Summary of Contents for Fortress Technologies FDH3816
- Page 1 Dehumidifier User Manual Model: FDH3816 *Before operating the appliance, please read this manual and all the safety instructions thoroughly and retain it for future reference.
-
Page 2: Table Of Contents
CONTENT PAGE SAFETY INSTRUCTION PARTS DESCRIPTION CONTROL PANEL OPERATION INSTRUCTION MAINTENANCE INSTRUCTION TROUBLESHOOTING SPECIFICATION WARRANTY... -
Page 3: Safety Instruction
SAFETY INSTURCTION IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. To avoid electric shock, fire or injury, please read the user manual carefully before using the appliance and keep it for future reference. This appliance is for household use only. Please use suitable power source. (Please refer to SPECIFICATION) Never immerse the appliance in water or other liquids. -
Page 4: Parts Description
PARTS DESCRIPTION Control Panel Control Panel Air Filter Water Tank Cover Outlet Carbon Filter Continuous Drainage Outlet Front Cover Air Inlet Water Tank CONTROL PANEL Ionizer ON/OFF Humidity Setting/ Timer LCD Display Button Button Fan Speed Button Button Sleep Mode Internal Wind Direction Mode Button... -
Page 5: Operation Instruction
OPERATION INSTRUCTION *Connect the power cord to the correct power supply. The room humidity and temperature will be displayed on the LCD display. The carbon filter indicator and the filter application time indicator will be on. Dehumidifier will be in standby mode. 1. - Page 6 Continuous dehumidify: Room humidity ≥ 60%: the compressor will be on and operated with high fan speed. Room humidity ≤ 55%: the compressor will be on and operated with medium fan speed. 60% > Room humidity >55%: continuous operating with existing mode. Laundry drying: the appliance operates with high fan speed and dehumidifies continuously.
- Page 7 Internal drying button Press the internal drying button for 3 seconds to activate the internal drying function. The internal drying indicator will start flashing. It will take around 1 hour for the whole cycle. It operates with high fan speed and the air deflector keeps upright for 30 minutes; then it operates with high fan speed and the air deflector starts swinging for 10 minutes;...
-
Page 8: Continuous Drainage
CONTINUOUS DRAINAGE 1. Turn off and unplug the appliance. 2. Use a knife or forceps to remove the cover of the continuous drain hole cover. (Fig. 3) 3. Remove the water tank and push the drain hole gasket. (Fig. 4) 4. -
Page 9: Maintenance Instruction
MAINTENANCE INSTRUCTION * Please turn off and unplug the appliance before cleaning or maintenance. Cleaning the air filter 1. Remove the front cover. (Fig. 7) 2. Remove the air filter from the appliance. (Fig. 8) 3. Remove the carbon filter from the air filter. 4. -
Page 10: Troubleshooting
TROUBLESHOOTING THE APPLIANCE DOES NOT OPERATE: Is the appliance plugged in? Is the house electricity on? Is the room temperature below 5 C or above 32 C? If so, it is out of the working range of the appliance. -
Page 11: Specification
SPECIFICATIONS Model No. FDH3816 Rated Voltage / Frequency 220V-240V~; 50Hz At 30 ℃ 80%RH: Dehumidifying Capacity 38L/day Power 650W At 26.7 ℃ 60%RH: Dehumidifying Capacity 24.8L/day Power 485W Net Weight 20.2kg Dimension (W x D x H)mm 410 x 265 x 665 C –... -
Page 12: Warranty
WARRANTY The product has 2 years warranty from the date of purchase. The warranty shall not apply: A. to any product subjected to misuse, alteration, act of God, improper handling, improper transport, improper testing or unauthorized repair; B. to cosmetic problems or defects which result from normal wear and tear under ordinary use yet not affecting the performance or use of the product;...
