after the first unlock command will cause all the vehicle doors to unlock. WHILE THE SYSTEM IS SOUNDING If during a triggered state, you wish to shut off the siren without disarming your security system, simply press and release any transmitter button other than the... - Page 6 NOTE: Always remember to return the system to the NON VALET mode, after servicing, to ensure that the vehicle remains protected at all times. MANUALLY OVERRIDING YOUR SYSTEM: USING THE VALET SWITCH MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmit- ter.
- Page 7 previously stored code, the new code was not entered correctly. Please repeat steps 1 through 7 above considering the following. NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero) or no digit entered in any place, units or tenths. NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5 seconds during any of the above steps, the unit will revert back to the last successfully stored code.
-
Page 8: Eliminating The Normal Arm / Disarm Chirps
Note: The siren will sound. 2) Within 5 seconds, press and release the pushbutton switch 1 time. 3) Within 5 seconds, turn the ignition switch off then on. 4) Within 5 seconds, press and release the pushbutton switch 1 time. 5) Turn the ignition switch off then on and start the vehicle. -
Page 9: Additional Remote Function ( Channel 3 )
While in the panic mode, anytime the DISARM button is pressed, the panic feature will continue for the allotted 30 seconds, however, the security system will be disarmed allowing the vehicle to start. ADDITIONAL REMOTE FUNCTION ( CHANNEL 3 ) This security system has an additional features that can be connected to a number of different optional accessories. - Page 10 Auto Unlock with ignition key Passive Arming No Lock in passive mode Hardwire doors, hood, and trunk Custom Code Override Valet Switch Override © 2001 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 APS 410 PASSIVE ARMING ARMED DISARMED VALET MODE...
