SERVICE MANUAL

Ver. 1.3 2009.06
• HCD-ZUX10D is the tuner, deck, DVD
and amplifier section in LBT-ZUX10D.
Amplifier section
The following are measured at AC 120, 127,
220, 240V 50/60 Hz
Power Output (rated):
170 W + 170 W (6 Ω, 1 kHz, 1% THD)
RMS output power (reference)
Front speaker:
260 W + 260 W (per channel at 6 Ω,
1 kHz, 10% THD)
Center speaker:
80 W (per channel at 6 Ω, 1 kHz,
10% THD)
Surround speaker:
260 W + 260 W (per channel at 6 Ω,
1 kHz, 10% THD)
Inputs
VIDEO INPUT:
VIDEO: 1 Vp-p, 75 ohms
AUDIO L/R: Voltage 250 mV,
impedance 47 kilohms
TV/SAT AUDIO IN L/R:
Voltage 250 mV/450 mV, impedance
47 kilohms
MIC 1 or 2:
Sensitivity 1 mV, impedance
10 kilohms
Sony Corporation
9-887-800-04
Audio&Video Business Group
2009F04-1
Published by Sony Techno Create Corporation
© 2009.06
HCD-ZUX10D
Model Name Using Similar Mechanism
DVD Section
CD Mechanism Type
Optical Pick-up Name
Tape Section
Model Name Using Similar Mechanism
SPECIFICATIONS
Outputs
AUDIO OUT:
Voltage 250 mV, impedance 1 kilohm
VIDEO OUT:
Max. output level 1 Vp-p, unbalanced,
Sync. negative load impedance
75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
P
/C
: 0.7 Vp-p, 75 ohms
B
B
P
/C
: 0.7 Vp-p, 75 ohms
R
R
S VIDEO OUT:
Y: 1 Vp-p, unbalanced, Sync. negative
C: 0.286 Vp-p, load impedance
75 ohms
PHONES:
accepts headphones of 8 ohms or more
SUBWOOFER OUT:
Voltage 1 V, impedance 1 kilohm
E Model
Australian Model
HCD-GNZ777D/GNZ888D
CDM74HF-DVBU101
KHM-313CAB/C2NP
HCD-GN1100D
– Continued on next page –
DVD DECK RECEIVER

Advertisement

Table of Contents

   Related Manuals for Sony HCD-ZUX10D

   Summary of Contents for Sony HCD-ZUX10D

  • Page 1: Service Manual

    HCD-ZUX10D SERVICE MANUAL E Model Australian Model Ver. 1.3 2009.06 • HCD-ZUX10D is the tuner, deck, DVD and amplifier section in LBT-ZUX10D. Model Name Using Similar Mechanism HCD-GNZ777D/GNZ888D DVD Section CD Mechanism Type CDM74HF-DVBU101 Optical Pick-up Name KHM-313CAB/C2NP Tape Section...
  • Page 2 COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
  • Page 3 HCD-ZUX10D Ver. 1.2 Notes on chip component replacement NOTES ON LASER DIODE EMISSION CHECK • Never reuse a disconnected chip component. The laser beam on this model is concentrated so as to be focused on • Notice that the minus side of a tantalum capacitor may be the disc reflective surface by the objective lens in the optical pick- damaged by heat.
  • Page 4 HCD-ZUX10D Ver. 1.3 MODEL IDENTIFICATION PLAYABLE DISCS Type Characteristics Logo – BACK PANEL – DVD VIDEO • DVD VIDEO • DVD-R*/-RW*/+R/+RW in DVD VIDEO format * also in video mode VR mode • DVD-R/-RW in VR (Video Recording) mode VIDEO CD •...
  • Page 5: Table Of Contents

    HCD-ZUX10D TABLE OF CONTENTS SERVICING NOTES 7-11. Schematic Diagram – Main Section (1/4) – ....48 7-12. Schematic Diagram – Main Section (2/4) – ....49 Loading Panel ..............6 7-13. Schematic Diagram – Main Section (3/4) – ....50 7-14.
  • Page 6: Servicing Notes

    HCD-ZUX10D SECTION 1 SERVICING NOTES LOADING PANEL 3 loading panel gear (shaft) 1 Turn the gear (shaft) in the direction of the arrow.
  • Page 7: General

    HCD-ZUX10D SECTION 2 GENERAL This section is extracted from instruction manual. Guide to parts and controls This manual mainly explains operations using the remote, but the same operations can also be performed using the buttons on the unit having the same or similar names.
  • Page 8 HCD-ZUX10D M MIC 1/2 LEVEL (pages 57, 65, 1 "/1 (on/standby) (pages 18, 19, 20, 54, 77, 78, 84) Press to turn the system on or off. Turn to adjust the microphone volume. B BEAM MODE (page 71) Press to change the lighting effect of ECHO LEVEL (page 65) a beam.
  • Page 9 HCD-ZUX10D Z AMP MENU (page 70) e; DISC 1 ~ 3 (page 28) Press to change the spectrum Press to select a disc or switch to analyser display, adjust the DVD function from another source. brightness of the display and built-in...
  • Page 10 HCD-ZUX10D es PRESET –/+ (page 53) Press to select a preset station. ./> (go backward/go forward) (pages 27, 38, 56, 84) Press to select a track, chapter or DivX video file. TUNING –/+ (pages 53, 54) Press to tune in a radio station.
  • Page 11 HCD-ZUX10D Display RELAY A Indicators for the disc tray (page 27). K Indicators for the BEAT BLEND “ ” lights up when the disc is mode (page 63). selected. “ ” lights up when there is L Indicators for the X-ROUND mode a disc on the disc tray.
  • Page 12 HCD-ZUX10D T Indicates the selected play mode C DISC SKIP (page 28) (page 31). Press to select the next disc. “SHUF” lights up when Shuffle Play D FUNCTION +/– (pages 27, 53, is activated. “PROGRAM” lights up 55, 76) when Program Play is activated.
  • Page 13 HCD-ZUX10D O TV CH +/– (page 22) R V/v/B/b (pages 23, 31, 53, 66, Press to select a TV channel. Press to select the settings. PRESET +/– (page 53) ENTER (pages 23, 31, 53, 58, Press to select a preset station.
  • Page 14 HCD-ZUX10D 3 PAD A (page 63) * The numeric button 5, TV VOL +, VOLUME + and H buttons have a tactile dot. Use the PAD B (page 63) tactile dot as a reference when operating the Press to add percussion sound.
  • Page 15: Disassembly

    HCD-ZUX10D SECTION 3 DISASSEMBLY Note: Disassemble the unit in the order as shown below. 3-1. SIDE R PANEL, SIDE L PANEL (Page 16) 3-6. TAPE MECHANISM DECK (Page 18) 3-2. TOP CASE SECTION (Page 16) 3-7. HOLDER (TC-L), HOLDER (TC-R) (Page 19) 3-3.
  • Page 16: Side R Panel, Side L Panel

    HCD-ZUX10D Note: Follow the disassembly procedure in the numerical order given. 3-1. SIDE R PANEL, SIDE L PANEL 0 side L panel 7 screw (case 3 TP2) 8 three screws (+BVTP 3 × 8) 3 three screws (+BVTP 3 × 8)
  • Page 17: Back Panel Section

    HCD-ZUX10D 3-3. BACK PANEL SECTION 4 two screws 6 three screws (+BVTP 3 × 8) (+BVTP 3 × 8) 7 three screws (+BVTP 3 × 8) 8 four screws 5 PRIMARY board (+BVTP 3 × 8) 1 wire (flat type) (9 core)
  • Page 18: Front Panel Section

    HCD-ZUX10D 3-5. FRONT PANEL SECTION 2 screw 4 screw (+BVTP 3 × 8) (+BVTP 3 × 8) 3 screw (+BVTP 3 × 8) 9 CN901 (5P) 5 CN602 (4P) 8 CN502 (5P) 1 wire (flat type) (17 core) (CN100) 0 front panel section 6 five screws (+BVTP 3 ×...
  • Page 19: Holder (tc-l), Holder (tc-r)

    HCD-ZUX10D 3-7. HOLDER (TC-L), HOLDER (TC-R) 5 spring (B) 2 spring (A) 1 damper 4 damper top case assy 6 holder (TC-R) 3 holder (TC-L) 3-8. POWER AMP SECTION 7 two screws 4 two screws 6 two screws (+BVTP 3 × 8) (+BVTP 3 ×...
  • Page 20: Main Board

    HCD-ZUX10D 7 CN252 (2P) 3-9. MAIN BOARD 8 CN251 (5P) 6 wire (flat type) (21 core) 4 wire (flat type) (13 core) (CN105) (CN521) 5 wire (flat type) (13 core) qa CN551 (5P) (CN104) 1 wire (flat type) (17 core)
  • Page 21: Illumination Board, Vol Board

    HCD-ZUX10D 3-11. ILLUMINATION BOARD, VOL BOARD 8 two screws (+BVTP 2.6 (3CR)) 6 two screws (+BVTP 2.6 (3CR)) 7 ILLUMINATION board 9 VOL board 4 knob (jog) 3 bracket (jog) 5 gear (encoder) 2 nut 1 knob (volume) 3-12. MIC BOARD, VR BOARD, BASE R LED BOARD...
  • Page 22: Hp-video Board, Base L Led Board

    HCD-ZUX10D 3-13. HP-VIDEO BOARD, BASE L LED BOARD 1 two screws (+BVTP 2.6 (3CR)) 4 bracket 7 screw 9 two screws (+BVTP 2.6 (3CR)) (+BVTP 2.6 (3CR)) 3 HP-VIDEO board 0 sheild plate assy qa BASE L LED board 5 two screws (+BVTP 2.6 (3CR))
  • Page 23: Bracket (trans)

    HCD-ZUX10D 3-15. BRACKET (TRANS) 2 two screws (+BVTP 3 × 8) 6 bracket (trans) 1 two screws (+BV 3 (3-CR)) 3 two screws (+BVTP 3 × 8) 5 CN201 (6P) 4 wire (flat type) (24 core) (CN101) 3-16. DMB16 BOARD, VIDEO BOARD...
  • Page 24: Dvd Mechanism Deck

    HCD-ZUX10D 3-17. DVD MECHANISM DECK 6 screw (+BVTP 3 × 10) 5 screw (+BVTP 3 × 10) 7 CDM cover assy 4 screw (+BVTP 3 × 10) 9 BU fitting screw qa DVD mechanism deck 0 dust sheet (bottom) 3 cover (BU)
  • Page 25: Optical Pick-up

    HCD-ZUX10D 3-19. OPTICAL PICK-UP 5 two insulators 2 two insulator screws 3 two insulator screws 6 optical pick-up 4 two insulators 7 holder (310) 1 floating screw (+PTPWH M2.6) 3-20. SENSOR BOARD 1 floating screw (+PTPWH M2.6) 2 t ray 8 s crew (+BTTP (M2.6))
  • Page 26: Motor (tb) Board

    HCD-ZUX10D 3-21. MOTOR (TB) BOARD 2 stopper table 1 stopper 7 t able motor assy (M741) 3 wire (flat type) (5 core) (CN742) 8 MOTOR (TB) board 6 Remove the two solderings of motor. 5 two screws (+BTTP (M2.6)) 3-22. MOTOR (LD) BOARD 3 two screws (+BTTP (M2.6))
  • Page 27: Test Mode

    HCD-ZUX10D SECTION 4 TEST MODE [PANEL TEST MODE] • Check of Amplifier 1. Press [EQ BAND/MEMORY] button repeatedly until a message • This mode is used to check the fluorescent indicator tube, LEDs, keys, [MASTER VOLUME] jog, [OPERATION DIAL] “GEQ MAX” appears on the fluorescent indicator tube. The jog, [X-ROUND] jog, model, destination and software version.
  • Page 28 HCD-ZUX10D [TUNER STEP CHANGE] [DVD COLOR SYSTEM] • The step interval of AM channels can be toggled between 9 • This mode let you change the color system of the video output kHz and 10 kHz. This mode is not available for Saudi Arabian from PAL to NTSC or vice-versa.
  • Page 29 HCD-ZUX10D Ver. 1.1 3. The fluorescent indicator tube displays “VATB F APC”. [DVD SERVICE MODE] “V” represents Conventional VACS (Triggered by signal level). • This mode let you make diagnosis and adjustment easily by “T” represents Thermal VACS NEO (Triggered by using the remote commander and the TV.
  • Page 30 HCD-ZUX10D Ver. 1.1 2. Select “3. Manual Adjustment” by pressing the [3] button on • Check Emergency History the remote commander. The following screen appears on the To check the emergency history, please follow the following on-screen display. procedure. 1. From the Top Menu of Remocon Diagnosis Menu, select “3.
  • Page 31 HCD-ZUX10D Ver. 1.1 • Parameter of error code To return to the Top Menu of Remocon Diagnosis Menu Press [0] button on the remote commander. This is the detail of error code. • Check Version Information Example of Error code To check the version information, please follow the following 1.
  • Page 32: Mechanical Adjustments

    HCD-ZUX10D SECTION 5 SECTION 6 MECHANICAL ADJUSTMENTS ELECTRICAL ADJUSTMENTS • Precaution DECK SECTION 0 dB = 0.775 V 1. Clean the following parts with a denatured alcohol-moistened swab : 1. Demagnetize the record/playback head with a head record/playback heads pinch roller demagnetizer.
  • Page 33 HCD-ZUX10D 3. Mode: Playback 0 dB = 1 µV TUNER SECTION test tape JACK board [FM TUNE LEVEL CHECK] P-4-A100 oscilloscope PHONES jack (10 kHz, − 10 dB) (J904) FM signal generator OUT (75 Ω ) waveform of oscilloscope in phase 45 °...
  • Page 34 HCD-ZUX10D Ver. 1.1 Connecting Location: DMB16 board (Side A) DVD SECTION DMB16 BOARD When the optical pick-up assy is replaced, perform the “Execute CN105 pin 3 (GND) (SIDE A) CN105 pin 6 (RFMON) IOP Measurement”. Execute IOP Measurement (See page 29)
  • Page 35: Diagrams

    HCD-ZUX10D SECTION 7 DIAGRAMS 7-1. BLOCK DIAGRAM – RF/SERVO Section – DVDRFIP DVDA DVDB DETECTOR DVDC DVDD 8 NA 9 NB CD/DVD RF AMP, OPTICAL PICK-UP FOCUS/TRACKING ERROR AMP VIDEO BLOCK DVD SYSTEM PROCESSOR SYSRESET SECTION DIGITAL SERVO PROCESSOR (Page 36)
  • Page 36: Block Diagram - Video Section

    HCD-ZUX10D 7-2. BLOCK DIAGRAM – VIDEO Section – VIDEO SELECTOR, BUFFER J900 (1/2) IC800 J802 VIDEO VIDEO VIDEO INPUT 75Ω VIDEO DRIVER IC801 CVBS IN CVBSOUT 23 C-IN S-DC OUT 27 J801 Y-IN C OUT 26 YUV3 S VIDEO CY-IN...
  • Page 37: Block Diagram - Tape/tuner Section

    HCD-ZUX10D 7-3. BLOCK DIAGRAM – TAPE/TUNER Section – MAIN (Page 38) A FL SECTION MAIN J602 (2/2) (Page 38) EFFECTOR-L SECTION AUDIO OUT R-CH EFFECTOR (Page 39) BEAT SECTION MAIN (Page 38) MIC SIG SECTION LINK-L MAIN (Page 38) SECTION...
  • Page 38: Block Diagram - Main Section

    HCD-ZUX10D 7-4. BLOCK DIAGRAM – MAIN Section – MIC SIG MIC AMP RV501 TAPE/TUNER IC905 SECTION MIC 1 ECHO AMP (1/2) MUSIC L+R (Page 37) LEVEL IC507 MIC AMP J902 IC506(1/2) MIX OUT MIC 1 MIC IN SCORE LEVEL SCORE...
  • Page 39: Block Diagram - Effector Section

    HCD-ZUX10D 7-5. BLOCK DIAGRAM – EFFECTOR Section – MX AMP IC1505 INPUT-L OUTPUT-L MAIN MAIN SECTION SECTION R-CH OUTPUT-R INPUT-R R-CH (Page 38) (Page 38) DIGITAL DELAY IC1504 CLOCK CONTROL SWITCH CLOCK CONTROL SWITCH LPF1IN LPF2OUT 9 IC1503 IC1502 COM 3...
  • Page 40: Block Diagram - Amp Section

    HCD-ZUX10D Ver. 1.3 7-6. BLOCK DIAGRAM – AMP Section – TAPE/TUNER DBFB F/B SECTION J904 (Page 37) PHONES AUDIO POWER AMP IC600 D624 RY646 TAPE/TUNER FR L-IN SECTION TM601 (Page 37) FRONT SPEAKER R-CH OVER LOAD MUTE DETECT Q640,641 Q618,668...
  • Page 41: Block Diagram - Display/power Section

    HCD-ZUX10D Ver. 1.3 7-7. BLOCK DIAGRAM – DISPLAY/POWER Section – S901 – 903, S900 – 908, S922, LED+9V S905 – 908, S909 – 917, S937,947, 83 XI S918 – 923, S924 – 930, KEY0 X900 S964 – 961, 938, S939 – 947, S931...
  • Page 42 HCD-ZUX10D Ver. 1.3 • Note for Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: Note on Schematic Diagram: • X : parts extracted from the component side. • All capacitors are in µF unless otherwise noted. (p: pF) •...
  • Page 43 HCD-ZUX10D • Waveforms – DMB16 Board – – VIDEO Board – (DVD PLAY) – MAIN Board – IC102 6 (DVDRFIP) IC102 <z., (YUV3) IC801 2 (CIN) IC801 qs (CBIN) IC100 qa (XC-OUT) 1.2 Vp-p 2.8 Vp-p 1.2 Vp-p 0.7 Vp-p 600 mVp-p 32.768 kHz...
  • Page 44 HCD-ZUX10D • Circuit Boards Location FL board POWER LED board KARAOKE board LEFT KEY board CENTER L LED board MAIN board BEAT CREATOR board CENTER KEY board RIGHT KEY board CENTER R LED board VOL board X-ROUND board ILLUMINATION board •...
  • Page 45: Printed Wiring Boards - Driver Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-8. PRINTED WIRING BOARDS – DRIVER Section – : Uses unleaded solder. MAIN BOARD CN105 (Page 47) (DISC TRAY ADDRESS DETECT) S751 CN751 (OPEN/CLOSE DETECT) HCD-ZUX10D...
  • Page 46: Schematic Diagram - Driver Section

    HCD-ZUX10D • See page 84 for IC Block Diagrams. 7-9. SCHEMATIC DIAGRAM – DRIVER Section – IC B/D IC701 R702 R701 D701 C715 CN704 C751 CN721 M751 IC B/D IC712 R712 R713 CN701 CN705 C752 CN751 S751 D711 R711 MAIN...
  • Page 47: Printed Wiring Board - Main Section

    HCD-ZUX10D Ver. 1.3 • See page 44 for Semiconductor Location. • See page 44 for Circuit Boards Location. 7-10. PRINTED WIRING BOARD – MAIN Section – : Uses unleaded solder. PRIMARY BOARD TAPE MECHANISM CASSETTE-TAPE DECK-B DECK-A CN1200 DECK BLOCK...
  • Page 48: Schematic Diagram - Main Section (1/4)

    HCD-ZUX10D Ver. 1.3 • See page 43 for Waveforms. • See page 84 for IC Block Diagrams. • See page 91 for IC Pin Description of IC100. 7-11. SCHEMATIC DIAGRAM – MAIN Section (1/4) – NO100 Q101 EXCEPT IC B/D...
  • Page 49: Schematic Diagram - Main Section (2/4)

    HCD-ZUX10D Ver. 1.3 • See page 43 for Waveform. 7-12. SCHEMATIC DIAGRAM – MAIN Section (2/4) – Q256 C269 R264 R263 R262 CN380 Q202 Q203 Q253 Q252 R256 R255 C254 R299 R240 C245 C246 C203 C253 FB203 D257 Q255 R206...
  • Page 50: Schematic Diagram - Main Section (3/4)

    HCD-ZUX10D Ver. 1.3 • See page 85 for IC Block Diagrams. 7-13. SCHEMATIC DIAGRAM – MAIN Section (3/4) – (Page 48) (Page 49) CN550 (Page 54) Q550 IC B/D D550 D551 JR553 IC553 IC554 R550 CN551 D552 IC555 Q551 JW496...
  • Page 51: Schematic Diagram - Main Section (4/4)

    HCD-ZUX10D • See page 84 for IC Block Diagrams. 7-14. SCHEMATIC DIAGRAM – MAIN Section (4/4) – (Page 49) CN521 C520 C570 C521 C571 C522 C572 C573 C523 C440 C490 R521 R522 R571 R572 R525 R526 R575 R576 R529 R530...
  • Page 52: Printed Wiring Board - Dmb16 Section (1/2)

    HCD-ZUX10D Ver. 1.3 • See page 44 for Circuit Boards Location. 7-15. PRINTED WIRING BOARD – DMB16 Section (1/2) – : Uses unleaded solder. DMB16 BOARD (SIDE A) MY,SP MODEL C109 R212 CL206 R5017 C212 CL208 R5016 E2,AUS,EA MODEL C214...
  • Page 53: Printed Wiring Board - Dmb16 Section (2/2)

    HCD-ZUX10D Ver. 1.3 When IC103 on the DMB16 board are damaged, exchange the • See page 44 for Circuit Boards Location. 7-16. PRINTED WIRING BOARD – DMB16 Section (2/2) – new DMB16 board for the DMB16 board which IC damaged.
  • Page 54: Schematic Diagram - Dmb16 Section (1/6)

    HCD-ZUX10D 7-17. SCHEMATIC DIAGRAM – DMB16 Section (1/6) – DMB16 DMB16 BOARD (1/6) (Page 55) BOARD SW+5V (2/6) DMB16 (Page 56) BOARD SW+5V (3/6) DMB16 CN302 DMB16 DSEL (Page 58) BOARD BOARD SW+5V JL4701 R321 WIDE (5/6) (4/6) RGBSEL CN401...
  • Page 55: Schematic Diagram - Dmb16 Section (2/6)

    HCD-ZUX10D Ver. 1.3 • See page 87 for IC Block Diagrams. 7-18. SCHEMATIC DIAGRAM – DMB16 Section (2/6) – R3621 DMB16 BOARD (2/6) R3611 R3781 R3783 1.5k 3.9k ART- R3782 R3784 1.5k 3.9k ART+ C3783 C3784 330p 330p IC B/D...
  • Page 56: Schematic Diagram - Dmb16 Section (3/6)

    HCD-ZUX10D • See page 87 for IC Block Diagram. 7-19. SCHEMATIC DIAGRAM – DMB16 Section (3/6) – DMB16 BOARD (3/6) DMB16 (Page 59) BOARD RF+3.3V RF+3.3V (6/6) DMB16 (Page 54) BOARD SW+5V (1/6) IC107 TK11133CSCL-G R126 DMB16 (Page 54) BOARD SW+3.3V...
  • Page 57: Schematic Diagram - Dmb16 Section (4/6)

    HCD-ZUX10D Ver. 1.3 • See page 43 for Waveforms. • See page 94 for IC Pin Description of IC102. 7-20. SCHEMATIC DIAGRAM – DMB16 Section (4/6) – (Page 55) (Page 55) (Page 59) (Page 58) (Page 54) DMB16 BOARD (2/6)
  • Page 58: Schematic Diagram - Dmb16 Section (5/6)

    HCD-ZUX10D Ver. 1.3 When IC103 on the DMB16 board are damaged, exchange the • See page 87 for IC Block Diagrams. 7-21. SCHEMATIC DIAGRAM – DMB16 Section (5/6) – new DMB16 board for the DMB16 board which IC damaged. (Page 57)
  • Page 59: Schematic Diagram - Dmb16 Section (6/6)

    HCD-ZUX10D 7-22. SCHEMATIC DIAGRAM – DMB16 Section (6/6) – DMB16 BOARD (6/6) (Page 56) REG01 DMB16 BOARD REG02 (3/6) R231 0.5% FCS- FCS- R234 FCS+ DMB16 FCS+ DMB16 BOARD TRK+ BOARD SW+5V (3/6) TRK+ (1/6) R223 100k 0.5% TRK- (Page 56)
  • Page 60: Printed Wiring Boards - Hp-video/mic Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-23. PRINTED WIRING BOARDS – HP-VIDEO/MIC Section – : Uses unleaded solder. (Page 47) (Page 72) MAIN POWER AMP BOARD BOARD CN251 CN602 VR BOARD NO903 CN501 (Page 66) CN901 R1008...
  • Page 61: Schematic Diagram - Hp-video/mic Section

    HCD-ZUX10D • See page 90 for IC Block Diagram. 7-24. SCHEMATIC DIAGRAM – HP-VIDEO/MIC Section – C1002 C986 JR904 D919 C1010 R1023 C1000 R1013 C1003 R1021 C1008 J900 C999 CN901 JR1005 R1012 J902 IC905(2/2) R1004 C987 TP936 2.7k NJM4565M C1004...
  • Page 62: Printed Wiring Board - Karaoke Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-25. PRINTED WIRING BOARD – KARAOKE Section – : Uses unleaded solder. • Semiconductor Location Ref. No. Location C2011 C2010 C2009 C2006 D2002 D2003 D2003 D2006 D2007 D2008 C2008 R2009 R2016...
  • Page 63: Schematic Diagram - Karaoke Section

    HCD-ZUX10D 7-26. SCHEMATIC DIAGRAM – KARAOKE Section – C2015 R2032 R2035 R2028 R2029 IC2002(1/2) IC2002(2/2) R2031 R2034 R2036 R2030 R2000 C2000 R2001 C2001 CN2000 C2007 C2013 R2002 C2006 IC2000(2/2) R2010 IC2000(1/2) R2017 R2009 C2016 R2019 R2020 C2004 C2010 (Page 49)
  • Page 64: Printed Wiring Board - Video Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-27. PRINTED WIRING BOARD – VIDEO Section – : Uses unleaded solder. J800 J801 J802 COMPONENT S VIDEO VIDEO VIDEO OUT C819 C821 C817 C818 FB800 C823 C820 FB804 FB801 C825...
  • Page 65: Schematic Diagram - Video Section

    HCD-ZUX10D • See page 43 for Waveforms. 7-28. SCHEMATIC DIAGRAM – VIDEO Section – CN801 IC801 C800 C815 R802 FB800 C801 C816 J800 C814 R803 FB801 C802 C817 C813 R804 FB802 R800 C803 (Page 54) C804 R805 FB803 C812 C805...
  • Page 66: Printed Wiring Board - Vr Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-29. PRINTED WIRING BOARD – VR Section – : Uses unleaded solder. MAIN BOARD NO250 (Page 47) MIC BOARD NO916 (Page 60) (11) 1-872-720- ECHO LEVEL MIC 2 LEVEL MIC 1 LEVEL...
  • Page 67: Schematic Diagram - Vr Section

    HCD-ZUX10D • See page 89 for IC Block Diagrams. 7-30. SCHEMATIC DIAGRAM – VR Section – RV502 IC506(1/2) IC B/D C512 C510 CN502 C547 R538 JR500 C545 IC507 C524 R502 C523 CN501 IC B/D C544 R533 R532 R521 (Page 49)
  • Page 68: Printed Wiring Board - Center Amp Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-31. PRINTED WIRING BOARD – CENTER AMP Section – : Uses unleaded solder. C448 C443 R445 IC400 JW402 POWER AMP BOARD CN401 (Page 72) C493 R471 D400 R443 C447 R472 JW405...
  • Page 69: Schematic Diagram - Center Amp Section

    HCD-ZUX10D 7-32. SCHEMATIC DIAGRAM – CENTER AMP Section – IC400 C448 C443 NO403 R413 R412 R404 R443 C447 R410 R471 R470 C410 C470 C440 NO402 R445 (Page 73) R440 C446 R444 R472 C471 R427 JW410 C426 C442 C425 C445 Q470...
  • Page 70: Printed Wiring Board - Effector Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-33. PRINTED WIRING BOARD – EFFECTOR Section – : Uses unleaded solder. • Semiconductor MAIN Location BOARD CN300 Ref. No. Location (Page 47) R1525 R1501 D1502 D1503 D1504 (CHASSIS) C1570 IC1503...
  • Page 71: Schematic Diagram - Effector Section

    HCD-ZUX10D • See page 86 for IC Block Diagrams. 7-34. SCHEMATIC DIAGRAM – EFFECTOR Section – CN1502 C1570 IC B/D Q1507 L1500 R1504 IC1502 C1528 C1511 R1525 R1599 R1598 R1597 R1596 R1517 R1516 R1542 R1565 R1502 R1544 R1540 Q1513 Q1511...
  • Page 72: Printed Wiring Board - Power Amp Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-35. PRINTED WIRING BOARD – POWER AMP Section – : Uses unleaded solder. TM601 TM701 TM403 FRONT SPEAKER SURROUND SPEAKER CENTER SPEAKER • Semiconductor C648 Location R649 C683 EP690 R685 Ref. No.
  • Page 73: Schematic Diagram - Power Amp Section

    HCD-ZUX10D • See page 85 for IC Block Diagrams. 7-36. SCHEMATIC DIAGRAM – POWER AMP Section – CN702 R697 C637 R637 Q634 CN602 R634 R640 Q640 (Page 51) R683 R667 C635 R635 (Page 61) NO601 R638 Q641 Q681 C634 R682...
  • Page 74: Printed Wiring Board - Fl Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-37. PRINTED WIRING BOARD – FL Section – : Uses unleaded solder. S905 FL900 IC903 FLUORESCENT VACUUM DISPLAYS TV/SAT C903 S906 102 104 VIDEO JW1101 R1061 JW937 JW1052 JW1053 JW996 JW995...
  • Page 75: Schematic Diagram - Fl Section

    HCD-ZUX10D • See page 43 for Waveform. • See page 90 for IC Block Diagram. • See page 99 for IC Pin Description of IC900. 7-38. SCHEMATIC DIAGRAM – FL Section – FL900 C905 R942 Q910 Q911 Q912 Q913 C903...
  • Page 76: Printed Wiring Boards - Key Section (1/2)

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-39. PRINTED WIRING BOARDS – KEY Section (1/2) – : Uses unleaded solder. D900 – 902, 911 (CENTER L ILLUMINATION) (12) 1-872-708- CENTER KEY BOARD LEFT KEY BOARD NO909 (Page 79)
  • Page 77: Printed Wiring Boards - Key Section (2/2)

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-40. PRINTED WIRING BOARDS – KEY Section (2/2) – : Uses unleaded solder. D903 – 905, 910 (CENTER R ILLUMINATION) 1-872-709- (12) CENTER KEY BOARD NO910 X-ROUND X-ROUND (Page 79) MODE...
  • Page 78: Schematic Diagram - Key Section

    HCD-ZUX10D 7-41. SCHEMATIC DIAGRAM – KEY Section – Q900 NO951 NO952 R918 R919 R921 R922 R979 R980 R924 R925 D908 D906 R972 R952 R971 R970 Q902 NO902 R900 R901 R902 R903 R904 R905 R906 R907 R908 CN956 NO906 CN908 (Page 75)
  • Page 79: Printed Wiring Boards - Led Section (1/2)

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-42. PRINTED WIRING BOARDS – LED Section (1/2) – : Uses unleaded solder. • Semiconductor (VOL 4) (VOL 5) Location Ref. No. Location D903 E-11 D904 D-12 D905 C-12 D906 B-11...
  • Page 80: Printed Wiring Boards - Led Section (2/2)

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-43. PRINTED WIRING BOARDS – LED Section (2/2) – : Uses unleaded solder. • Semiconductor Location Ref. No. Location D900 D901 D902 D923 TUNER/ D924 BAND D925 D926 D927 D928 D901,902...
  • Page 81: Schematic Diagram - Led Section

    HCD-ZUX10D 7-44. SCHEMATIC DIAGRAM – LED Section – NO906 NO909 S924 S925 S926 S927 S928 S929 S930 (Page 78) R944 R945 R946 R947 R948 R949 R950 (Page 75) NO912 S939 S940 S941 S942 S943 S944 S945 S946 S947 S937 NO910...
  • Page 82: Printed Wiring Boards - Power Section

    HCD-ZUX10D • See page 44 for Circuit Boards Location. 7-45. PRINTED WIRING BOARDS – POWER Section – : Uses unleaded solder. S1200 VOLTAGE SELECTOR (Page 72) 120V POWER AMP 220V BOARD 230V–240V CN600 (CHASSIS) (CHASSIS) F1251 T1200 POWER TRANSFORMER F1271...
  • Page 83: Schematic Diagram - Power Section

    HCD-ZUX10D 7-46. SCHEMATIC DIAGRAM – POWER Section – F1241 FH1242 FH1241 FH1251 FH1252 F1251 NO1212 T1200 JW1235 FH1261 FH1262 F1261 CN1204 NO1211 S1200 CN1202 (Page 73) FH1271 F1271 FH1272 JW1236 RY1200 C1292 FH1281 FH1282 F1281 JW1204 CN1213 NO1203 FH1291 FH1292...
  • Page 84 HCD-ZUX10D • IC Block Diagrams IC701 BA6956AN (DRIVER Board) IC201 M61530FP-D60G (MAIN Board (4/4)) IC712 BA6956AN (DRIVER Board) FR LPFOUT 42 FL LPFOUT FR-CH FL-CH LPF AMP LPF AMP FR LPF IN 41 FL LPF IN FR INPUT FL INPUT...
  • Page 85 HCD-ZUX10D IC600 STK412-150C (POWER AMP Board) IC700 STK412-150C (POWER AMP Board) COM1 DRIVER DRIVER CURRENT CURRENT LIMITER LIMITER COM2 IC550 RT8H015C-T112-1 (POWER AMP Board) IC552 PQ09RD21J00H (MAIN Board (3/4)) IC553 PQ05RD11J00H (MAIN Board (3/4)) OVER LOAD DETECT DETECT VOUT...
  • Page 86 HCD-ZUX10D IC500 BU4052BCF-E2 (MAIN Board (4/4)) IC501 BU4052BCF-E2 (MAIN Board (4/4)) LEVEL BINARY TO 1 OF 4 CONVERTER DECODER WITH INHIBIT IC1501 M65850FP-E1 (EFFECTOR Board) IC1504 M65850FP-E1 (EFFECTOR Board) OSCILLATOR LPF2 1/2 VCC CLOCK AUTO MAIN 20KBIT RESET RESET CONTROL...
  • Page 87 HCD-ZUX10D IC301 AK4358VQ-L (DMB16 Board (2/6)) (FL) SDTI4 DATT ROUT1+ SDTI1 (FR) DATT ROUT1- AUDIO SDTI2 LOUT2+ INTERFACE (SL) DATT SDTI3 LOUT2- LRCK ROUT2+ (SR) DATT ROUT2- CONTROL LOUT3+ (FC) DATT REGISTER LOUT3- DATT ROUT3+ DATT (SW) CAD1 ROUT3- DCLK...
  • Page 88 HCD-ZUX10D IC101 MX29LV320CBTC70-CBA3-0701CE (DMB16 Board (5/6)) IC101 MX29LV320CBTC70-CBA3-0701GA (DMB16 Board (5/6)) IC101 MX29LV320CBTC70-CBA3-0701UC (DMB16 Board (5/6)) BYTE DQ15/A–1 CONTROL WRITE INPUT PROGRAM/ERASE STATE LOGIC HIGH VOLTAGE DQ14 MACHINE (WSM) DQ13 DQ12 FLASH X–DECODER ADDRESS RESET ARRAY STATE ARRAY LATCH DQ11...
  • Page 89 HCD-ZUX10D IC106 NJM2387ADL3(TE2) (DMB16 Board (5/6)) CURRENT LIMIT OVERVOLTAGE THERMAL PROTECTION PROTECTION BANDGAP REFERENCE CONTROL VOUT VADJ IC507 R2A15906SP (VR Board) MIX OUT VREF ECHO CONTROL VOLUME MIX NFIN ALC TC ECHO VOLIN ALC LC LPF2 OUT MIC IN LPF2 IN...
  • Page 90 HCD-ZUX10D IC1505 NJM4565M(TE2) (EFFECTOR Board) IC506 NJM4565M(TE2) (VR Board) IC905 NJM4565M(TE2) (MIC Board) 8 V+ A OUTPUT 7 B OUTPUT A -INPUT 6 B -INPUT A +INPUT 5 B +INPUT IC904 NJM2760V-TE2 (FL Board) BPF2OUT BPF1IN1 BPF1IN2 BUF1OUT RECOUT BPF4OUT...
  • Page 91 HCD-ZUX10D • IC Pin Descriptions IC100 M30622MEP-B18FPU0 (SYSTEM CONTROL) (MAIN BOARD (1/4)) Pin No. Pin Name Pin Description Channel 1 Next Command Ready status signal input from digital synthesizer ML2252-NCR1 ML2252 “H”: Ready Channel 2 playback status signal from digital synthesis ML2252 ML2252-BUSY2 “H”: Playback stop...
  • Page 92 HCD-ZUX10D Pin No. Pin Name Pin Description OPEN-SW Eject detection signal input from CDM [MTK-RST] USB-RTS0 Reset signal output to DVD TBL-SENSE Disc tray position detection signal input from CDM Disc tray status detection signal input from CDM Disc tray status detection signal input from CDM...
  • Page 93 HCD-ZUX10D Pin No. Pin Name Pin Description [CAPM-CNT]/ Capstan motor drive signal output I/O_EXP_CLK [A-TRIG]/ Deck A side trigger plunger drive signal output “H”: plunger on I/O_EXP RESET A-HALF Deck A cassette detection signal input FREQ Z-GROOVE Z-Groove frequency select control signal output “L”: Z-Groove...
  • Page 94 HCD-ZUX10D IC102 CXD9849R (CD/DVD RF AMP, FOCUS/TRACKING ERROR AMP, DVD SYSTEM PROCESSOR, DIGITAL SERVO PROCESSOR) (DMB16 BOARD (4/6)) Pin No. Pin Name Pin Description AGND — Ground DVDA AC coupled input path A DVDB AC coupled input path B DVDC...
  • Page 95 HCD-ZUX10D Pin No. Pin Name Pin Description SPFG Motor Hall sensor signal input DSEL Select signal output WIDE Wide signal output Volume control signal output MAMUTE MAMUTE signal output to System Controller Not used in this set. (Open) DVDD18 —...
  • Page 96 HCD-ZUX10D Pin No. Pin Name Pin Description DQMO DQM0 signal output to SD-RAM MREQ DQM signal input Data bus 7 from SD-RAM DVSS — Ground 117, 118 RD 6, 5 Data bus 6, 5 from SD-RAM DVSS — Ground 120, 121...
  • Page 97 HCD-ZUX10D Pin No. Pin Name Pin Description OCSW SEN signal input from System Controller/OCSW signal input Not used. (Open) — Not used in this set. (Open) CKSW CKSW signal input Not used in this set. (Open) — Not used. (Open) —...
  • Page 98 HCD-ZUX10D Pin No. Pin Name Pin Description RFVDD18 — Power Supply (+1.8 V) XTALO Oscillator signal output (27 MHz) XTALI Oscillator signal input (27 MHz) JITFO RF jitter meter output JITFN Negative input of operation amplifier for RF jigger meter PLLVSS —...
  • Page 99 HCD-ZUX10D IC900 MB90M407PF-G-153-BND (GC MICOM, FL DRIVE) (FL BOARD) Pin No. Pin Name Pin Description 1 to 8 G17 to G24 Grid drive signal output to the fluorescent indicator tube display 9, 10 P36, P35 Segment drive signal output to the fluorescent indicator tube display VSS-IO —...
  • Page 100: Exploded Views

    HCD-ZUX10D Ver. 1.3 SECTION 8 EXPLODED VIEWS NOTE: The components identified by mark • The mechanical parts with no reference • Abbreviation 0 or dotted line with mark 0 are number in the exploded views are not supplied. AUS : Australian model critical for safety.
  • Page 101: Front Panel Section (1)

    HCD-ZUX10D 8-2. FRONT PANEL SECTION (1) not supplied (POWER LED board) not supplied not supplied (FL board) (CENTER L LED board) not supplied not supplied (LEFT KEY board) FL900 not supplied (RIGHT KEY board) not supplied (CENTER R LED board) front panel section (2) Ref.
  • Page 102: Front Panel Section (2)

    HCD-ZUX10D 8-3. FRONT PANEL SECTION (2) not supplied not supplied (VR board) not supplied not supplied (BASE L LED board) not supplied not supplied (HP-VIDEO board) not supplied not supplied (MIC board) not supplied (BASE R LED board) not supplied front panel section (3) Ref.
  • Page 103: Front Panel Section (3)

    HCD-ZUX10D 8-4. FRONT PANEL SECTION (3) not supplied (BEAT CREATOR board) supplied with S950 not supplied (CENTER KEY board) not supplied (X-ROUND board) not supplied (VOL board) not supplied (ILLUMINATION board) not supplied not supplied Ref. No. Part No. Description Remark Ref.
  • Page 104: Top Case Section

    HCD-ZUX10D 8-5. TOP CASE SECTION not supplied not supplied (KARAOKE board) not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-095-348-11 HOLDER (TC-L) 4-231-825-01 CAM (B), HEART 2-669-613-01 SPRING, DETENT...
  • Page 105: Back Panel Section

    HCD-ZUX10D Ver. 1.3 8-6. BACK PANEL SECTION not supplied not supplied M891 not supplied (EFFECTOR board) TU901 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0 251 1-468-737-51 POWER, SWITCHING TU901 1-693-734-21 TUNER (FM/AM) (ANTENNA) (EXCEPT AUS)
  • Page 106: Chassis Section

    HCD-ZUX10D Ver. 1.3 8-7. CHASSIS SECTION not supplied (CENTER AMP board) not supplied not supplied T1200 not supplied F1241 not supplied F1251 (VIDEO board) F1261 M892 F1271 F1291 F1281 not supplied not supplied DVD mechanism deck not supplied not supplied...
  • Page 107: Dvd Mechanism Section (1)

    HCD-ZUX10D 8-8. DVD MECHANISM SECTION (1) (CDM74HF-DVBU101) M741 DVD mechanism section-2 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-218-253-42 SCREW (M2.6), +BTTP 4-243-820-01 GEAR (TABLE) 1-776-182-11 WIRE (FLAT TYPE) (5 CORE) 4-243-819-01 GEAR (GENEVA) 1-687-134-12 MOTOR (TB) BOARD...
  • Page 108: Dvd Mechanism Section (2)

    HCD-ZUX10D 8-9. DVD MECHANISM SECTION (2) (CDM74HF-DVBU101) RE701 not supplied M751 not supplied not supplied not supplied (DRIVER board) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-251-923-01 YOKE (310) 4-224-611-01 GEAR (LOADING B) 2-345-982-01 PULLEY A (310), CHUCKING...
  • Page 109: Electrical Parts List

    HCD-ZUX10D Ver. 1.3 SECTION 9 BASE L LED BASE R LED ELECTRICAL PARTS LIST NOTE: The components identified by mark • Due to standardization, replacements in the • SEMICONDUCTORS In each case, u : µ, for example: 0 or dotted line with mark 0 are parts list may be different from the parts uA..
  • Page 110 HCD-ZUX10D BEAT CREATOR CENTER AMP CENTER KEY Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark BEAT CREATOR BOARD < RESISTOR > ******************* 0 R404 1-217-637-00 FUSIBLE 1/4W F < CONNECTOR > R410 1-216-841-11 METAL CHIP 1/10W...
  • Page 111 HCD-ZUX10D Ver. 1.3 CENTER L LED CENTER R LED DMB16 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark CENTER L LED BOARD C102 1-125-837-11 CERAMIC CHIP 6.3V C105 1-126-947-11 ELECT 47uF ****************** C106 1-162-970-11 CERAMIC CHIP 0.01uF...
  • Page 112 HCD-ZUX10D Ver. 1.3 DMB16 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C174 1-162-970-11 CERAMIC CHIP 0.01uF C3705 1-107-826-11 CERAMIC CHIP 0.1uF C175 1-162-970-11 CERAMIC CHIP 0.01uF C3706 1-107-826-11 CERAMIC CHIP 0.1uF C176 1-162-970-11 CERAMIC CHIP 0.01uF...
  • Page 113 HCD-ZUX10D Ver. 1.3 DMB16 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark ET002 1-537-771-21 TERMINAL BOARD, GROUND Q3801 8-729-230-49 TRANSISTOR 2SC2712-YG ET003 1-537-771-21 TERMINAL BOARD, GROUND < RESISTOR > < FERRITE BEAD > R101 1-216-809-11 METAL CHIP...
  • Page 114 HCD-ZUX10D Ver. 1.3 DMB16 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R216 1-216-834-11 METAL CHIP 1/10W R1548 1-216-829-11 METAL CHIP 4.7K 1/10W R219 1-216-838-11 METAL CHIP 1/10W R1549 1-216-829-11 METAL CHIP 4.7K 1/10W R220 1-216-833-11 METAL CHIP...
  • Page 115 HCD-ZUX10D Ver. 1.3 DMB16 DRIVER Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R3738 1-216-829-11 METAL CHIP 4.7K 1/10W R5001 1-216-864-11 SHORT CHIP R3739 1-216-821-11 METAL CHIP 1/10W R5014 1-216-864-11 SHORT CHIP 0 (E2,E51) R3741 1-216-823-11 METAL CHIP 1.5K...
  • Page 116 HCD-ZUX10D DRIVER EFFECTOR Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R731 1-247-807-31 CARBON 1/4W C1574 1-162-965-11 CERAMIC CHIP 0.0015uF 10% R732 1-249-429-11 CARBON 1/4W C1577 1-126-947-11 ELECT 47uF R733 1-247-831-11 CARBON 1/4W C1584 1-104-658-11 ELECT...
  • Page 117 HCD-ZUX10D EFFECTOR Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R1516 1-216-833-11 METAL CHIP 1/10W R1596 1-216-833-11 METAL CHIP 1/10W R1517 1-216-833-11 METAL CHIP 1/10W R1597 1-216-833-11 METAL CHIP 1/10W R1519 1-216-840-11 METAL CHIP 1/10W R1598...
  • Page 118 HCD-ZUX10D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C982 1-119-941-11 ELECT 470uF 6.3V Q912 8-729-027-56 TRANSISTOR DTC143TKA-T146 C983 1-119-941-11 ELECT 470uF 6.3V Q913 8-729-027-56 TRANSISTOR DTC143TKA-T146 C984 1-162-970-11 CERAMIC CHIP 0.01uF Q914 8-729-027-43 TRANSISTOR DTC114EKA-T146...
  • Page 119 HCD-ZUX10D HP-VIDEO ILLUMINATION KARAOKE Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R1002 1-216-826-11 METAL CHIP 2.7K 1/10W ILLUMINATION BOARD R1060 1-216-845-11 METAL CHIP 100K 1/10W ******************* R1061 1-216-845-11 METAL CHIP 100K 1/10W R1062 1-216-845-11 METAL CHIP...
  • Page 120 HCD-ZUX10D Ver. 1.3 KARAOKE LEFT KEY MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C2006 1-126-160-11 ELECT LEFT KEY BOARD C2007 1-164-156-11 CERAMIC CHIP 0.1uF ************** C2008 1-162-961-11 CERAMIC CHIP 330PF C2009 1-124-589-11 ELECT 47uF <...
  • Page 121 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C112 1-100-566-11 CERAMIC CHIP 0.1uF C324 1-137-190-11 FILM 0.22uF C115 1-100-566-11 CERAMIC CHIP 0.1uF C325 1-126-960-11 ELECT C116 1-104-656-11 ELECT 2200uF 6.3V C326 1-100-566-11 CERAMIC CHIP 0.1uF...
  • Page 122 HCD-ZUX10D MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C410 1-126-964-11 ELECT 10uF C522 1-126-960-11 ELECT C411 1-162-964-11 CERAMIC CHIP 0.001uF C523 1-126-960-11 ELECT C412 1-126-964-11 ELECT 10uF C524 1-126-963-11 ELECT 4.7uF C413 1-162-964-11 CERAMIC CHIP 0.001uF...
  • Page 123 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark CN381 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P < CONNECTOR > CN382 1-569-927-11 SOCKET, CONNECTOR 9P * CN501 1-564-714-11 PIN, CONNECTOR (SMALL TYPE) 12P J603...
  • Page 124 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark JR350 1-216-864-11 SHORT CHIP Q300 8-729-023-22 TRANSISTOR 2SD2114K JR351 1-216-864-11 SHORT CHIP Q301 8-729-230-49 TRANSISTOR 2SC2712-YG JR400 1-216-296-11 SHORT CHIP Q302 8-729-023-22 TRANSISTOR 2SD2114K...
  • Page 125 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R110 1-216-833-11 METAL CHIP 1/10W R183 1-216-809-11 METAL CHIP 1/10W R111 1-216-851-11 METAL CHIP 330K 1/10W R184 1-216-809-11 METAL CHIP 1/10W R112 1-216-845-11 METAL CHIP...
  • Page 126 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R255 1-216-839-11 METAL CHIP 1/10W R324 1-216-833-11 METAL CHIP 1/10W R256 1-216-864-11 SHORT CHIP R328 1-216-821-11 METAL CHIP 1/10W R257 1-216-830-11 METAL CHIP 5.6K...
  • Page 127 HCD-ZUX10D Ver. 1.3 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R435 1-216-821-11 METAL CHIP 1/10W R527 1-216-821-11 METAL CHIP 1/10W R436 1-216-841-11 METAL CHIP 1/10W R529 1-216-841-11 METAL CHIP 1/10W R437 1-216-833-11 METAL CHIP...
  • Page 128 HCD-ZUX10D MAIN MOTOR (LD) MOTOR (TB) POWER AMP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R613 1-216-845-11 METAL CHIP 100K 1/10W < JACK > (EXCEPT AUS) R614 1-216-825-11 METAL CHIP 2.2K 1/10W J902 1-817-630-11 JACK (LARGE TYPE) (MIC 1)
  • Page 129 HCD-ZUX10D POWER AMP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C618 1-128-560-11 ELECT 22uF 100V D612 6-501-180-01 DIODE UDZW-TE17-18B C619 1-128-560-11 ELECT 22uF 100V D620 6-500-334-01 DIODE MC2836-T112-1 C634 1-104-665-11 ELECT 100uF D624 8-719-404-50 DIODE MA111-TX...
  • Page 130 HCD-ZUX10D POWER AMP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R609 1-216-843-11 METAL CHIP 1/10W R673 1-216-844-11 METAL CHIP 1/10W R610 1-216-843-11 METAL CHIP 1/10W R674 1-216-837-11 METAL CHIP 1/10W R611 1-216-839-11 METAL CHIP 1/10W...
  • Page 131 HCD-ZUX10D POWER AMP POWER LED PRIMARY RIGHT KEY Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < TERMINAL BOARD > < TRANSISTOR > TM403 1-780-473-11 TERMINAL BOARD (SPEAKER) 1P Q1200 8-729-230-49 TRANSISTOR 2SC2712-YG (CENTER SPEAKER) TM601 1-820-067-11 TERMINAL BOARD (SPEAKER) 2P <...
  • Page 132 HCD-ZUX10D SENSOR TRANS VIDEO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1-687-132-12 SENSOR BOARD C809 1-164-156-11 CERAMIC CHIP 0.1uF C810 1-164-156-11 CERAMIC CHIP 0.1uF ************* C812 1-126-916-11 ELECT 1000uF 6.3V < CONNECTOR > C813 1-126-916-11 ELECT 1000uF 6.3V...
  • Page 133 HCD-ZUX10D VIDEO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R807 1-216-809-11 METAL CHIP 1/10W C539 1-136-497-81 FILM 0.1uF R808 1-218-285-11 METAL CHIP 1/10W C541 1-162-969-11 CERAMIC CHIP 0.0068uF 10% R809 1-216-833-11 METAL CHIP 1/10W C542 1-115-416-11 CERAMIC CHIP 0.001uF...
  • Page 134 HCD-ZUX10D Ver. 1.3 X-ROUND Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark X-ROUND BOARD MISCELLANEOUS ************** *************** < CAPACITOR > 1-828-991-11 WIRE (FLAT TYPE) (17 CORE) 1-828-966-11 WIRE (FLAT TYPE) (11 CORE) C906 1-162-964-11 CERAMIC CHIP 0.001uF...
  • Page 135 HCD-ZUX10D MEMO...
  • Page 136: Revision History

    HCD-ZUX10D REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the top of the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2007.07 2007.08...

Comments to this Manuals

Symbols: 0
Latest comments:
  • Fajar Feb 15, 2020 02:39:
    Lampu power hidup tapi kalau di tekan tak bisa setar atau on
