  • Page 1 User Manual AIIS-3400/3410 Machine Vision System (Computer)
  • Page 2 The documentation and the software included with this product are copyright © 2016 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Safety Instructions

    RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan- tech disclaims all responsibility for the accuracy of any statements contained herein. AIIS-3400/3410 User Manual...
  • Page 6 VGA+DVI-D 4 8-CH AIIS-3400U-00A1E 4-CH USB 3.0 VGA+DVI-D 4 8-CH For AIIS-3410 Camera COM 232/ Part Number Display USB 3.0 Isolated DIO Interface 422/485 AIIS-3410P-00A1E 4-CH GigE PoE VGA+DVI-D 4 8-CH AIIS-3410U-00A1E 4-CH USB 3.0 VGA+DVI-D 4 8-CH AIIS-3400/3410 User Manual...
  • Page 7 8-CH DIO DB-25 Wiring Terminal, DIN-rail Mount AIIS-DIO32-00A1E Isolated DIO module, 32-CH, 9-pin USB interface AIIS-E730-AE Isolated DIO module, 32-CH, MIO with PCIex1 interface PCL-10137-1E 32-CH DIO Cable 1M for Wiring Terminal ADAM-3937-BE 32-CH DIO DB-37 Wiring Terminal, DIN-rail Mount PCI riser card AIIS-3400/3410 User Manual...
  • Page 8 AIIS-3400/3410 User Manual viii...

  • Page 9: Table Of Contents

    (JOBS1+JWDT1)............5 Chapter Hardware Installation ......7 Front Panel Controls, Indicators & Connectors......... 8 Figure 2.1 AIIS-3400 Front View ..........8 Figure 2.2 AIIS-3410 Front View ..........8 2.1.1 Power On/Off Button..............8 Figure 2.3 Power On/Off Button ..........8 Table 2.1: Power Button Connector Pin Assignment ....8 2.1.2...
  • Page 10 HDD Installation ..................17 Figure 2.16HDD Installation ............17 Internal USB Lock Installation..............18 CFast Installation ..................18 Figure 2.17CFast Installation (AIIS-3400 only)......18 AIIS-DIO32 Installation ................19 Figure 2.18AIIS-DIO32 Installation..........19 Wallmount Installation................20 Figure 2.19Wallmount Installation ..........20 2.10...
  • Page 11 Overview ....................72 Isolated Digital I/O Connections.............. 72 C.2.1 Dry/Wet Contact Support for Digital Input........72 Figure C.1 Isolated Digital Input Connections ......72 C.2.2 Isolated Digital Output Connections..........72 Figure C.2 Isolated Digital Output Connections ......73 AIIS-3400/3410 User Manual...
  • Page 12 Appendix D Exploded Diagram & Parts List ..75 Exploded Diagram .................. 76 Figure D.1 Exploded Diagram............ 76 Table D.1: Parts List ..............77 AIIS-3400/3410 User Manual...

  • Page 13: Chapter 1 General Introduction

    Chapter General Introduction This chapter gives background information on the AIIS-3400/3410 series.

  • Page 14: Introduction

    Compliant with USB 3.0 SuperSpeed, it is capable of transferring data up to 5 Gbps, whereas USB 2.0 can only provide up to 480 Mbps. AIIS-3400/3410 utilizes a single RJ45 cable that carries both data and electrical power. Compliant with IEEE 802.3af, it can provide a maximum of 15 watts of power to each powered device up to a distance of 100 meters, whereas USB 2.0 can only...

  • Page 15: Product Specifications

    Internal 2.5” HDD Bay: 1  CFast: 1 1.3.7 Front I/O  Display: 1 x VGA; 1 x DVI-D  USB: 4 x USB3.0  Serial: 2 x RS-232/422/485  Isolated DIO: 4 DI and 4 DO channels  Audio: Line-in/Line-out/Mic-in AIIS-3400/3410 User Manual...

  • Page 16: Watchdog Timer

    Power adapter: AC to DC, 24Vdc/9.16A, 220W, FSP220-AAAN2 (optional) 1.3.10 Cooling  System Fan: – 1 (8 cm / 57 CFM) for AIIS-3410 – 1 (6 cm / 27.7 CFM) for AIIS-3400 1.3.11 Miscellaneous  LED Indicators: Power, HDD, temperature  Control: Power on/off switch 1.3.12 Environment ...

  • Page 17: Jumper Settings

    Hardware Monitor Alarm (JOBS1) and Watchdog Timer Output (JWDT1) AIIS-3400/3410 contains a watchdog timer that will reset the CPU in the event the CPU stops processing. This feature means AIIS-3400/3410 will recover from a soft- ware failure or an EMI problem. The JWDT1 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped.
  • Page 18 AIIS-3400/3410 User Manual...

  • Page 19: Chapter 2 Hardware Installation

    Chapter Hardware Installation This chapter introduces external IO and the installation of AIIS-3400/3410 Hardware.

  • Page 20: Front Panel Controls, Indicators & Connectors

    2.1.1 Power On/Off Button AIIS-3400/3410 has a Power On/Off button with LED indicators on the front side that show On status (green LED) and Off/Suspend status (orange LED). The Power but- ton supports dual functions: Soft Power -On/Off (Instant off or Delay 4 Seconds then off), and Suspend.

  • Page 21: Led Indicators

    LED color Function Connected Powered Device 2.1.3 Power Input Connector AIIS-3400/3410 comes with a four-pin header that carries 19Vdc - 24Vdc external power input. Figure 2.5 Power Input Connector Table 2.4: Power Input Connector Pin Assignments Signal 19Vdc - 24 Vdc...

  • Page 22: Digital I/O

    2.1.4 Digital I/O AIIS-3400/3410 provides one DSUB-15 male connector which offers 4-ch digital input and a 4-ch digital output with 2.5KV isolation. AIIS-3400/3410 provides addi- tional DSUB-male connector which offers 4-ch digital input and 4-ch digital output with 2.5KV isolation.

  • Page 23: Vga+Dvi Connector

    DO15 2.1.5 VGA+DVI Connector AIIS-3400/3410 offers an integrated D-sub 24-pin female DVI-D Digital Visual Inter- face connector and a D-sub 15-pin VGA; DVI-D carries digital video signal. This sup- ports high-speed, high-resolution digital displays and traditional analog displays. Figure 2.8 Figure 2.7 VGA Connector Table 2.7: VGA Connector Pin Assignment...

  • Page 24: Com Connectors

    TMDS clock + TMDS clock - 2.1.6 COM Connectors AIIS-3400/3410 provides 2 D-sub 9-pin connectors that are serial communication interface ports. COM-1 & COM-2 support RS-232/422/485 mode by BIOS selection. Figure 2.10 COM Connectors Table 2.9: Front 2-COM Pin Assignment...

  • Page 25: Ethernet Connectors (Lans)

    2.1.7 Ethernet Connectors (LANs) AIIS-3400/3410 provides six RJ45 connectors for Gigabit LAN interfaces; two of them are equipped with Intel® i219LM, i210AT Ethernet controllers, four of them are equipped with Intel® i210 Ethernet controllers that are fully compliant with IEEE 802.3af Power over Ethernet standard.

  • Page 26: Remote Power Switch Connector

    Line Out Pink Mic In 2.1.10 Remote Power Switch Connector AIIS-3400/3410 includes a 2-pin Phoenix DC power connector that provides for remote power control. CPU Installation Remove top cover. Pull the handle beside the processor socket outward and lift it.

  • Page 27: Cpu Cooler Installation

    CPU Cooler Installation Remove top cover. Attach the CPU cooler on the motherboard. Fasten four screws on the cooler into the steel back-plate on the PCB. Reinstall top cover. Figure 2.14 CPU & CPU Cooler Installation AIIS-3400/3410 User Manual...

  • Page 28: Memory Installation

    Memory Installation Remove top cover. Insert the memory module into the SODIMM socket. Reinstall top cover. Figure 2.15 Memory Installation AIIS-3400/3410 User Manual...

  • Page 29: Hdd Installation

    Install the 2.5” SATA HDD with the 4 HDD mounting screws. Make sure the PCB side of the HDD will be facing the bottom cover. Connect the SATA signal cable and power cable to the HDD. Reinstall the HDD bracket and top cover. Figure 2.16 HDD Installation AIIS-3400/3410 User Manual...

  • Page 30: Internal Usb Lock Installation

    Install the USB dongle and adjust the position of the lock-kit properly. Reinstall the USB lock-kit and top cover. CFast Installation Remove top cover. Insert the CFast card into socket. Assemble the CFast clamp to assure firm installation. Reinstall top cover. Figure 2.17 CFast Installation (AIIS-3400 only) AIIS-3400/3410 User Manual...

  • Page 31: Aiis-Dio32 Installation

    AIIS-DIO32 Installation Remove top cover. Install the AIIS-DIO32 with 2 stand-offs and 2 screws. Connect main board USB12 connector with AIIS-DIO32 USB1 connector via DIO cable. Reinstall top cover. Figure 2.18 AIIS-DIO32 Installation AIIS-3400/3410 User Manual...

  • Page 32: Wallmount Installation

    1. This pair of wallmount brackets is designed for use on the side of the chassis or the bottom. Reverse installation is not permitted. 2. Screw holes that are not used for wallmount brackets should be kept filled with screws. AIIS-3400/3410 User Manual...

  • Page 33: Din-Rail Installation (Aiis-3400 Only)

    2.10 DIN-rail Installation (AIIS-3400 only) Figure 2.20 DIN-rail Installation Note! 1. This DIN-rail bracket is designed for use on the rear side or the bot- tom. Reverse installation is not permitted. 2. Screw holes that are not used for DIN-rail brackets should be kept filled with screws.

  • Page 34: Dio Installation

    2.11 DIO Installation Figure 2.21 DIO Installation AIIS-3400/3410 User Manual...

  • Page 35: Ami Bios Setup

    Chapter AMI BIOS Setup...

  • Page 36: Introduction

    The Setup Utility uses a number of menus for making changes and turning specific features on or off. This chapter describes the basic navigation of the AIIS-3400/3410 setup screens. Figure 3.1 Main setup screen AMI’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 37: Entering Bios Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from the AIIS-3400/3410 setup screen to enter the Advanced BIOS setup screen. You can select any of the items in the left frame of the screen, such as CPU configuration, to go to the sub menu for that item.
  • Page 38 <Arrow> keys. All Advanced BIOS Setup options are described in this section. The Advanced BIOS Setup screens are shown below. The sub menus are described on the following pages. Figure 3.3 Advanced BIOS features setup screen 3.2.2.1 Trusted Computing Figure 3.4 TPM Settings AIIS-3400/3410 User Manual...
  • Page 39  TPM Support Enable or Disable TPM Support. You can purchase Advantech LPC TPM mod- ule to enable TPM function. P/N: PCA-TPM-00A1E. 3.2.2.2 ACPI Settings Figure 3.5 ACPI Settings  Enable Hibernation Enable or Disable Hibernation (OS/S4 Sleep State). This option may not be applied in some OSs.
  • Page 40 3.2.2.3 PCH-FW Configuration Figure 3.6 PCH-FW Configuration  PCH-FW Version ® PCH-FW page shows Intel ME FW information. AIIS-3400/3410 User Manual...
  • Page 41 3.2.2.4 SMART Settings Figure 3.7 SMART Settings  SMART Self Test Enable or Disable SMART Self Test on all HDDs during POST. AIIS-3400/3410 User Manual...
  • Page 42 3.2.2.5 Super IO Configuration Figure 3.8 Super IO Configuration Figure 3.9 Serial Port 1 Configuration AIIS-3400/3410 User Manual...
  • Page 43  Parallel Port Enable or Disable Parallel Port. – Change Settings To select an optimal setting for parallel port. – Device Mode Parallel port could be selected as "ECP and EPP 1.9 Mode" and other set- tings. AIIS-3400/3410 User Manual...
  • Page 44 CPUFAN Smartfan Setting Enable or Disable CPUFAN Mode to SMART FAN setting.  SYSFAN1 Smartfan Setting Enable or Disable SYSFAN Mode to SMART FAN setting.  SYSFAN2 Smartfan Setting Enable or Disable SYSFAN Mode to SMART FAN setting. AIIS-3400/3410 User Manual...
  • Page 45 3.2.2.7 S5 RTC Wake Settings Figure 3.11 S5 RTC Wake Settings  Wake System at Fixed Time To Enable or Disable System wake at set time event. The system will wake at the hr:min:sec as specified. AIIS-3400/3410 User Manual...
  • Page 46 Figure 3.12 Serial Port Console Redirection  COM1 – Console Redirection Settings Console Redirection Enable or Disable.  Serial Port for Out-of-Band Management/ Windows Emergency Manage- ment services (EMS) – Console Redirection Console Redirection Enable or Disable. AIIS-3400/3410 User Manual...
  • Page 47 CPU AES Enable or Disable CPA advanced encryption standard instruction.  Boot Performance Select the performance state that the BIOS will set before OS handoff.  Intel® Speedstep™ Allows more than two frequency ranges to be supported. AIIS-3400/3410 User Manual...
  • Page 48 Figure 3.14 Platform Misc Configuration  Platform Misc Configuration – Native PCIE Enable PCI Express Native Support Enable/Disable. This is only available in Vista. – Native ASPM On enable, Vista will control the ASPM support for the device. AIIS-3400/3410 User Manual...
  • Page 49 3.2.2.11 SATA Configuration Figure 3.15 SATA Configuration  SATA Controller(s) Enable or Disable SATA Controller.  SATA Mode Selection Select AHCI mode. AIIS-3400/3410 User Manual...
  • Page 50 3.2.2.12 PCI Subsystem Settings Figure 3.16 PCI Subsystem Settings  PCI Common Settings PCI Latency Timer Value to be programed into PCI Latency Timer Register. VGA Palette Snoop Enable or Disable VGA palette registers snooping. AIIS-3400/3410 User Manual...
  • Page 51 Controls the execution of UEFI and Legacy Storage OpROM. – Video Controls the execution of UEFI and Legacy Video OpROM. – Other PCI devices Determines OpROM execution policy for devices other than Network, Stor- age or Video. AIIS-3400/3410 User Manual...
  • Page 52 Hub descriptor.  Mass Storage Devices Mass storage device emulation type. "Auto" enumerates device according to their media format. Optical drives are emulated as 'CDROM', drives with no media will be emulated according to a drive type. AIIS-3400/3410 User Manual...

  • Page 53: Chipset

    3.2.3 Chipset Figure 3.19 Chipset This page provides information on the AIIS-3400/3410 chipset. AIIS-3400/3410 User Manual...
  • Page 54 Serial IRQ Mode Configure Serial IRQ Mode.  High Precision timer Enable or Disable the high precision event timer.  Restore AC Power Loss Power off or Power on or Last State to restore AC Power Loss. AIIS-3400/3410 User Manual...
  • Page 55 3.2.3.2 PCI Express Configuration Figure 3.21 PCI Express Configuration  PCI Express Root Port 1~20 status Enable or Disable PCI Express Root Ports. AIIS-3400/3410 User Manual...
  • Page 56  USB Precondition Pre-condition work on USB host controller and root ports for faster enumeration.  XHCI Disable Compliance mode Options to disable compliance mode. Default is FALSE, enable compliance mode. Set TRUE to disable compliance mode. AIIS-3400/3410 User Manual...
  • Page 57 Figure 3.23 HD Audio Configuration  HD Audio Control detection of the HD-Audio device. Disable = Azalia will be unconditionally disabled. Enable = Azalia will be unconditionally enabled. Auto = Azalia will be enabled if present, disabled otherwise. AIIS-3400/3410 User Manual...
  • Page 58 3.2.3.5 System Agent (SA) Configuration Figure 3.24 System Agent (SA) Configuration  VT-d Enable or Disable VT-d function.  Graphics Configuration Figure 3.25 Graphics Configuration AIIS-3400/3410 User Manual...
  • Page 59 Enable Root Port Enable or disable the root port.  Max Link speed Configure PEG 0:1:0 max speed.  Detect Non-compliance device Detect Non-Compliance PCI express Device in PEG.  Maximum Memory Frequency Maximum memory frequency selections in Mhz. AIIS-3400/3410 User Manual...

  • Page 60: Security

    Security Figure 3.26 Security Select Security Setup from the AIIS-3400/3410 Setup main BIOS setup menu. All Security Setup options, such as password protection is described in this sec- tion. To access the sub menu for the following items, select the item and press <Enter>.

  • Page 61: Boot

     Boot Option #1/2 Sets the boot order.  New Boot Option Policy Controls the placement of newly detected UEFI boot options.  Floppy Drive BBS Priorities Set the order of the legacy devices on this group. AIIS-3400/3410 User Manual...

  • Page 62: Save & Exit

    Select Exit Discarding Changes from the Exit menu and press <Enter>. The following message appears: Quit without saving? [Yes] [No] Select Yes to discard changes and exit.  Discard Changes Select Discard Changes from the Exit menu and press <Enter>. AIIS-3400/3410 User Manual...

  • Page 63: Chapter 4 Software Installation

    Chapter Software Installation This chapter introduces driver installation.

  • Page 64: Chipset Software Installation Utility

    4.1.1 Before you begin To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the AIIS-3400/3410 are located on the software installation CD. Note! The files on the software installation CD are compressed. Do not attempt to install the drivers by copying the files manually.

  • Page 65: Windows 10 / Windows 8.1/ Windows 7

    3D support deliv- ers an intensive and realistic visual experience. Caution! Intel® Graphic Device does not support Windows 10 (32bit) and Win- dows 8.1 (32.bit) AIIS-3400/3410 User Manual...

  • Page 66: Windows 10 /Windows 8.1 /Windows 7 Driver Setup

    Insert the driver CD into your system’s CD-ROM drive. Navigate to the "04_Intel ME" folder and find folder "Intel ME" to install the driver. Note! If the Intel® Management Engine (Intel® ME) driver has not been suc- cessfully installed in Win7, please refer to the Win7 ME install process below. AIIS-3400/3410 User Manual...

  • Page 67: Install Intel® Me For Windows 7

    LAN Configuration 4.4.1 Introduction The AIIS-3400/3410 has dual Gigabit Ethernet LANs via dedicated PCI Express x1 lanes (Intel® I219LM (LAN1) and I210IT (LAN2)) that offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ethernet at 1000 Mbps.

  • Page 68: Installation

    In the following sections, refer to the one that provides the driver setup procedure for the operating system you are using. 4.4.4 Windows 10 /Windows 8.1 /Windows 7 Insert the driver CD into your system's CD-ROM drive. Select folder "03_LAN" then click the "Disk" folder, and then click "Autorun". AIIS-3400/3410 User Manual...

  • Page 69: Sata Raid Setup

    SATA RAID Driver and Utility Setup The installation utility is in the CD’s “06_Intel RAID_AHCI” folder. Go to the directory of the CD and follow these steps to install. Note! Please install “.NET 4.5” before installing “Intel Rapid Storage Technol- ogy”. AIIS-3400/3410 User Manual...

  • Page 70: Install Usb3.0

    Install USB3.0 4.6.1 Introduction AIIS-3400/3410 provides 8x USB 3.0 and the data transfer rate of USB3.0 (5Gb/s) is 10 times to USB2.0 (480 Mbps). Insert the driver CD into your system’s CD-ROM drive. Navigate to "09_AIIS- 3400USB_USB3.0" to install the drier.

  • Page 71: Appendix A Programming The Watchdog Timer

    Appendix Programming the Watchdog Timer...

  • Page 72: Watchdog Timer Overview

    The AIIS-3400/3410’s watchdog timer can be used to monitor system software oper- ation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it.
  • Page 73 Unlock NCT6776D Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock NCT6776D AIIS-3400/3410 User Manual...

  • Page 74: Example Programs

    Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set second as counting unit AIIS-3400/3410 User Manual...
  • Page 75 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h Out dx, al Inc dx In al,dx Or al, 08h Out dx,al ;----------------------------------------------------------- AIIS-3400/3410 User Manual...
  • Page 76 Dec dx ; Enable watchdog timer to be reset by mouse Mov al,0f7h Out dx,al Inc dx In al,dx Or al,80h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776D Mov al,0aah Out dx,al Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock NCT6776D AIIS-3400/3410 User Manual...
  • Page 77 Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx AIIS-3400/3410 User Manual...
  • Page 78 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776D Mov al,0aah Out dx,al AIIS-3400/3410 User Manual...

  • Page 79: Appendix B Programming 8-Bit Dio (Gpio)

    Appendix Programming 8-bit DIO (GPIO)

  • Page 80: Supported Gpio Register

    MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------- Configure logical device, configuration register CRE0,CRE1,CRE2 --------------------------------------------------------------- MOV DX,2EH MOV AL,09H OUT DX,AC DEC DX MOV AL,30H OUT DX,AL INC DX IN AL,DX OR AL,10000000B DEC DX MOV AL,07H OUT DX,AL AIIS-3400/3410 User Manual...
  • Page 81 ;Set GPIO is normal not inverter OUT DX,AL; DEC DX MOV AL,E1H OUT DX,AL INC DX MOV AL,??H ; Put the output value into AL OUT DX,AL ------------------------------------------ Exit extended function mode | ------------------------------------------ MOV DX,2EH MOV AL,AAH OUT DX,AL AIIS-3400/3410 User Manual...
  • Page 82 AIIS-3400/3410 User Manual...

  • Page 83: Appendix C 32-Bit Dio Signal Connections

    Appendix 32-bit DIO Signal Connections...

  • Page 84: Overview

    (IDO 0 ~ IDO 15) while it is being used as an output channel, the current will flow from the external voltage source to the card. Please take care that the current through each GND pin not exceed 100 mA. AIIS-3400/3410 User Manual...
  • Page 85 Figure C.2 Isolated Digital Output Connections AIIS-3400/3410 User Manual...
  • Page 86 AIIS-3400/3410 User Manual...
  • Page 87 Appendix Exploded Diagram & Parts List...
  • Page 88 Exploded Diagram Figure D.1 Exploded Diagram AIIS-3400/3410 User Manual...
  • Page 89 Table D.1: Parts List Fan filter CFast card clamps bracket Top cover Chassis assy HDD tray USB clamps bracket DIO board Side bracket PoE board Side cover R SYS fan Side cover L Main board Front IO panel Fan bracket AIIS-3400/3410 User Manual...
  • Page 90 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopy, recording, or otherwise, without the prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2016...
