Remote Control - Phase Linear UDV7 Instruction Manual

UV7

REMOTE CONTROL

Button
Name/Ref # DVD
MENU 1 Enters the main Turns on PBC
menu of the disc when playing VCD
TITLE 2 Enters the title Plays first ten sec-
menu of the disc onds of each
chapter/title
MUTE 3 Toggles on/off Toggles on/off
audio output audio output
4 Turns the power Turns the power
POWER
on/off on/off
AUDIO 5 Changes the
audio language
for disc playback
REPT A-B 6 Setup to repeat Setup to repeat
playback from playback from
time frame A to time frame A to
time frame B time frame B
REPT 7 Repeats playback Repeats playback
of current chapter of current chapter
SRC 8 Selects playing Selects playing
mode mode
SUBTITLE 9 Language selec-
tion for subtitle
DISP 10 Displays playing Displays playing
information information
ANGLE 13 Plays back disc in Plays back Picture
different angle for CD with different
a scene angle of picture
displayed
14 Fast forwards the Fast forwards the
disc content disc content
VOL - 15 Decreases vol- Decreases vol-
ume ume
VOL + 16 Increases volume Increases volume
17 Selects the previ- Selects the previ-
ous chapter for ous chapter for
playback playback
18 Pauses playback/ Pauses playback/
starts playback starts playback
Table 1: Remote Control Functions
Function
VCD AM/FM CD/MP3
Toggles on/off Toggles on/off
audio output audio output
Turns the power Turns the power
on/off on/off
Repeats playback
of current track
Selects playing Selects playing
mode mode
Displays playing Display playing
information information
Fast forwards the
disc content
Decreases vol- Decreases vol-
ume ume
Increases volume Increases volume
Searches an Selects the previ-
available radio ous track for play-
station by back
decreasing tuning
frequency
Scans FM/AM Pauses playback/
radio station; starts playback
plays/stores radio
station; deletes
radio station
XM iPod
Displays XM Selects Photo
Setup Menu mode
Selects Music
mode
Toggles on/off Toggles on/off
audio output audio output
Turns the power Turns the power
on/off on/off
Selects Video
mode
Selects Category Repeats playback
Mode of current track
Selects playing Selects playing
mode mode
Displays playing Display playing
information information
Accesses iPod
Menu
Decreases vol- Decreases vol-
ume ume
Increases volume Increases volume
Searches an Pauses playback/
available radio starts playback
station by
decreasing tuning
frequency
Scans XM radio
station; plays/
stores radio sta-
tion; deletes radio
station
9
NOTE: Your remote control may differ slightly
from the one pictured here. The above diagram is
for illustrative purposes only.
