PIPELINE PRO 2 PLUS MANUAL
PIPELINE-PRO.CO.UK
02 FEATURES
-5 to 40 Watts
-Adjustable Centre Pin
-Up to 12V output voltage
-Up to 15A output current
-OLED display
-Temperature controlled vaping (possible with various wires)
-Heat Protection Function
-Power Boost Function
-Unregulated vaping possible
('Bypass' electronic overload protection)
-Battery shutdown voltage adjustable from 2.5V to 3.0V
-Resistance check
-Displays battery voltage under load
-Adjustable brightness display
-Set the length of time the menu is displayed
-Set the standby time
-Personalise click setting from 0-5 to activate device
-Info menu
-Battery capacity measurable
-Atomizer resistance range from 0.05Ω to 5Ω is possible
-Atomizer resistance from 0.2Ω to 3.5Ω (40W)
-Reverse polarity protection
-Abnormal temperature protection
-Serial Number
-2 year warranty on the electronics
-Design by Thomas Wilms
-Made in Germany by Dicodes
01 PIPELINE PRO 2 PLUS
The PIPELINE PRO 2 PLUS is a German made high-end mod for use
with 18650 batteries and has 5 different modes.
Variable Watt, Temperature Control (with various wires possible),
Variable Watt with Heat Protection, Variable Watt with Power Boost
and Bypass (unregulated, electronic overload protection).
We recommend operation with high current carrying IMR and high
drain batteries (eg Samsung 25R) with a discharge current of 20
amps (unprotected).
For optimal function of the temperature control we recommend
the Dicodes wire Resistherm (NiFe30).
03 MAIN MENU
Click once to enter the menu. There you can navigate by clicking
through the menu items. After a short wait at the desired menu item
you will be able to change the values by further clicking.
Power Up and Power Down
(Change Power)
Power Up gradually increases the power up to the set power limit
Power Down decreases the power.
Factory setting 10W
The power limit value is set in the extended functions submenu
'Temp Menu' and provides a power limit for less powerful atomizers
or a desired power limit.
