Accelero Mono Plus
Dear Customer,
Thank you for choosing the Accelero Mono Plus.
The Mono Plus is an upgrade cooler with a good cooling/noise
ratio at a compact size and thus does not just offer superb GPU
temperatures but everything at a low noise level. A complete set
of VRM heatsinks and high performance thermal glue
completes this solution.
I hope you enjoy this GPU cooler and we at ARCTIC look
forward to further enriching your life with our products. If you
would like to share how you use ARCTIC's products please do
so at https://www.facebook.com/ARCTIC.en
ARCTIC is a fully carbon neutral company and your support
helps us to compensate every kilogram of CO we produce.
Thank You.
Sincerely,
Magnus Huber
ARCTIC CEO
Accessories
M2 Screws
x 4
Spacers (2 mm)
x 1
Mounting Plate x 2
Heatsinks
x 11
Welcome Guide
support.arctic.ac/monoplus
Washers (Red)
x 4
Spacers (4 mm)
x 1
x 2
x 4
Spacers (1 mm)
x 4
Thermal Adhesive
(3 g)
4-pin Fan Power Adapter
x 1
x 4
2
x 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arctic accelero mono plus
Summary of Contents for Arctic accelero mono plus
- Page 1 VRM heatsinks and high performance thermal glue completes this solution. I hope you enjoy this GPU cooler and we at ARCTIC look forward to further enriching your life with our products. If you would like to share how you use ARCTIC's products please do so at https://www.facebook.com/ARCTIC.en...
- Page 2 Please ensure that the fan connector pin assignment on your VGA board is in accordance with the following table. If your power socket does not come with 4 pins, please refer to the usage of 4-pin Fan Power Adapter at arctic.ac/4pins. Main Cable Set Pin No.
- Page 3 ⑤ 58.4 x 58.4 mm 2.0 mm NVIDIA GeForce: GTX 970, 960, 760, 670, 660Ti, 660, 650 Ti Boost Note: This table is for reference only. Please refer to your own VGA card holes during installation. Updated information is available at arctic.ac/amp...
- Page 4 M2 Scerws x 4 Spacers (1 mm) Spacers (2 mm) Washers (Red) M2 Scerws x 4 Spacers (2 mm) Spacers (4 mm) Washers (Red) Squeeze out all the glue with pliers. Tips of Applying Thermal Adhesive Since the thermal adhesive can be applied once only, fit the cooler to the card with the heatsinks accurately positioned before you apply the thermal adhesive.
- Page 5 Heasinks Heatsinks Heatsinks Apply Thermal Adhesive on all VR and RAM components. Heatsinks Installation of Accelero Mono Plus M2 Scerws x 4 X: < 55 mm X: < 55 mm X: 55 mm - 65 mm X: 55 mm - 65 mm X: >...
- Page 6 ARCTIC (HK) Ltd. In no event shall ARCTIC, its directors or employees be liable for any indirect damages, incidental or consequential damages...
