5 - USE
Parameter Parameter's description
1001 Supply temperature
1002 Indirect water heater temperature
1004 Outdoor sensor temperature
1006 Flue gas temperature
1007 Return temperature
1008 Ionisation current
1009 State of the Local pump
1010 State of the CH pump
1011 State of the DHW pump
1012 Calculated CH setpoint (when outdoor sensor is enabled)
1040 Actual Fan speed
1041 Ignition fan speed
1042 Low power fan speed
1043 High power fan speed
1051 Last lockout number
1052 Last Blocking error
1053 Number of flame failures
1055 Number of failed ignitions
1056 Total hours of operation
1057 Total hours of operation of the indirect water heater
1059 **Interval between Lockouts. May be: 1:MIN; 2:HRS; 3:DAY; 4:WK
**Interval between Blocking errors. May be: 1:MIN; 2:HRS; 3:DAY; 4:WK
1060
1062 Water flow
1101 CASCADE: number of boilers ON
1102 CASCADE: header temperature
1103 CASCADE: any boiler into Lockout
1104 CASCADE: any boiler into Blocking Error
1106 CASCADE: system is in emergency mode
1107 CASCADE: current cascade setpoint
1120 CASCADE: boiler 1 modulating level
1121 CASCADE: boiler 2 modulating level
1122 CASCADE: boiler 3 modulating level
1123 CASCADE: boiler 4 modulating level
** How to read the timer value:
Eg: If it shows 1:29, it means 29 minutes;
Eg: If it shows 2:12, it means 12 hours;
Eg: If it shows 3:15, it means 15 days;
Eg: If it shows 4:26, it means 26 weeks;
5.10 - "Users'
menu"
Pressing RESET key for 2 seconds,
you will enter the "Users' menu".
When entering the "Users' menu", the
display, item "M" in Figure 5-1, will
16
start showing parameters from 1000.
Press keys and
can scroll all parameters inside this
menu. All parameters into this "Users'
menu" can be consulted but not
changed.
Units
°F
°F
°F
°F
°F
μA (micro ampere)
ON/OFF
ON/OFF
ON/OFF
°F
rpm/min
rpm/min
rpm/min
rpm/min
\
\
no
no
Hr x 10
Hr x 10
GPM
n
°F
/
/
/
°F
%
%
%
%
you
