Solar Eclipse Installation & Operations Manual
1A. Description ...............................................................1
1B. Specifications ...........................................................1
1C. Warranty Summary ..................................................1
2A. Pool Preparation ......................................................1
2B. Location ....................................................................1
2C. Mounting ..................................................................2
2D. Electrical ..................................................................2
2E. Plumbing ..................................................................2
3A. Initial System Start-Up .............................................3
3B. Normal Operation .....................................................3
3C. System Shut-Down ..................................................3
3D. Winterizing ...............................................................3
3E. Water Chemistry ......................................................3
READ AND FOLLOW ALL INSTRUCTIONS.
•
Read this manual completely before attempting installation. Failure to install in accordance with the installation
instructions could void warranty and result in injury or death.
•
All permanent electrical connections should be made by a qualified electrician.
•
A pressure wire connector, labeled "BONDING LUGS", is provided on the outside of the unit to permit connection
to a minimum No. 6 AWG (13.3 mm2) solid bonding conductor between this point and any metal equipment, metal
enclosures of electrical equipment, metal water pipes, or conduit within 5 feet (1.5 meters) of the unit as needed to
comply with local requirements.
•
Install at least 5 feet (1.5 meters) from wall of pool. Install ozone generator no less than one (1) foot above
maximum water level to prevent water from contacting electrical equipment. Install in accordance with the installation
instructions.
•
Follow all applicable electrical codes.
•
Electric shock hazard. Be sure to turn power OFF and disconnect from power source before any service work is
performed. Failure to do so could result in serious injury or death.
•
The Solar Eclipse must be installed in an outdoor location, or indoors in a forced air ventilated room, and installed so
that the orientation is exactly as shown in Figure 3. Install to provide water drainage of generator to protect electrical
components.
•
Mount the Solar Eclipse so that it is inaccessible to anyone in the pool. Never attempt any servicing while unit is wet.
•
Warning - Short-term inhalation of high concentrations of ozone and long term inhalation of low concentrations of
ozone can cause serious harmful physiological effects. DO NOT inhale ozone gas produced by this device.
•
For your safety, do not store or use gasoline, chemicals or other flammable liquids or vapors near this or any
other appliance.
•
To maintain cosmetic integrity, protect this unit from direct prolonged sunlight exposure.
•
To reduce the risk of injury, do not permit children to use this product, unless they are closely supervised at all times.
•
ENVIRONMENTAL NOTICE - Hg-Lamp CONTAINS MERCURY. Manage in accordance with disposal laws.
See: www.lamprecycle.org
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
4A. System Electromechanical Overview ...................... 3
4B. System Maintenance .............................................. 4
4C. Ozone Module Servicing ......................................... 4
4D. UV Reactor Service & Maintenance ....................... 5
SECTION 5 Trouble Shooting .........................6
6A. Contact Information ................................................. 7
6B. Ordering Information ............................................... 7
6C. Standard Replacement Parts List ........................... 7
Appendix A: Installation Plumbing ................................. 8
Warranty ........................................................................ 9
