Page 1: Instruction Manual
Tabletop Bandsaw Model BS-IT-1651 Item 10276 Instruction Manual Locally QPS Revised - 03/06/2017 Approved Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com... -
Page 2: Table Of Contents
Table of Contents Model BS-IT-1651 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 8 Operation ----------------------------------------------------------------------------------------- 8 - 9 Maintenance ----------------------------------------------------------------------------------- 9 - 10 Troubleshooting... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model BS-IT-1651 Blade Length 65” / 1651 mm Cutting Capacity (H*W) 11” x 8” / 279 x 203 mm Power 1.2 HP / 0.90 kW... -
Page 7: Installation
Installation • Use 2 M10 studs long enough to ensure a fixing of at least 15 mm on the machine, with 2 large washers and 2 nuts. INSTALLATION CASE B The bandsaw must be mounted horizontally on a stable, robust and anti-skid base suitable to support its weight (refer to Technical Specifications section). -
Page 8: Operation
Installation on the blade. (Figure 8) 12. Rotate manually the bottom wheel in order to position the saw blade correctly. (Figure 9) 13. Make sure that the teeth protrude from the positioning bottom wheel for their whole depth. IMPORTANT: 14. If the teeth do not protrude out of the upper wheel, act as follows: •... -
Page 9: Maintenance
Operation 7. Once the operation is finished, position the switch to OFF (Figure 22). IMPORTANT If the bandsaw is in function and an unexpected power failure occur, the machine will stop immediately (Figure 23). When the power returns, the machine will not work even though the switch is in the ON position. To restart, turn the switch to OFF and then to ON (Figure 24). -
Page 10: Troubleshooting
Maintenance IMPORTANT: The top wheel can be easily taken off to the motor shaft. Avoid scraping inside the wheel hole, otherwise, the efficient working of the bandsaw may be undermined (Figure 33). 7. Remove the spring and, with two hands, pull off the drive pulley (Figure 34). IMPORTANT: When the bottom pulley doesn’t pull off easily, use the bottom wheel extractor supplied. -
Page 11: Illustrated Drawings
In the event of any faulty operation, do not hesitate to contact the customer service. REFERENCE Item Number Model Number Description Manufacturer Model Number Band Saw 65” / 1651mm Blade 10276 BS-IT-1651 T210E 1.2 HP / 895 W 110V/60/1 Illustrated Drawings Figure 1 Figure 2 Figure 3... - Page 12 Illustrated Drawings Figure 9 Figure 10 Figure 11 Figure 12 Figure 16 Figure 13 Figure 14 Figure 15 Figure 17 Figure 18 Figure 19 Figure 20...
- Page 13 Illustrated Drawings Figure 22 Figure 24 Figure 23 Figure 21 Figure 25 Figure 26 Figure 27 Figure 28 Figure 29 Figure 30 Figure 31 Figure 32...
- Page 14 Illustrated Drawings Figure 33 Figure 34 Figure 35 Figure 36 Figure 37 Figure 38...
-
Page 15: Parts Breakdown
Parts Breakdown Model BS-IT-1651 10276... - Page 16 Parts Breakdown Model BS-IT-1651 10276...
- Page 17 Parts Breakdown Model BS-IT-1651 10276...
- Page 18 Parts Breakdown Model BS-IT-1651 10276...
- Page 19 Parts Breakdown Model BS-IT-1651 10276 Item No. Description Position Item No. Description Position Item No. Description Position Stainless Steel Ring EL.Benzing 8 for 36537 A5406X 36649 Stainless Steel Nut U5588 M10 for T210E D0167X 36856 Protection Per Cover for T210E...
-
Page 20: Parts Breakdown
Parts Breakdown Model BS-IT-1651 10276 Item No. Description Position Item No. Description Position Item No. Description Position 19691 Grub Screw M6*6 for T210E V6066 37045 Screw TCEI U5931 M8x40 for T210E V6267 19718 Screw Bracket for T210E V7920 Screw TCTC AUT.D7981 3.5x9.5 for... -
Page 21: Electrical Schematics
Electrical Schematics Model BS-IT-1651 10276 Position Code Description Position Code Description I3627 Switch C5842 Capacitor 50 µF 250V (T250CE) R2043 Minicontactor B6-30-10-220V (T210CE) R2001 Relay 5.1A (T210CE) R2046 Minicontactor B6-30-10-120V (T-S250CE) R2002 Relay 11.8A (T250CE-S250CE) M8487 Motor 220V/60Hz (T210CE) Thermal Protector... -
