Page 1
Magnetic Elliptical Trainer OWNER’S MANUAL CET-2150...
Page 2
Page of Contents ■ Precautions ■ Operating Instruction ■ Parts List ■ Overview Drawing Hardware Packing List ■ Assembly Instructions ■ Adjustment ■ Maintenance and Treatment ■ Warming Up and Cooling ■ dowm Cosco (India) Ltd., 2/8,Roop Nagar,Delhi-110 007...
Page 3
1. Precautions 1) Read all the instructions in this manual and do warm exercises before using this equipment. 2) This elliptical trainer is a home stationary fitness equipment, and also an aerobic training equipment that can help you to develop your cardiovascular function. 3) Please make sure all parts are not damaged and fixed well before use.
Page 4
Operation Instruction Warning: To avoid injury, remember not to ride the bike in the opposite direction when riding in one direction at high speed. Function: 1. Program: 19 programs as following fig 1 A: 1 Manual Program P1 (see fig 1) B: 10 Preset Program Profile: P2~P11 (see fig 2~fig 11) P2: ROLLING P3: VALLEY...
5. PULSE RECOVERY: First test your current heart rate and show your heart rate value, press this button to enter into pulse recovery testing. When you are in pulse recovery mode, press this button to exit. OPERATION 1. Turn on the computer Plug in one end of the adaptor to the AC electrical source and connect the other end to the computer.
Page 7
fig 25 HEART RATE CONTROL PROGRAM: P12, P13 and P14 The maximum heart rate depends on different age and this program will ensure you do the healthy exercise within maximum heart rate. A. Press UP, DOWN to choose the heart rate control program B.
Page 8
User Profile Programs: P16 ~P18 A. Press UP, DOWN to select the user B. Press ENTER to confirm your choice, and enter into time setting window. fig 28 C. The time display will flash, and then press UP, DOWN to set up the desired time to do the exercise. Press ENTER to confirm the value.
Page 9
G. Press START/STOP to begin testing your body fat.(see fig 34) NOTE: 1. During the body fat measurement, place both your palms on the contact pads. The test result are: FAT%, BMR (Basal Metabolic Rate), BMI (Body Mass Index). (see fig 35) fig 35 FAT%: The total body fat in our body measured by percentage.
Remark: During the process of pulse measurement, because of the contact jamming, the measurement value may not be stable when start, then it will return to normal level. The measurement value cannot be regarded as the basis of medical treatment. NOTE: If the computer is also equipped with wireless heart rate measuring via the transmitter belt, the wireless signal detecting is preferred.
Page 11
13 U-shape bracket M10 hex nut cap 14 handlebar bracket Hexagonal nut M6 15 handlebar foam Hexagonal nut M5 Φ25 Round plug 16 Left handlebar Φ32 Round plug 17 Right handlebar 18 Handlebar support foam M10 special nut cap 19 Motor Left pedal 1/2 20 Pulse wire Right pedal 1/2...
1. Hardware Packing List 1)Hardware Packing List 2)blister faced package Description Q’ty Description Q’ty Handlebar support assembly hardware Pedal support tube assembly hardware Handlebar assembly hardware Pedals assembly hardware Wave washer...
Page 15
6. Assembly Instructions Please follow these assembly instructions step by step to assemble this elliptical; the base end caps, foot cushions and chain cover have been assembled in the factory. 1. Install the Front Stabilizer Attached front stabilizer (2) to the main frame (1) with 2 sets of half-round Allen bolt M8x16 (62), Spring washer Φ8(92) and flat washer Φ8 (86).
Page 16
a. Attach the left Pedal (49) to the left Pedal support tube (5) with E [ Bolts M8x50 (70), Flat washers Φ8 (86), and Lock nuts M8 (82)]. Do the above same steps to assemble the right Pedal (50) to the right Pedal support tube (6). (See figure 5) b.
Page 17
7. Install the Handlebar (Right & Left) Attached the left and right handlebar (16&17) to the handlebar support (8&9) with B [hexagonal bolt M8x40 (71), arc washer (69), spring washerΦ8 (92) and nut cap (59) ] ,then tighten as show on figure 9. Note: The bolt must be set into the hexangular hole.
Page 18
1) Resistance can be adjusted by the computer to increase or decrease the exercise intensity. 2) After a long term use, if finding the turning parts are loose, please tighten the bolts or screws. 8. Maintenance and Treatment 1) Verify that all the bolts and nuts are locked properly and the turning parts should be turned freely without damaged parts.
Warming up and cooling down A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. Warming up is an important part of your workout, and should begin every session.
