Page 2: Table Of Contents
Contents Page 1. Items delivered 2. General product information 3. Tips for mounting 4. System overview 5. Connecting and operating 6. Internal adjustments 7. Troubleshooting 8. Technical specifications 9. Technical Support 10. Your notes... -
Page 3: Items Delivered
General product information Thevideo distributor guarantees stable transmission quality of branched (distributed) video signals. The V-DA-8-16 can be used for either 2 sets of video input to 8 video outputs (jumper setting), or 2 sets of 2 video inputs to 4 video outputs or 4 video input to 2 video outputs. -
Page 4: System Overview
System overview Configuration options:... -
Page 5: Connecting And Operating
2 x 1 input 4 x 1 input 8 x 1 input NOTE: All jumper and strap configurations of the V-DA-8-16 outputs leave all inputs enabled. Therefore, verify that all extra inputs are unused. Using multiple inputs will result in distorted video on the outputs. -
Page 6: Internal Adjustments
Factory setting: The V-DA-8-16 is set to 2 video inputs to each 8 video outputs. To make the adjustments mentioned below, open the housing. To change to mode 4 (8) video inputs = 8 x 2 video outputs (V-DA-8-16), please proceed as follows: disconnect the unit from power supply... -
Page 7: Troubleshooting
1: off 2: on Troubleshooting... - Page 8 Error Cause 1. The jumper on the circuit board is Video outputs are not all set to duplicated number of video available inputs/outputs (e.g. 1 video input 6 video outputs) 1. These distortions are caused by One or several monitors hum in the picture which is a re- have stripes in the picture sult of connecting several moni-...
-
Page 9: Technical Specifications
Technical specifications V-DA-8-16 Purpose video distributor (amplifier) 8 x 1 / 4 x 1 Number of video inputs or 2 x 1 8 x 2 / 4 x 4 Number of video out- or 2 x 8 puts 20 MHz / - 3 dB... -
Page 10: Technical Support
Technical Support Should you have any problems during installation you can reach our Technical Hotline under following telephone number: +1-800-34- VICON (+1-800-348-4266) -
Page 11: Your Notes
Your notes...
