Alcatel-Lucent OAW-AP228 Installation Manual

The Alcatel-Lucent OAW-AP228 is a fully temperature hardened, water resistant, indoor rated, dual-
radio IEEE 802.11ac wireless access point. This access point use MIMO (Multiple-in, Multiple-out)
technology and other high-throughput mode techniques to deliver high-performance, 802.11ac
2.4 GHz and 5 GHz functionality while simultaneously supporting existing 802.11a/b/g/n wireless
services. The OAW-AP228 access point works only in conjunction with an Alcatel-Lucent Switch.
OAW-AP228 Operations
Wireless transceiver

Wireless access point (IEEE 802.11 a/b/g/n/ac)

Wireless air monitor (IEEE 802.11 a/b/g/n/ac)

Protocol-independent networking functionalityF

Compatibility with IEEE 802.3at PoE

Central management configuration and upgrades with an Alcatel-Lucent Switch.

Guide Overview
"OAW-AP228 Hardware Overview" on page 3

OAW-AP228.
"Before You Begin" on page 5

a wireless network.
"Installing the AP" on page 7

deployment of the OAW-AP228.
"Safety and Regulatory Compliance" on page 12

compliance information.
Package Contents
OAW-AP228 Access Point

Cable Glands x2

USB Console Cable

Copper Lug x1

M4 x 6 Screw x1

Installation Guide (this document)

The weatherproof caps for Ethernet and Console interfaces are connected to the AP, not loose in the package.
Mounting kits for use with the OAW-AP228 access points are sold separately. Contact your Alcatel-Lucent sales
representative for details.
0511756-01 |
January 2015
OAW-AP228 Wireless Access Point
provides key questions to ask and items to consider when deploying
describes the multi-step process for a successful installation and
Installation Guide
provides a detailed hardware overview of the
provides an overview of safety and regulatory
1
