Page 1 HDCVI Series DVR User’s Manual Dahua HDCVI Series DVR User’s Manual Version 1.2.1...
Page 2: Table Of Contents
HDCVI Series DVR User’s Manual Table of Contents FEATURES AND SPECIFICATIONS ..............1 Overview ............................1 Features ............................1 Specifications ........................... 2 1.3.1 HCVR5104C Series ........................2 1.3.2 HCVR51XXC-V2 Series ......................5 1.3.3 HCVR7104C-V2 Series....................... 7 1.3.4 HCVR410XC-S2 Series ......................8 1.3.5...
Page 3 HDCVI Series DVR User’s Manual 2.1.2 HCVR51XXH/HCVR51XXHE/ HCVR51XXH-V2 / HCVR51XXHE-V2/HCVR71XXH-V2 / HCVR71XXHE-V2 Series ........................38 2.1.3 HCVR51XXHC/ HCVR51XXHC-V2/ HCVR71XXHC-V2 Series ..........39 2.1.4 HCVR41XXHE-S2/ HCVR51XXH-S2/ HCVR51XXHE-S2/ HCVR710XH-S2/ HCVR710XHE-S2/ HCVR41XXHS-S2/ HCVR2108HS-S2 Series ............40 Rear Panel ............................40 2.2.1 HCVR5104C Series ........................40 2.2.2...
Page 4 HDCVI Series DVR User’s Manual 2.3.15 HCVR710XHE-S2 Series ..................... 82 2.3.16 HCVR41XXHS-S2/HCVR2108HS-S2 Series ..............83 Remote Control ..........................84 Mouse Control ..........................86 INSTALLATION AND CONNECTIONS ............. 88 Check Unpacked DVR ........................88 About Front Panel and Rear Panel ....................88 HDD Installation ..........................
Page 5 HDCVI Series DVR User’s Manual Other Interfaces ..........................94 OVERVIEW OF NAVIGATION AND CONTROLS ..........95 Boot up and Shutdown ........................95 4.1.1 Boot up ............................95 4.1.2 Shutdown ........................... 95 4.1.3 Auto Resume after Power Failure .................... 95 4.1.4 Replace Button Battery ......................
Page 6 HDCVI Series DVR User’s Manual Main Menu ............................ 110 Operation ............................110 4.8.1 Search ............................110 4.8.2 Backup ............................. 117 4.8.3 Shut Down..........................119 Information ............................ 119 4.9.1 System Info ..........................119 4.9.2 Event ............................123 4.9.3 Network ............................ 123 4.9.4...
Page 7 HDCVI Series DVR User’s Manual Setup ............................. 198 5.8.1 Camera ............................. 198 5.8.2 Network ............................ 206 5.8.3 Event ............................221 5.8.4 Storage ............................. 229 5.8.5 Setting ............................231 Information ............................ 243 5.9.1 Version ............................. 243 5.9.2 Log ............................243 5.9.3 Online User ..........................
Page 8 HDCVI Series DVR User’s Manual APPENDIX D COMPATIBLE DISPLAYER LIST ..........266 APPENDIX E COMPATIBLE SWITCHER LIST ..........267 APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ........268...
Page 9 HDCVI Series DVR User’s Manual Welcome Thank you for purchasing our Dahua HDCVI DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.
Page 10: Important Safeguards And Warnings
HDCVI Series DVR User’s Manual Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
Page 11: Features And Specifications
HDCVI Series DVR User’s Manual 1 FEATURES AND SPECIFICATIONS 1.1 Overview This series product is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. It is easy to use and can realize surveillance function after some simple setups.
Page 12: Specifications
HDCVI Series DVR User’s Manual Support network remote real-time monitor, remote record search and remote PTZ control.  Alarm activation function Several relay alarm outputs to realize alarm activation and on-site light control. The alarm input port and output has the protection circuit to guarantee device safety.
Page 13 HDCVI Series DVR User’s Manual 1-ch VGA output. Video 1-ch HDMI output. Output Support VGA/HDMI video output at the same time. Video Video monitor Support PAL/NTSC. Standard Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s...
Page 14 HDCVI Series DVR User’s Manual Storage Support channel record quota setup Mode Recording 1 to 120 minutes single record duration (Default setup is 60 minutes) Length Playback Repeat When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel.
Page 15: Hcvr51Xxc-V2 Series
HDCVI Series DVR User’s Manual 2 USB 2.0 port. Interface Interface Network 1 RJ45 10M/100M self-adaptable Ethernet port connection RS485 RS232 System Hard Disk Display HDD current status Information Information Data Data stream statistics for each channel (in wave mode)
Page 16 HDCVI Series DVR User’s Manual Parameters HCVR5104C-V2 HCVR5108C-V2 Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 1536Kbps-4096Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps Bit Stream Type Video stream/composite stream Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit...
Page 17: Hcvr7104C-V2 Series
HDCVI Series DVR User’s Manual 1.3.3 HCVR7104C-V2 Series Parameters HCVR7104C-V2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P /720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 2048Kbps-6144Kbps， Rate For 1080P: default setup is 4Mbps，max supports 6Mbps...
Page 18: Hcvr410Xc-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104C-V2 Weight 1.25KG（No HDD） Installation Desk Mode 1.3.4 HCVR410XC-S2 Series Parameters HCVR4104C-S2 HCVR4108C-S2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 720P/960H/D1/HD1/ 720P(1~15fps)/960H/D1/ Resolution 2CIF/CIF/QCIF HD1/2CIF/CIF/QCIF HDCVI ：...
Page 19: Hcvr510Xc-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR4104C-S2 HCVR4108C-S2 Port Communication 2 USB ports Others Power DC12V ≤15W（With power adapeter, no HDD） Power Consuption Working -10℃－＋55℃ Temperature Working 10%~90% Humidity Dimensions SMART 1U case，270mm（W）×205mm（D）×41mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.5 HCVR510XC-S2 Series...
Page 20: Hcvr7104C-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR5104C-S2 HCVR5108C-S2 Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Coomunication Network 1 RJ45 port, 100Mbps Ethernet port Port...
Page 21: Hcvr2108C-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104C-S2 Audio Port Audio Input 1-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port. Talk Input Record Record Mode Schedule record/manual record/MD record/Alarm record Record Max 4-channel playback Playback...
Page 22: Hcvr51Xxh Series
HDCVI Series DVR User’s Manual Parameters HCVR2108C-S2 Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 1-channel RCA port. Audio Output 1-channel RCA port.
Page 23 HDCVI Series DVR User’s Manual Audio Compressio G711A, G711U, PCM 4-CH composite video input: 8-CH composite video input: Video Input 75Ω) 75Ω) (NTSC/PAL) BNC (1.0V (NTSC/PAL) BNC (1.0V P- P, P- P, 1-ch VGA output. Video 1-ch HDMI output. Output Support VGA/HDMI video output at the same time.
Page 24 HDCVI Series DVR User’s Manual Manual recording, motion detection recording, schedule recording and Recording alarm recording Mode Priority: Manual recording> alarm recording>motion detection Record and recording>schedule recording. playback Storage Support channel record quota setup Mode Recording 1 to 120 minutes single record duration (Default setup is 60 minutes)
Page 25 HDCVI Series DVR User’s Manual Manual Alarm Control Alarm Input Alarm Output Alarm Relay 2 USB 2.0 ports. Interface Interface Network 1 RJ45 10M/100M self-adaptable Ethernet port connection PTZ control port RS485 Support various PTZ control protocols. RS232 System Hard Disk...
Page 26: Hcvr51Xxh-V2 Series
HDCVI Series DVR User’s Manual 1.3.9 HCVR51XXH-V2 Series Parameters HCVR5104H-V2 HCVR5108H-V2 HCVR5116H-V2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 1536Kbps-4096Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps...
Page 27: Hcvr51Xxhc Series
HDCVI Series DVR User’s Manual Parameters HCVR5104H-V2 HCVR5108H-V2 HCVR5116H-V2 Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.10 HCVR51XXHC Series HCVR5104HC HCVR5108HC Parameter High-performance industrial embedded micro controller Main System Processor Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel playback...
Page 28 HDCVI Series DVR User’s Manual Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Cover secret channel with black screen though system is encoding Lock normally. Screen-lock function to prevent unauthorized user seeing secret video.
Page 29 HDCVI Series DVR User’s Manual function Mode Support peripheral USB backup device. (Flash disk, portable disk and etc.) Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance.
Page 30: Hcvr51Xxhc-V2 Series
HDCVI Series DVR User’s Manual User-friendly interface when login. Provide the following options: Logout /shutdown/ restart. Right authentication when shut down to make sure only those proper people can turn off DVR DC 12V Power Power General ≤15W (With adapter, exclude HDD)
Page 31: Hcvr51Xxhe Series
HDCVI Series DVR User’s Manual Parameters HCVR5104HC-V2 HCVR5108HC-V2 HCVR5116HC-V2 Playback playback playback playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Coomunication Network 1 RJ45 port, 100Mbps Ethernet port...
Page 32 HDCVI Series DVR User’s Manual Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s Record per channel Speed Video 1/4 windows(Optional) 1/4/8/9 windows Partition Monitor Support monitor tour functions such as motion detection, and schedule Touring auto control.
Page 33 HDCVI Series DVR User’s Manual Playback Repeat When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame playback Mode and reverse play mode.
Page 34: Hcvr51He-V2 Series
HDCVI Series DVR User’s Manual PTZ control port RS485 Support various PTZ control protocols. RS232 System Hard Disk Display HDD current status Information Information Data Data stream statistics for each channel (in wave mode) Stream Statistics Backup to 1024 log files.
Page 35: Hcvr71Xxh-V2 Series
HDCVI Series DVR User’s Manual Parameters HCVR5104HE-V2 HCVR5108HE-V2 HCVR5116HE-V2 Video Frame 1536Kbps-4096Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps Bit Stream Type Video stream/composite stream Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps 4-channel ，...
Page 36 HDCVI Series DVR User’s Manual Parameters HCVR7104H-V2 HCVR7108H-V2 Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P /720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 2048Kbps-6144Kbps， Rate For 1080P: default setup is 4Mbps，max supports 6Mbps Bit Stream Type Video stream/composite stream...
Page 37: Hcvr71Xxhc-V2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104H-V2 HCVR7108H-V2 Mode 1.3.15 HCVR71XXHC-V2 Series Parameters HCVR7104HC-V2 HCVR7108HC-V2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P/720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 2048Kbps-6144Kbps，...
Page 38: Hcvr71Xhe-V2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104HC-V2 HCVR7108HC-V2 Temperature Working 10%~90% Humidity Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.16 HCVR71XHE-V2 Series Parameters HCVR7104HE-V2 HCVR7108HE-V2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264...
Page 39: Hcvr41Xxhe-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104HE-V2 HCVR7108HE-V2 Port Communication RS485 port 2 USB ports Others Power DC12V ≤30W（With power adapeter, no HDD） Power Consuption Working -10℃－＋55℃ Temperature Working 10%~90% Humidity Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.17 HCVR41XXHE-S2 Series...
Page 40: Hcvr51Xxh-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR4104HE-S2 HCVR4108HE-S2 HCVR4116HE-S2 HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 4-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port. Talk Input...
Page 41: Hcvr51Xxhe-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR5104H-S2 HCVR5108H-S2 HCVR5116H-S2 Video Port Analog Video 4-channel，BNC port 8-channel，BNC port 16-channel， Input BNC port Network Video Max 2-channel IPC connections (8M) Input Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)，...
Page 42: Hcvr710Xh-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR5104HE-S2 HCVR5108HE-S2 HCVR5116HE-S2 Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-channel，BNC port 8-channel，BNC port 16-channel， Input BNC port Network Video Max 2-channel IPC connections (8M)
Page 43: Hcvr710Xhe-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104H-S2 HCVR7108H-S2 Video Frame HDCVI：1～25f/s（PAL）；1~30f/s（NTSC） Rate CVBS：1~25f/s（PAL）；1~30f/s（NTSC） Video Frame 2048Kbps-6144Kbps， Rate For 1080P: default setup is 4Mbps，max supports 6Mbps. For 720P: default setup is 2Mbps，max supports 4Mbps. Bit Stream Type Video stream/composite stream Dual-Stream...
Page 44 HDCVI Series DVR User’s Manual Parameters HCVR7104HE-S2 HCVR7108HE-S2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame HDCVI：1～25f/s（PAL）；1~30f/s（NTSC） Rate CVBS：1~25f/s（PAL）；1~30f/s（NTSC） Video Frame 2048Kbps-6144Kbps， Rate For 1080P: default setup is 4Mbps，max supports 6Mbps.
Page 45: Hcvr41Xxhs-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR7104HE-S2 HCVR7108HE-S2 Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.22 HCVR41XXHS-S2 Series Parameters HCVR4104HS-S2 HCVR4108HS-S2 HCVR4116HS-S2 System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard...
Page 46: Hcvr2108Hs-S2 Series
HDCVI Series DVR User’s Manual Parameters HCVR4104HS-S2 HCVR4108HS-S2 HCVR4116HS-S2 Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Coomunication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication RS485 port 2 USB ports Others Power DC12V ≤15W（With power adapeter, no HDD）...
Page 47 HDCVI Series DVR User’s Manual Parameters HCVR2108HS-S2 Record 960H: Max 4-channel playback Playback 720P: Max 1-channel playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input Alarm Output HDD Port 1 SATA port，does not support eSATA port Space...
Page 48: Overview And Controls
HDCVI Series DVR User’s Manual 2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 HCVR5104C/ HCVR51XXC-V2/ HCVR7104C-V2/HCVR410XC-S2/ HCVR510XC- S2/HCVR7104C-S2/HCVR2108C-S2 Series The front panel is shown as below.
Page 49: Hcvr51Xxhc/ Hcvr51Xxhc-V2/ Hcvr71Xxhc-V2 Series
HDCVI Series DVR User’s Manual Figure 2-2 Please refer to the following sheet for front panel button information. Icon Name Function To connect USB storage device, USB mouse and USB port etc. When an alarm occurs, the light becomes red to...
Page 50: Hcvr41Xxhe-S2/ Hcvr51Xxh-S2/ Hcvr51Xxhe-S2/ Hcvr710Xh-S2
HDCVI Series DVR User’s Manual Figure 2-3 Please refer to the following sheet for front panel button information. Icon Name Function Network abnormal Network error occurs or there is no network indicator light connection, the light becomes red to alert you.
Page 51: Hcvr5104C-V2/Hcvr5108C-V2 Series
HDCVI Series DVR User’s Manual Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc.
Page 52: Hcvr7104C-V2 Series
HDCVI Series DVR User’s Manual Figure 2-6 The HCVR5108C-V2 rear panel is shown as below. See Figure 2-7. Figure 2-7 Please refer to the following sheet for detailed information. Icon Name Note Ground end Power input port Input 12V DC.
Page 53: Hcvr4104/Hcvr4108C-S2/Hcvr2108C-S2 Series
HDCVI Series DVR User’s Manual Figure 2-8 Please refer to the following sheet for detailed information. Icon Name Note Ground end VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 54 HDCVI Series DVR User’s Manual Figure 2-9 The HCVR4108C-S2/HCVR2108C-S2 series rear panel is shown as below. See Figure 2-10. Figure 2-10 Please refer to the following sheet for detailed information. Icon Name Note Ground end USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc.
Page 55: Hcvr5104/5108C-S2 Series
HDCVI Series DVR User’s Manual HDMI port of the display device. AUDIO OUT Audio output port Connect to video output device such as sound box. 2.2.5 HCVR5104/5108C-S2 Series The HCVR5104C-S2 series rear panel is shown as below. See Figure 2-11.
Page 56: Hcvr7104C-S2 Series
HDCVI Series DVR User’s Manual VIDEO IN Video input port Connect to analog camera, video input signal. Power input port Input 12V DC. Network port 100M Ethernet port HDMI High definition High definition audio and video media interface signal output port.
Page 57: Hcvr5104H/Hcvr5108H Series
HDCVI Series DVR User’s Manual Network port 100M Ethernet port AUDIO OUT Audio output port Connect to video output device such as sound box. 2.2.7 HCVR5104H/HCVR5108H Series The HCVR5104H series rear panel is shown as below. See Figure 2-14. Figure 2-14 The HCVR5108H series rear panel is shown as below.
Page 58: Hcvr5104H-V2/Hcvr5108H-V2/Hcvr5116H-V2 Series
HDCVI Series DVR User’s Manual RS485_A port. It is the cable A. You RS485（RS-485） can connect to the control devices communication port such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ.
Page 59: Hcvr5104Hc/Hcvr5108Hc Series
HDCVI Series DVR User’s Manual Figure 2-18 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 60: Hcvr5104Hc-V2/Hcvr5108Hc-V2/Hcvr5116Hc-V2 Series
HDCVI Series DVR User’s Manual Figure 2-19 The HCVR5108HC series rear panel is shown as below. See Figure 2-20. Figure 2-20 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal.
Page 61 HDCVI Series DVR User’s Manual Figure 2-21 The HCVR5108HC-V2 series rear panel is shown as below. See Figure 2-22. Figure 2-22 The HCVR5116HC-V2 series rear panel is shown as below. See Figure 2-23. Figure 2-23 Please refer to the following sheet for detailed information.
Page 62: Hcvr5104He/Hcvr5108He Series
HDCVI Series DVR User’s Manual port analog video signal. Can connect to the monitor to view ananlog video output. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc. VIDEO IN Video input port Connect to analog camera, video input signal.
Page 63: Hcvr5104He-V2/Hcvr5108He-V2/Hcvr5116He-V2 Series
HDCVI Series DVR User’s Manual Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal. AUDIO OUT Audio output port Connect to video output device such as sound box. AUDIO IN Audio input port Connect to audio input device such as speaker.
Page 64 HDCVI Series DVR User’s Manual The HCVR5108HE-V2 series rear panel is shown as below. See Figure 2-27. Figure 2-27 The HCVR5116HE-V2 series rear panel is shown as below. See Figure 2-28. Figure 2-28 Please refer to the following sheet for detailed information.
Page 65: Hcvr7104H-V2/Hcvr7108H-V2 Series
HDCVI Series DVR User’s Manual communication port such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ. Network port 100M Ethernet port HDMI High definition High definition audio and video...
Page 66: Hcvr7104Hc-V2/Hcvr7108Hc-V2 Series
HDCVI Series DVR User’s Manual VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc. HDMI...
Page 67: Hcvr7104He-V2/Hcvr7108He-V2 Series
HDCVI Series DVR User’s Manual Figure 2-32 Please refer to the following sheet for detailed information. Icon Name Note VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 68 HDCVI Series DVR User’s Manual The HCVR7108HE-V2 series rear panel is shown as below. See Figure 2-34. Figure 2-34 Please refer to the following sheet for detailed information. Icon Name Note Alarm input/Alarm Input/output alarm signal. output Power on-off button Power on/off button.
Page 69: Hcvr4104/4108/4116He-S2 Series
HDCVI Series DVR User’s Manual 2.2.16 HCVR4104/4108/4116HE-S2 Series The HCVR4104HE-S2 series rear panel is shown as below. See Figure 2-35. Figure 2-35 The HCVR4108HE-S2 series rear panel is shown as below. See Figure 2-36. Figure 2-36 The HCVR4116HE-S2 series rear panel is shown as below. See Figure 2-37.
Page 70: Hcvr5104/5108/5116H-S2 Series
HDCVI Series DVR User’s Manual Power on-off button Power on/off button. Alarm input/Alarm Input/output alarm signal. output VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. AUDIO IN...
Page 71 HDCVI Series DVR User’s Manual Figure 2-38 The HCVR5108H-S2 series rear panel is shown as below. See Figure 2-39. Figure 2-39 The HCVR5116H-S2 series rear panel is shown as below. See Figure 2-40. Figure 2-40 Please refer to the following sheet for detailed information.
Page 72: Hcvr5104/5108/5116He-S2 Series
HDCVI Series DVR User’s Manual Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. AUDIO IN Audio input port Connect to audio input device such as speaker.
Page 73 HDCVI Series DVR User’s Manual Figure 2-42 Figure 2-43 The HCVR5116HE-S2 series rear panel is shown as below. See Figure 2-43 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. Alarm input/Alarm Input/output alarm signal.
Page 74: Hcvr7104/7108H-S2 Series
HDCVI Series DVR User’s Manual Ground end Input 12V DC. Power input port HDMI High definition High definition audio and video media interface signal output port. transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device.
Page 75: Hcvr7104/7108He-S2 Series
HDCVI Series DVR User’s Manual Figure 2-45 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 76 HDCVI Series DVR User’s Manual Figure 2-46 The HCVR7108HE-S2 series rear panel is shown as below. See Figure 2-47. Figure 2-47 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. Alarm input/Alarm Input/output alarm signal.
Page 77: Hcvr41Xxhs-S2/ Hcvr2108Hs-S2 Series
HDCVI Series DVR User’s Manual mouse, burning DVD-ROM and etc. RS485 （ RS-485 ） RS485_A port. It is the cable A. You can connect to the control devices communication port such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ.
Page 78: Connection Sample
HDCVI Series DVR User’s Manual Figure 2-50 Please refer to the following sheet for detailed information. Icon Name Note Power input port Input 12V DC. RS485 （ RS-485 ） RS485_A port. It is the cable A. You can connect to the control devices communication port such as speed dome PTZ.
Page 79: Hcvr5104C Series
HDCVI Series DVR User’s Manual 2.3.1 HCVR5104C Series Please refer to Figure 2-51 for connection sample. Figure 2-51 2.3.2 HCVR51XXH Series Please refer to Figure 2-52 for connection sample. The following figure is based on the HCVR5108H series product.
Page 80: Hcvr51Xxhc/Hcvr51Xxhe Series
HDCVI Series DVR User’s Manual Figure 2-52 2.3.3 HCVR51XXHC/HCVR51XXHE Series Please refer to Figure 2-53 for connection sample. The following figure is based on the HCVR5108HC series product.
Page 81: Hcvr51Xxc-V2/Hcvr71Xxc-V2 Series
HDCVI Series DVR User’s Manual Figure 2-53 2.3.4 HCVR51XXC-V2/HCVR71XXC-V2 Series Please refer to Figure 2-54 for connection sample. The following figure is based on the HCVR7104C-V2 series product.
Page 82: Hcvr51Xxh-V2/Hcvr71Xxh-V2 Series
HDCVI Series DVR User’s Manual Figure 2-54 2.3.5 HCVR51XXH-V2/HCVR71XXH-V2 Series Please refer to Figure 2-55 for connection sample. The following figure is based on the HCVR7108H-V2 series product.
Page 83: Hcvr51Xxhe-V2/Hcvr71Xxhe-V2 Series
HDCVI Series DVR User’s Manual Figure 2-55 2.3.6 HCVR51XXHE-V2/HCVR71XXHE-V2 Series Please refer to Figure 2-56 for connection sample. The following figure is based on the HCVR5116HE-V2 series product.
Page 84: Hcvr51Xxhc-V2/Hcvr71Xxhc-V2 Series
HDCVI Series DVR User’s Manual Figure 2-56 2.3.7 HCVR51XXHC-V2/HCVR71XXHC-V2 Series Please refer to Figure 2-57 for connection sample. The following figure is based on the HCVR7108HC-V2 series product.
Page 85: Hcvr410Xc-S2/Hcvr2108C-S2 Series
HDCVI Series DVR User’s Manual Figure 2-57 2.3.8 HCVR410XC-S2/HCVR2108C-S2 Series Please refer to Figure 2-58 for connection sample. The following figure is based on the HCVR4104C-S2 series product.
Page 86: Hcvr510Xc-S2 Series
HDCVI Series DVR User’s Manual Figure 2-58 2.3.9 HCVR510XC-S2 Series Please refer to Figure 2-59 for connection sample. The following figure is based on the HCVR5108C-S2 series product.
Page 87: Hcvr7104C-S2 Series
HDCVI Series DVR User’s Manual Figure 2-59 2.3.10 HCVR7104C-S2 Series Please refer to Figure 2-60 for connection sample.
Page 88: Hcvr41Xxhe-S2 Series
HDCVI Series DVR User’s Manual Figure 2-60 2.3.11 HCVR41XXHE-S2 Series Please refer to Figure 2-61 for connection sample. The following figure is based on the HCVR4104HE-S2 series product.
Page 89: Hcvr51Xxh-S2 Series
HDCVI Series DVR User’s Manual Figure 2-61 2.3.12 HCVR51XXH-S2 Series Please refer to Figure 2-62 for connection sample. The following figure is based on the HCVR5104H-S2 series product.
Page 90: Hcvr51Xxhe-S2 Series
HDCVI Series DVR User’s Manual Figure 2-62 2.3.13 HCVR51XXHE-S2 Series Please refer to Figure 2-63 for connection sample. The following figure is based on the HCVR5108HE-S2 series product.
Page 91: Hcvr710Xh-S2 Series
HDCVI Series DVR User’s Manual Figure 2-63 2.3.14 HCVR710XH-S2 Series Please refer to Figure 2-64 for connection sample. The following figure is based on the HCVR7108H-S2 series product.
Page 92: Hcvr710Xhe-S2 Series
HDCVI Series DVR User’s Manual Figure 2-64 2.3.15 HCVR710XHE-S2 Series Please refer to Figure 2-65 for connection sample. The following figure is based on the HCVR7108HE-S2 series product.
Page 93: Hcvr41Xxhs-S2/Hcvr2108Hs-S2 Series
HDCVI Series DVR User’s Manual Figure 2-65 2.3.16 HCVR41XXHS-S2/HCVR2108HS-S2 Series Please refer to Figure 2-65 for connection sample. The following figure is based on the HCVR4108HS-S2/HCVR2108HS-S2 series product.
Page 94: Remote Control
HDCVI Series DVR User’s Manual Figure 2-66 2.4 Remote Control The remote control interface is shown as in Figure 2-67. Please note remote control is not our standard accessory and it is not included in the accessory bag.
Page 95 HDCVI Series DVR User’s Manual Figure 2-67 Please refer to the following sheet for detailed information. Serial Number Name Function Power button Click it to boot up or shut down the device. Address Click it to input device number, so that you can control it.
Page 96: Mouse Control
HDCVI Series DVR User’s Manual Cancel Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel. Click this button for at least 1.5 seconds, system can go to the Manual Record interface.
Page 97 HDCVI Series DVR User’s Manual In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.
Page 98: Installation And Connections
HDCVI Series DVR User’s Manual 3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage.
Page 99: Hcvr51Xxh/51Xxhc/51Xxhe/51Xxh-V2/Hc-V2/He-V2/71Xxh-V2/71Xxhc
HDCVI Series DVR User’s Manual ○ ○ ○ Turn the device upside down and Fix the HDD firmly. Connect the HDD cable and then turn the screws in firmly. power cable. ○ ○ Put the cover in accordance with Secure the screws in the rear panel and the side panel.
Page 100: Connecting Power Supply
HDCVI Series DVR User’s Manual ⑦ ⑧ Put the cover in accordance with the Secure the screws in the rear panel clip and then place the upper cover and the side panel. back. Important:  You can connect the HDD data cable and the power cable first and then fix the HDD in the device.
Page 101: Connecting Video Output
HDCVI Series DVR User’s Manual 3.5.2 Connecting Video Output ，75Ω）output ,a VGA output and HDMI output. System Video output includes a BNC(PAL/NTSC1.0V supports BNC, VGA and HDMI output at the same time. When you are using pc-type monitor to replace the monitor, please pay attention to the following points: ...
Page 102: Alarm Input And Output Details
HDCVI Series DVR User’s Manual The alarm output port should not be connected to high power load directly (It shall be less than 1A) to avoid high current which may result in relay damage. Please use the co contactor to realize the connection between the alarm output port and the load.
Page 103: Alarm Output Port
HDCVI Series DVR User’s Manual  Please parallel connect the Ground of the DVR and the ground of the alarm detector.  Please connect the NC port of the alarm sensor to the DVR alarm input(ALARM)  Use the same ground with that of DVR if you use external power to the alarm device.
Page 104: Other Interfaces
HDCVI Series DVR User’s Manual 3.8 RS485 When the DVR receives a camera control command, it transmits that command up the coaxial cable to the PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit. To enable the operation, connect the PTZ device to the RS485 (A,B) input on the DVR.
Page 105: Overview Of Navigation And Controls
HDCVI Series DVR User’s Manual 4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK.
Page 106 HDCVI Series DVR User’s Manual Check the box Startup button here, system goes to startup wizard again when it boots up the next time. Cancel the Startup button, system goes to the login interface directly when it boots up the next time.
Page 107 HDCVI Series DVR User’s Manual Figure 4-3 Click Next button, you can go to network interface. See Figure 4-4. For detailed information, please refer to chapter 4.9.3. Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5.
Page 108: Manual Record
HDCVI Series DVR User’s Manual Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No.
Page 109 HDCVI Series DVR User’s Manual  Preview drag: If you want to change position of channel 1 and channel 2 when you are previewing, you can left click mouse in the channel 1 and then drag to chann el 2, release mouse you can switch channel 1 and channel 2 positions.
Page 110 HDCVI Series DVR User’s Manual Figure 4-9  Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-10. Figure 4-10 Right click mouse to cancel zoom and go back to the original interface.
Page 111: Right-Click Menu
HDCVI Series DVR User’s Manual 4.4 Right-Click Menu On the preview interface, right click mouse, you can view menu interface shown as in Figure 4-11. Tips After you go to the corresponding interface, right click mouse to go back to the upper-level.
Page 112 HDCVI Series DVR User’s Manual Figure 4-13 In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure 4-14. Please make sure your protocol supports this function and you need to use mouse to control.
Page 113 HDCVI Series DVR User’s Manual Tour Reset Pattern Scan Aux on-off button Rotate Go to menu 4.4.2.1 PTZ Function Setup Click , you can go to the following interface to set preset, tour, pattern, and scan. See Figure 4-16. Figure 4-16 Preset Setup In Figure 4-16, click preset button and use eight direction arrows to adjust camera to the proper position.
Page 114 HDCVI Series DVR User’s Manual Input tour value and preset No. Click Add preset button to add current preset to the tour. See Figure 4-18. Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour.
Page 115 HDCVI Series DVR User’s Manual Figure 4-20 4.4.2.2 Call PTZ Function Call Preset In Figure 4-15, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-15, input pattern value and then click to call a pattern.
Page 116: Color
HDCVI Series DVR User’s Manual Figure 4-21 4.4.3 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mo de and etc. See Figure 4-22. Figure 4-22 Please refer to the following sheet for detailed information. Item...
Page 117: Search
HDCVI Series DVR User’s Manual Item Note Brightness It is to adjust monitor window bright. The value ranges from 0 to 100. The default value is 50. The larger the number, the bright the video is. When you input the value here, the bright section and the dark section of the video will be adjusted accordingly.
Page 118: Main Menu
HDCVI Series DVR User’s Manual Figure 4-23 4.5.1 Main Menu Click button to go to the main menu interface. 4.5.2 Output Screen Select corresponding window-split mode and output channels. 4.5.3 Favorites Click , system pops up the favorites schemes. Click one item, you can view saved favorite channel split mode and channel number.
Page 119: Remote Device
HDCVI Series DVR User’s Manual Figure 4-25 4.5.10 Remote Device Click , system goes to an interface for you to view remote device information. Please refer to chapter 4.10.1.1 4.5.11 Network Click , system goes to the network interface. It is to set network IP address, default gateway and etc.
Page 120: Main Menu
HDCVI Series DVR User’s Manual Figure 4-26 4.7 Main Menu The main menu interface is shown as below. See Figure 4-27. Figure 4-27 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-28.
Page 121 HDCVI Series DVR User’s Manual  M: Motion detection recording file Figure 4-28 Please refer to the following sheet for more information. Name Function Here is to display the searched picture or file. Display Support 1/4/8-window playback. window Here you can select to search the picture or the recorded file.
Page 122 HDCVI Series DVR User’s Manual Click it to go to mark file list interface. You can view all mark information of current Mark file channel by time. Please refer to chapter 4.8.1.3 for detailed information. list button Please note only the product of this icon supports mark function.
Page 123 HDCVI Series DVR User’s Manual Click the snapshot button in the full-screen mode, the system can snapshot 1 picture. System supports custom snap picture saved path. Please connect the peripheral device first, click snap button on the full-screen mode, you can select or create path.
Page 124 HDCVI Series DVR User’s Manual  Once the motion detect play has begun, click button again will terminate current motion detect file play.  There is no motion detect zone by default.  If you select to play other file in the file list, system switches to motion detect play of other file.
Page 125 HDCVI Series DVR User’s Manual Important  System does not support motion detect zone setup during the full-screen mode.  During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search. 4.8.1.2 Accurate playback by time Select records from one day, click the list, you can go to the file list interface.
Page 126 HDCVI Series DVR User’s Manual Figure 4-31  Playback Mark During 1-window playback mode, click mark file list button in Figure 4-28, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time.
Page 127: Backup
HDCVI Series DVR User’s Manual  If the mark file you want to playback has been removed, system begin playbacking from the first file in the list. 4.8.2 Backup DVR support CD-RW, DVD burner, USB device backup, network download and eSATA. Here we introduce USB, eSATA backup.
Page 128 HDCVI Series DVR User’s Manual Figure 4-34 System only backup files with a √ before channel name. You can use Fn or cancel button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.
Page 129: Shut Down
HDCVI Series DVR User’s Manual The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S. File extension name is .dav. Tips: During backup process, you can click ESC to exit current interface for other operation. The system will not terminate backup process.
Page 130 HDCVI Series DVR User’s Manual Figure 4-37 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-38.  SATA: 1 here means system max supports 1 HDD. ○ means current HDD is normal. X means there is error.
Page 131 HDCVI Series DVR User’s Manual Figure 4-38 Double click one HDD information; you can see the HDD SMART information. See Figure 4-39. Figure 4-39 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-40.
Page 132 HDCVI Series DVR User’s Manual Figure 4-40 4.9.1.3 BPS Here is for you to view current video data stream (KB/s), resolution and etc. See Figure 4-41. Figure 4-41 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and...
Page 133: Event
HDCVI Series DVR User’s Manual Figure 4-42 4.9.2 Event It is to display device status and channel status. See Figure 4-43. Figure 4-43 4.9.3 Network 4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-44. You can disconnect one user or block one user if you have proper system right. Max disconnection...
Page 134 HDCVI Series DVR User’s Manual System detects there is any newly added or deleted user in each five seconds and refresh the list automatically. Figure 4-44 4.9.3.2 Network Load Network load is shown as in Figure 4-45. Here you can view the follow statistics of the device network adapter.
Page 135: Log
HDCVI Series DVR User’s Manual Network test interface is shown as in Figure 4-46.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.
Page 136 HDCVI Series DVR User’s Manual  Start time/end time: Pleased select start time and end time, then click search button. You can view the log files in a list. System max displays 100 logs in one page. It can max save 1024 log files.
Page 137: Setting
HDCVI Series DVR User’s Manual Figure 4-48 4.10 Setting It is for you to set camera, network, event, storage, system and etc. 4.10.1 Camera Here you can set audio/video property, camera property and channel name, channel type. 4.10.1.1 Remote Device (For digital channel only) Note You can see this interface after you set IP channel in chapter 4.10.1.3.5.
Page 138 HDCVI Series DVR User’s Manual  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list.  Manual add: Click it to add the IPC manually. The port number is 37777. The default user name is admin and password is admin.
Page 139 HDCVI Series DVR User’s Manual 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-51.  IPC status: : Front-end does not support.
Page 140 HDCVI Series DVR User’s Manual 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-53. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.)
Page 141 HDCVI Series DVR User’s Manual  Sharpness: The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa. Please note there is noise if the val ue here is too high.
Page 142 HDCVI Series DVR User’s Manual Figure 4-54 Figure 4-55 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-56.  Channel: Select the channel you want.
Page 143 HDCVI Series DVR User’s Manual  Resolution: System supports various resolutions, you can select from the dropdown list. Please note the option may vary due to different series.  Frame rate: It ranges from 1f/s to 25f/s in NTSC mode and 1f/s to 30f/s in PAL mode.
Page 144 HDCVI Series DVR User’s Manual Figure 4-57 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-58.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel.
Page 145 HDCVI Series DVR User’s Manual Figure 4-58 Figure 4-59 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-60.
Page 146: Network
HDCVI Series DVR User’s Manual Figure 4-60 4.10.1.3.5 Channel Type It is to set channel type. It supports coaxial/UTP/IP. See Figure 4-61. Figure 4-61 4.10.2 Network 4.10.2.1 TCP/IP The interface is shown as in Figure 4-62...
Page 147 HDCVI Series DVR User’s Manual  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.  MAC address: The host in the LAN can get a unique MAC address. It is for you to access in the LAN. It is read-only.
Page 148 HDCVI Series DVR User’s Manual Figure 4-62 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-63.  Max connection: system support maximal 128 users. 0 means there is no connection lim it.  TCP port: Default value is 37777.
Page 149 HDCVI Series DVR User’s Manual Figure 4-63 4.10.2.3 WIFI The WIFI interface is shown as below. See Figure 4-64.  Auto connect WIFI: Check the box here, system automatically connects to the previous WIFI hotspot.  Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before.
Page 150 HDCVI Series DVR User’s Manual  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 151 HDCVI Series DVR User’s Manual Figure 4-65 4.10.2.5 PPPoE PPPoE interface is shown as in Figure 4-66. Input “PPPoE name” and “PPPoE password” you get from your ISP (Internet service provider). Click save button, you need to restart to activate your configuration.
Page 152 2) Function Introduction The Dahua DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 153 HDCVI Series DVR User’s Manual 3) Operation Before you use Dahua DDNS, you need to enable this service and set proper server address, port value and domain name.  Server address：www.dahuaddns.com  Port number：80  Domain name：There are two modes: Default domain name and customized domain name.
Page 154 HDCVI Series DVR User’s Manual Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
Page 155 HDCVI Series DVR User’s Manual  SSL enable: System supports SSL encryption box.  Interval: The send interval ranges from 0 to 3600 seconds. 0 means there is no interval.  Health email enable: Please check the box here to enable this function. This function allows the system to send out the test email to check the connection is OK or not.
Page 156 HDCVI Series DVR User’s Manual Figure 4-71 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to H140H140H140HTUFTP://10.10.7.7UTH and then test it can modify or delete folder or not. See Figure 4-72.
Page 157 HDCVI Series DVR User’s Manual Figure 4-73 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-62. See Figure 4-74. ...
Page 158 HDCVI Series DVR User’s Manual Figure 4-74 Figure 4-75 4.10.2.11 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system.
Page 159 HDCVI Series DVR User’s Manual Figure 4-76 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
Page 160 HDCVI Series DVR User’s Manual Figure 4-77 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”...
Page 161 HDCVI Series DVR User’s Manual Please note multiple cast function applies to special series only. 4.10.2.13 Register This function allows the device to auto register to the proxy you specified. In this way, you can use the client-end to access the DVR and etc via the proxy. Here the proxy has a switch function. In the network service, device supports the server address of IPv4 or domain.
Page 162: Event
HDCVI Series DVR User’s Manual Figure 4-79 4.10.2.15 P2P The P2P interface is shown as in Figure 4-80. You can use you cell phone to scan the QR to add the device via the client on the cell phone. For detailed information, please refer to the P2P operation manual included in the resources CD.
Page 163 HDCVI Series DVR User’s Manual In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-81.There is three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
Page 164 HDCVI Series DVR User’s Manual  In Figure 4-84. Click button after one date or a holiday, you can see an interface shown as in Figure 4-85. There are four record types: regular, motion detection (MD), Alarm, MD & alarm.
Page 165 HDCVI Series DVR User’s Manual Figure 4-81 Figure 4-82 Figure 4-83...
Page 166 HDCVI Series DVR User’s Manual Figure 4-84 Figure 4-85 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-81, select video loss from the type list. You can see the interface is shown as in Figure 4-86.This function allows you to be informed when video loss phenomenon occurred.
Page 167 HDCVI Series DVR User’s Manual Figure 4-86 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-87.
Page 168 HDCVI Series DVR User’s Manual Figure 4-87 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzz er. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. For analog channel, the interface is shown as in Figure 4-88 and Figure 4-89 .
Page 169 HDCVI Series DVR User’s Manual motion detection (MD), Alarm, MD & alarm.  In Figure 4-93, Select icon of several dates, all checked items can be edited together. Now the icon is shown as . Click to delete a record type from one period.
Page 170 HDCVI Series DVR User’s Manual Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. Figure 4-88 Figure 4-89...
Page 171 HDCVI Series DVR User’s Manual . Figure 4-90 Figure 4-91...
Page 172 HDCVI Series DVR User’s Manual Figure 4-92 Figure 4-93 Figure 4-94...
Page 173 HDCVI Series DVR User’s Manual 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-95 and Figure 4-96.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-97.  Alarm output: Please select alarm activation output port (multiple choices).
Page 174 HDCVI Series DVR User’s Manual Figure 4-96 Figure 4-97 4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual.
Page 175: Storage
HDCVI Series DVR User’s Manual Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-98. Figure 4-98 4.10.4 Storage It is to set HDD management, storage parameters, set record plan and record control.
Page 176 HDCVI Series DVR User’s Manual  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all.
Page 177 HDCVI Series DVR User’s Manual Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording.
Page 178 HDCVI Series DVR User’s Manual setup of channel 1 to all channels, you can click the first box “ALL”. Click the OK button to save current copy setup. Click the OK button in the Encode interface, the copy function succeeded.
Page 179 HDCVI Series DVR User’s Manual  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-106.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See Figure 4-107.
Page 180 HDCVI Series DVR User’s Manual Figure 4-107 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 181 HDCVI Series DVR User’s Manual Figure 4-109 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 182 HDCVI Series DVR User’s Manual 4.10.4.2 HDD Manager Here is for you to view and implement hard disk management. See Figure 4-111. You can see current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy).
Page 183 HDCVI Series DVR User’s Manual Figure 4-112 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-113. Figure 4-113 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function. 4.10.4.4 HDD Detect...
Page 184 HDCVI Series DVR User’s Manual The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types:  Quick detect is to detect via the universal system files. System can quickly complete the HDD scan.
Page 185 HDCVI Series DVR User’s Manual Figure 4-115 4.10.4.4.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-116. Figure 4-116 Click the item you can see the detailed information such as detect result. See Figure 4-117.
Page 186: System
HDCVI Series DVR User’s Manual Figure 4-117 4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-118.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.
Page 187 HDCVI Series DVR User’s Manual  Startup wizard: Once you check the box here, system will go to the startup wizard directly when the system restarts the next time. Otherwise, it will go to the login interface.  Mouse property: You can set double click speed via dragging the slide bard. You can Click Default button to restore default setup.
Page 188 HDCVI Series DVR User’s Manual Figure 4-119 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-120. Click Add new holiday button, you can input new holiday information. See Figure 4-121. Here you can set holiday name, repeat mode and start/end time.
Page 189 HDCVI Series DVR User’s Manual Figure 4-120 Figure 4-121 4.10.5.2 Display It is to set display, TV adjust, tour, zero-channel encode, and preview favorites information. 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-122.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 190 HDCVI Series DVR User’s Manual  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
Page 191 HDCVI Series DVR User’s Manual  Delete: Click it to remove selected channel group.  Move up: Click it to move current selected channel up.  Move down: Click it to move current selected channel down.  Default: Click it to restore default setup.
Page 192 HDCVI Series DVR User’s Manual function is disabled. After you enabled this function, login the Web and you can select zero-channel encoding mode at the right corner of the interface . Select a mode; you can view the local preview video.
Page 193 Control mode: You can select control mode from the dropdown list. There are two options: Serial/HDCVI. For HDCVI series product, please select HDCVI. The control signal is sent to the PTZ via the coaxial cable. For the serial mode, the control signal is sent to the PTZ via the RS485 port.
Page 194 HDCVI Series DVR User’s Manual Figure 4-127 Figure 4-128 4.10.5.4 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode is network. The network type interface is shown as below. See Figure 4-129.
Page 195 HDCVI Series DVR User’s Manual For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number). Figure 4-129 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-130.
Page 196 HDCVI Series DVR User’s Manual 4.10.5.5 Account Here is for you to implement account management. See Figure 4-131 and Figure 4-132. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password.
Page 197 HDCVI Series DVR User’s Manual Figure 4-132 4.10.5.5.1 Add/Modify Group Click add group button in Figure 4-132 , the interface is shown as below. See Figure 4-133. Here you can input group name and then input some memo information if necessary.
Page 198 HDCVI Series DVR User’s Manual Click add user button in Figure 4-131 , the interface is shown as in Figure 4-134. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user.
Page 199 HDCVI Series DVR User’s Manual Figure 4-135 4.10.5.7 Config Backup The configuration file backup interface is shown as below. See Figure 4-136. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.
Page 200 HDCVI Series DVR User’s Manual Figure 4-136 4.10.5.8 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 4-137.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function.
Page 201 HDCVI Series DVR User’s Manual Figure 4-137 4.10.5.9 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-138.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 202: Web Operation
HDCVI Series DVR User’s Manual 5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 203: Lan Mode
HDCVI Series DVR User’s Manual 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are six function buttons: Live（chapter 5.4）, playback (chapter 5.10) setup (chapter 5.8), info (chapter 5.9), alarm (chapter 5.11), and logout (chapter 5.12).
Page 204: Live
HDCVI Series DVR User’s Manual Please note, if audio input port from the device to the client-end is using the first channel audio input port. During the bidirectional talk process, system will not encode the audio data from the 1-channel.
Page 205: Ptz
HDCVI Series DVR User’s Manual In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP (10.15.6.144), channel number (1), network monitor bit stream (61Kbps) and stream type: M (Main stream)/S (Sub stream).
Page 206: Image
HDCVI Series DVR User’s Manual Parameter Function  Select Tour from the dropdown list. Tour  Input preset value in the column. Click Add preset button, you have added one preset in the tour.  Repeat the above procedures you can add more presets in one tour.
Page 207: Wan Login
HDCVI Series DVR User’s Manual Figure 5-12 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-13. Figure 5-13 Please refer to the following contents for LAN and WAN login difference.
Page 208: Setup
HDCVI Series DVR User’s Manual Figure 5-14 Important The window display mode and the channel number are by default. For example, for the 16- channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 209 HDCVI Series DVR User’s Manual Figure 5-15 Figure 5-16 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device information on the list. It includes device IP address, port, device search name, manufacturer and type.
Page 210 Note:  System supports manufactures such as Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont, Dahua and Onvif standard protocol.  If you do not input IP address here. System uses default IP 192.168.0.0 and system does not connect to this IP.
Page 211 HDCVI Series DVR User’s Manual Figure 5-18 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods.
Page 212 HDCVI Series DVR User’s Manual ranges from 40 to 60. Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 213 HDCVI Series DVR User’s Manual video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 214 HDCVI Series DVR User’s Manual 1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF; the extra stream supports CIF/QCIF. Please note the option may vary due to different series. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is.
Page 215 HDCVI Series DVR User’s Manual It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Or you can set customized value. The max setup is 3600s/picture.
Page 216: Network
HDCVI Series DVR User’s Manual Here you can set snap image saved path ( in the preview interface) and the record storage path in the preview interface).The default setup is C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup.
Page 217 HDCVI Series DVR User’s Manual  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.
Page 218 HDCVI Series DVR User’s Manual Figure 5-26 Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120.
Page 219 HDCVI Series DVR User’s Manual Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status.
Page 220 HDCVI Series DVR User’s Manual Check send SMS box and then input the phone number in the receiver column. Click to add one receiver. Repeat the above steps you can add more phones. Select a phone number and then click you can delete it.
Page 221 2) Function Introduction The Dahua DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 222 HDCVI Series DVR User’s Manual  User name: It is optional. You can input your commonly used email address. Important  Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack.
Page 223 HDCVI Series DVR User’s Manual Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function. You can auto login anonymously.
Page 224 HDCVI Series DVR User’s Manual Figure 5-34 5.8.2.11 UPnP It allows you to establish the mapping relationship between the LAN and the public network. Here you can also add, modify or remove UPnP item. See Figure 5-35.  In the Windows OS, From Start->Control Panel->Add or remove programs. Click the “Add/Remove Windows Components”...
Page 225 HDCVI Series DVR User’s Manual Parameter Function It is corresponding to the UPnP mapping information on the router. Check the box before the service name to enable current PAT service. Otherwise, the service is null.  Service name：Custmozied name. Prptocol：Protocol type.
Page 226 HDCVI Series DVR User’s Manual Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write.
Page 227 HDCVI Series DVR User’s Manual 5.8.2.15 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs.
Page 228 HDCVI Series DVR User’s Manual Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.16.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43.
Page 229 HDCVI Series DVR User’s Manual Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
Page 230 HDCVI Series DVR User’s Manual Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
Page 231: Event
HDCVI Series DVR User’s Manual Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.16.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50.
Page 232 HDCVI Series DVR User’s Manual Figure 5-51 Figure 5-52 Figure 5-53...
Page 233 HDCVI Series DVR User’s Manual Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.
Page 234 HDCVI Series DVR User’s Manual Parameter Function Show System can pop up a message to alarm you in the local host message screen if you enabled this function. Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs.
Page 235 HDCVI Series DVR User’s Manual Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzz er. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
Page 236 HDCVI Series DVR User’s Manual Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods.
Page 237 HDCVI Series DVR User’s Manual Parameter Function current channel as schedule record. System can delay the record for specified time after alarm Record Delay ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.
Page 238 HDCVI Series DVR User’s Manual It includes two types: No disk, disk error, disk no space, net disconnection, IP conflict and MAC conflict. See Figure 5-61 and Figure 5-62. Figure 5-61 Figure 5-62 Please refer to the following sheet for detailed information.
Page 239: Storage
HDCVI Series DVR User’s Manual 5.8.4 Storage 5.8.4.1 Schedule In this interfaces, you can add or remove the schedule record/snapshot setup. See Figure 5-63. There are three record modes: general (auto), motion detect and alarm. There are six periods in one day.
Page 240 HDCVI Series DVR User’s Manual Figure 5-65 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30.
Page 241: Setting
HDCVI Series DVR User’s Manual Figure 5-67 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device. Status There are three statuses: schedule, manual and stop.
Page 242 HDCVI Series DVR User’s Manual Figure 5-68 Please refer to the following sheet for detailed information. Parameter Function It is to set device name. Device ID Device No. It is device channel number. Language You can select the language from the dropdown list.
Page 243 HDCVI Series DVR User’s Manual Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device.
Page 244 HDCVI Series DVR User’s Manual Figure 5-70 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 Display Here you can set background color and transparency level. See Figure 5-71. Figure 5-71 Please refer to the following sheet for detailed information.
Page 245 HDCVI Series DVR User’s Manual Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s.
Page 246 PTZ type You can select control mode from the dropdown list. There are two Control options: Serial/HDCVI. For HDCVI series product, please select mode HDCVI. The control signal is sent to the PTZ via the coaxial cable. For the serial mode, the control signal is sent to the PTZ via the RS485 port.
Page 247 HDCVI Series DVR User’s Manual Parameter Function Default setup is 1. Please set according to the speed dome dial switch Stop bit setup. Parity Default setup is none. Please set according to the speed dome dial switch setup. 5.8.5.4 ATM/POS The ATM/POS function is for financial areas.
Page 248 HDCVI Series DVR User’s Manual Figure 5-76 5.8.5.5 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline.
Page 249 HDCVI Series DVR User’s Manual Hidden user “default” is for system interior use only and can not be deleted. When there is no login user, hidden user “default” automatically login. You can set some rights such as monitor for this user so that you can view some channel view without login.
Page 250 HDCVI Series DVR User’s Manual Figure 5-79 5.8.5.5.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-80. Figure 5-80 Add group: It is to add group and set its corresponding rights. See Figure 5-81.
Page 251 HDCVI Series DVR User’s Manual Figure 5-81 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-82. Here you can modify group information such as remarks and rights. Figure 5-82 5.8.5.6 Auto maintain...
Page 252 HDCVI Series DVR User’s Manual Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 253: Information
HDCVI Series DVR User’s Manual Important Improper upgrade program may result in device malfunction! Figure 5-86 5.9 Information 5.9.1 Version The version interface is shown as in Figure 5-87. Here you can view record channel, alarm input/output information, software version, release date and etc.
Page 254: Online User
HDCVI Series DVR User’s Manual Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 255: Search Record
HDCVI Series DVR User’s Manual Figure 5-90 5.10.1 Search Record Please set record type, record date, window display mode and channel name.  Select Date You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files.
Page 256: Playback
HDCVI Series DVR User’s Manual Figure 5-93 5.10.3 Playback Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time.
Page 257: Load More
HDCVI Series DVR User’s Manual Figure 5-95 5.10.5 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. Or you can use watermark function to verify file.
Page 258 HDCVI Series DVR User’s Manual Check the file(s) you want to download and there are two options for you to save the file(s).  Download to local Click Download to local, system pops up the following interface for you to set record format and saved path.See Figure 5-97.
Page 259: Alarm
HDCVI Series DVR User’s Manual Figure 5-99 Set record format and saved path, you can click OK to download and view the download process. After the download operation, you can see corresponding dialog box. 5.10.5.3 Watermark Watermark interface is shown as In Figure 5-100. Please select a file and then click Verify button to see...
Page 260: Log Out
HDCVI Series DVR User’s Manual Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.). Figure 5-101 Please refer to the following sheet for detailed information. Type...
Page 261: Un-Install Web Control
HDCVI Series DVR User’s Manual Figure 5-102 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 262: Professional Surveillance System
HDCVI Series DVR User’s Manual 6 Professional Surveillance System Besides Web, you can use our Smart PSS to login the device. For detailed information, please refer to Smart PSS user’s manual.
Page 263: Faq
HDCVI Series DVR User’s Manual 7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.
Page 264 HDCVI Series DVR User’s Manual  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged.  HDD is broken.  Upgraded program is not compatible. ...
Page 265 HDCVI Series DVR User’s Manual  PTZ decoder and DVR address is not compatible.  When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable.
Page 266 HDCVI Series DVR User’s Manual  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.  Data amount exceeds backup device capacity. It may result in burner error.
Page 267 HDCVI Series DVR User’s Manual Please contact your local service engineer or our sales person for help. We can guide you to solve this problem. 24. When I login via HTTPS, a dialogue says the certificate for this website is for other address.
Page 268: Appendix A Hdd Capacity Calculation
HDCVI Series DVR User’s Manual Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.
Page 269: Appendix B Compatible Backup Device List
HDCVI Series DVR User’s Manual Appendix B Compatible Backup Device List Compatible USB drive list NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. If you use the USB drive, please confirm the format FAT or FAT32.
Page 270 HDCVI Series DVR User’s Manual Netac U228 Compatible SD Card List Please refer to the following sheet for compatible SD card brand. Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Micro-SD Sandisk Micro-SD Compatible Portable HDD List Please refer to the following sheet for compatible portable HDD brand.
Page 271 HDCVI Series DVR User’s Manual Seagate Seagate SV35.1 ST3250824SV 250G SATA Seagate Seagate SV35.1 ST3500641SV 500G SATA Seagate Seagate SV35.2 ST3250820SV 250G SATA Seagate Seagate SV35.2 ST3320620SV 320G SATA Seagate Seagate SV35.2 ST3500630SV 500G SATA Seagate Seagate SV35.2 ST3750640SV 750G...
Page 272 HDCVI Series DVR User’s Manual Seagate Seagate ST2000NM0031 SATA Constellation ES Seagate Seagate ST1000NM0031 SATA Constellation ES Seagate Seagate ST500NM0031 500G SATA Constellation ES Seagate Seagate ST2000NM0051 SATA Constellation ES Seagate Seagate ST1000NM0051 SATA Constellation ES Seagate Seagate ST500NM0051 500G...
Page 273 HDCVI Series DVR User’s Manual Westem WDAV-GP—AVCS WD2500AVCS 250G SATA Digital Westem WDAV-GP—EVCS WD10EVCS-63ZLB0 SATA Digital Westem WDAV-GP—EVCS WD20EVCS-63ZLB0 SATA Digital Westem WDAV-GP—AVVS WD3200AVVS-63L2B0 320G SATA Digital Westem WDAV-GP—AVVS WD5000AVVS-63ZWB0 500G SATA Digital Westem WDAV-GP—AVVS WD7500AVVS-63E1B1 750G SATA Digital Westem WDAV-GP—AVVS...
Page 274 HDCVI Series DVR User’s Manual Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 275: Appendix C Compatible Cd/Dvd Device List
HDCVI Series DVR User’s Manual APPENDIX C Compatible CD/DVD Device List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner.
Page 276: Appendix D Compatible Displayer List
HDCVI Series DVR User’s Manual Appendix D Compatible Displayer List Please refer to the following sheet for the compatible device brand. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD）...
Page 277: Appendix E Compatible Switcher List
HDCVI Series DVR User’s Manual Appendix E Compatible Switcher List Please refer to the following sheet form compatible switcher list. Brand Model Network Working Mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive There are five network modes： 1、AUTO 2、HALF-10M...
Page 278: Appendix F Compatible Wireless Mouse List
HDCVI Series DVR User’s Manual Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630 Note:  This manual for reference only. Slight difference may be found in the user interface.
