Table 2.6: 32-bit DIO Connector Pin Assignment
29 GND
31 DO3
33 DO7
35 DO11
37 DO15
2.1.5

VGA+DVI Connector

AIIS-3400/3410 offers an integrated D-sub 24-pin female DVI-D Digital Visual Inter-
face connector and a D-sub 15-pin VGA; DVI-D carries digital video signal. This sup-
ports high-speed, high-resolution digital displays and traditional analog displays.
Table 2.7: VGA Connector Pin Assignment
Pin
1
3
5
7
9
11
13
15
AIIS-3400/3410
Table 2.8: DVI Connector Pin Assignment
Pin
1
3
5
7
9
11
13
15
30
32
34
36
Figure 2.8 Figure 2.7 VGA Connector
Signal
RED
BLUE
GND
GND
VCC
N/C
H-SYNC
SCK
Figure 2.9 DVI Connector
Signal
TMDS Data 2-
GND
N/C
DDC data
TMDS Data 1-
GND
N/C
GND
11
DO1
DO5
DO9
DO13
Pin Signal
2 GREEN
4 N/C
6 GND
8 GND
10 GND
12 SDT
14 V-SYNC
Pin Signal
2 TMDS Data 2+
4 N/C
6 DDC clock
8 N/C
10 TMDS Data 1+
12 N/C
14 +5 V
16 Hot plug detect
