Model Name
iCLEBO OMEGA
Voltage
220 V
Less than 0.6W
Standby Power
Main Body Power
53 W
Consumption
Battery Type
Lithium ion
Size
34.6
x 35.4
(width)
Height
8.7 cm
3.1 kg
Weight
350 mm/s
Speed
HEPA filter
Filter
Camera, PSD, Bumper, Dust detection,
Sensors
Floor carpet detection, IR
Charging Time
Approx. 180 min.
Working Time
80 min.
(In Turbo Mode: 60 min.)
Noise
68.5 dB[A]
(In Turbo Mode: 70dB[A])
A/S and Customer Center
Yujin Robot Customer Support : +1 714 880 6036
ㆍMonday-Friday 9 am to 6pm PST
Closed
ㆍSaturdays
ㆍSundays
Closed
MADE IN KOREA
17517 Fabrica Way, Suite K, Cerritos, CA 90703
support@yujinrobotinc.com
T +1 714 880 6036 F +1 714 880 6039
www.yujinrobotinc.com
One-Year Limited Warranty.
Specifications and features are subjected to change without notice.
(YCR-M07)
(Li-ion)
cm
(length)
(Max)
iOMN.USA.EN.V1
YCR-M07
User manual
Cleaning Robot iCLEBO OMEGA
■ The following Safety Precautions must be read before using the product.
■ Product warranty is included in this User Guide
www.yujinrobotinc.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Iclebo OMEGA
Summary of Contents for Iclebo OMEGA
- Page 1 220 V YCR-M07 Less than 0.6W Standby Power User manual Main Body Power 53 W Consumption Battery Type Lithium ion (Li-ion) Cleaning Robot iCLEBO OMEGA Size 34.6 x 35.4 (width) (length) Height 8.7 cm 3.1 kg Weight 350 mm/s Speed...
-
Page 2: Table Of Contents
Safety Precautions Checklist before Use Checklist after Use Components and Components Part Names Part Names Installation For Effective Cleaning How a Cleaning Robot Operates Before Use Assembling Side Brush Installing Charging Station Mounting Mop Pad Initial Power On / Off Charging Applying Blocking Tape Setting Time... -
Page 3: Checklist Before Use
The following instruction is to guarantee user safety and prevent any property loss. Read the below carefully and use the product with care. Users must follow the instructions to avoid serious injury or death. Warning Users must follow the instructions to avoid light injury or product damage. Caution 1. - Page 4 Remove small or fragile objects from cleaning area before use. - Fragile pottery, ceramics, or glass product. - Coins, hair pins, or jewelries. - Obstacles such as tablecloth, power cords, towels, or toys. ▶It may cause fire or malfunction. Do not use the product Do not repeatedly insert battery and charging and disconnect a power...
- Page 5 Blocking Caution required when Do not use a product in tape using a robot cleaner in areas with stairs that are areas with steps that are 5cm in height or above. up to 5cm in height. (e.g.: terrace, bathroom, 5cm or porch, etc.) ▶Blocking tape must be more...
- Page 6 Do not contact any Please empty the dust bin magnetic materials to the first before using a robot product body or charging cleaner. terminal. ▶ A robot cleaner with a full dust bin may not ▶It may cause damage or operate properly.
-
Page 7: Checklist After Use
Mop plate The plug must be YCR-M07 User Guide assembled tightly. Cleaning Robot iCLEBO OMEGA Otherwise, it may cause fire. ■ The following Safety Precautions must be read before using the product. ■ Product warranty is included in this User Guide www.iclebo.com... -
Page 8: Part Names
Part Names Top Part Bottom Part Front Wheel Cover Main Blade Cover Front Wheel Main Blade Charging Side Brush Dust bin Air vent Wheel Camera Display window Mop plate Bumper Main Sensor Manual charging jack Lithium-ion battery Power Switch Cleaning robot sensors ㆍDust bin and filter detection sensor (internal) PSD sensor, IR sensor... - Page 9 Charging Station Dust bin Charging Jack Charging display LED Inductive charging sensor Anti-slip Charging terminals HEPA filter Mesh filter Dust bin Remote Control Inserting Remote Control Batteries Power Insert 2 AAA batteries included in the product Charging Select Mode packaging in a remote control before using a product. Insert 2 AAA batteries included in the product Cursor Keys OK button...
-
Page 10: For Effective Cleaning
For effective cleaning Please read the followings to increase cleaning efficiency. ㆍPlease empty dust bin after using a robot cleaner. ㆍPlease apply entrance prevention tape or close doors to indicate non-cleaning areas. how to apply entrance prevention tape ㆍPlease clear unfixed objects such as toys, magazines and shoes before cleaning. ㆍDo not lift or force moving a robot cleaner in operation. -
Page 11: Installing Charging Station
Installing Charging Station 1. Connect an adapter jack to the back charging hole of the station. 2. Clear objects around the station, with a radius of 1.5m from the center of the station. Side parameter can be as short as 0.5m. Mounting Mop Mounting tip and pin... -
Page 12: Applying Blocking Tape
Charging while in Use ㆍThis robot cleaner will automatically move to a charging station once its battery runs too low to continue cleaning. After fully charged, it will start cleaning the remaining areas again and come back to the charging station once finished (except for the manual mode) Display Remote Control Operation... -
Page 13: Power On / Off
2. Set “HOUR” by pressing the cursor keys and press “OK”. Down 3. Set “MINUTE” by pressing the cursor keys and press “OK”. 4. A beeping sound means that the time is set. Down Using the Robot Cleaner Power On / Off Display Remote Control Operation... -
Page 14: Cleaning Modes
It is not available when the mop “CLIMB” again to reset. plate is attached. CLIMB Deactivating a climb mode while OMEGA cleans on a carpet may hinder OMEGA from coming down from the carpet. Maximize the suction for effective ㆍPress “TURBO” on a remote control to... -
Page 15: Timer Mode
Cleaning time may be decreased. (About 60 minutes) From normal mode, it automatically change to TURBO TURBO mode when it detects lots of dust or climbs on a carpet. Timer Mode Display Remote Control Operation 1. Press “TIMER” on a remote control. If a TIMER mode is preset, the screen indicates a time set. -
Page 16: Cleaning Side Brush
3. Use a cleaning brush to clean dust in the filters. The dust bin can be cleaned with water, but it needs to be dried thoroughly before being assembled again. HEPA filter is NOT washable. Use a regular vacuum machine to clean the filters. However, vacuum in a distance with a weak power to avoid damaging the filters. -
Page 17: Cleaning The Front Wheel
Cleaning the Front Wheel 1. Pull the front wheel 2. Use a cleaning brush or cover clips down to cotton bud to clean remove the cover. dust and dirt from the wheel. If a magnet was also 3. Put the front wheel removed, insert it by back. - Page 18 Below is a list of FAQs that shows the most commonly occurred problems while using the product. If you can’t solve a problem with information below, please contact our Service Center. (+1 714 880 6036) FAQs Cause of Problem Solution It is not cleaning ▶Dust bin is too full.
-
Page 19: Display Error Messages
Display Error Messages Display Cause Solution Lifted wheel Move the robot to an even place. Cannot detect floor Move the robot to an even place in case the wheels are stuck on an obstacle. Dust bin error Dust bin is not properly installed. Refer to Maintenance part in the user manual. - Page 20 Product Warranty Product Name iCLEBO OMEGA Model Name YCR-M07 Color Product Number Customer Name Telephone Address Date of Purchase Where it was Purchased Warranty Period: 1 Year (Battery: 6 months) Customer Compensation Policy Compensation Policy Description Within Warranty Period After Warranty Expired...
- Page 21 Open source software This vacuum cleaning robot contains open source software. Yujinrobot Inc. hereby provides a complete copy of the corresponding source code. To obtain the source code visit www.iclebo.com...
