203 E. Daugherty, Webb City, MO 64870 USA Ph: 417-673-4631 Fax: 417-673-2153 0046-M563-O1 Rev A Printed in USA 02/13 www.detecto.com Technical Support: Ph: 866-254-8261 techsupport@cardet.com Technical Support: Ph: 866-254-8261 tech@cardet.com 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 2
0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 3
INTRODUCTION Thank you for purchasing our DETECTO™ IB Series Model IB800 in-bed scale. It has been manufactured with quality and reliability and has been assembled and tested before leaving our factory to insure accuracy and dependability for years to come.
Page 4
ASSEMBLY INSTRUCTIONS The IB Series Model IB800 in-bed scale is shipped disassembled in three (3) separate cartons. Carefully inspect all cartons for damage that may have taken place during shipment. It is the responsibility of the purchaser to file all claims with the shipping company for damages or loss incurred during transit.
Page 5
TWO PEOPLE. PLEASE READ THROUGH THE INSTRUCTIONS CAREFULLY BEFORE STARTING TO ASSEMBLE THE SCALE. Remove the shipping straps and packing material to unpack the IB Series Model IB800 in-bed scale. Check the parts against the PACKING CHECKLIST. If any are damaged or missing, please contact our Parts Department at 1-800-641-2045 or by email at parts@cardet.com.
Page 6
6. Continue to rotate the handle clockwise until the stance widens completely. 7. Return the handle to a vertical position to engage the locking pin. Releasing the Locking Pin Base at full wide stance 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 7
Next, install the 5/8” flat washers and 5/8-11 elastic stop nuts removed in step 1 on each bolt and tighten. Use the 1/2” drive ratchet with the 15/16 socket and 15/16” wrench to tighten. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 8
1 and tighten. Use the 1/2” drive ratchet with the 3/4” socket and 5/16” Allen wrench to tighten. Have an assistant hold the Boom Remove Bolt from Column Assembly while inserting the bolt 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 9
4. Next, align the ball end of the hydraulic cylinder with the ball socket on the column assembly and insert the ball into the socket. Tighten the cylinder nut to hold in place. Hand-tighten only. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 10
4. Repeat steps 2 and 3 for the push handle bolts on the other side of the column assembly. 5. Completely tighten all bolts to secure the push handle to the column assembly. Use the 7/16” wrench to tighten. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 11
3. Align the hole in the stretcher support hoop with the hoop support hook on the load cell tube and place on the support hook. Align hole in Stretcher Hoop Stretcher Hoop Installed with Support Hook 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 12
8. Completely tighten all three screws to secure the hoop retainer plate to the load cell tube weldment. Use the 3/16”Allen wrench to securely tighten. 9. Repeat steps 2 through 8 to install the stretcher support hoop on the other end of the load cell tube. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 13
NOTE: For more detailed information on installing the batteries, mounting the indicator on the scale bracket and connecting the load cell cable, refer to the 750 Owner’s Manual, 8555-M483-O1. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 14
Velcro® straps. Secure the stretcher support hoops to the column using the Anti-Swing Bars, attaching the rear anti-swing bar to the cylinder with the Velcro® strap. 0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 15
0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
Page 16
0046-M563-O1 Rev A IB800 ASSEMBLY INSTRUCTIONS...
