(continued from previous page)
Dealer Settings > Tablet > System Settings
one midnight to the next. For example, 3:23 pm would be
displayed as "15:23".
Select date format: Tap to open a dialog that allows the
selection of the following date formats:
• Normal (12/31/2011) (Month/Day/Year)
• 12/31/2011 (Month/Day/Year)
• 31/12/2011 (Day/Month/Year)
• 2011/12/31 (Year/Month/Day)
Display - Allows changes to the IBR-ITAB display screen.
Brightness: Tap to open a sliding status bar control. In-
crease or decrease the screen brightness by sliding your
finger left or right across the status bar.
Auto-rotate screen: (Not Used; do not check this selec-
tion).
Animation: Tap to open a pull-down menu where you can
select "No animations" to disable all optional animation ef-
fects, "Some animations" to enable animated transitions
for some effects, or "All animations" for all supported ef-
fects including screen to screen navigation attributes. Note:
The "No animations" setting does not control animation in
all applications.
Screen timeout: Specifies how much user idle time (IBR-
ITAB is operational but not being used) must elapse before
the screen dims. The default setting is "never". Note:
When this feature is enabled and the screen dims, the IBR-
ITAB also enters "sleep mode", an inactive state to save
power. To re-awaken, touch any non-screen button.
Screen timeout selections include 15 seconds, 30 seconds,
1 minute, 2 minutes, 10 minutes, 30 minutes and never.
TV Mode: (Reserved for future use)
TV Resolution: (Reserved for future use)
TV HDCP: (Reserved for future use)
Language - Tap to select the language of the IBR-ITAB menus.
Sound - Controls sound intensity and feedback settings.
Volume: Tap to open a dialog containing sliding status bar
controls to set the Media volume, Alarm volume and Notifi-
cation volume intensity.
Feedback
Audible selection: Check to play a sound when certain
icons, keys, buttons and other onscreen items are
touched.
Screen lock sounds: Check to play sounds when the
IBR-ITAB display screen is locked or unlocked.
Haptic feedback: Check to briefly vibrate the IBR-ITAB
when certain icons, keys, buttons and other onscreen
items are touched (unavailable with some models)
Dealer Settings > Tablet > Auto Task Killer
Check to automatically kill all unnecessary tasks listed in the
Task Killer list during an alarm or other emergency situation.
Tasks include applications currently in use, and those run-
ning in the background ("hidden" tasks running "behind the
scenes"), such as operating system and network communi-
cation processes. See OI376, MENU BUTTON, Task Kil-
ler for more information.
6
Dealer Settings > Tablet > Restore Factory
Settings
Tap to restore the IBR-ITAB to the settings originally set at
the factory. Thus the IBR-ITAB is returned to its original
"out of box" condition.
Dealer Settings > Tablet > Update
Update Server Address: Displays the IP Address and Port
number used by the network server when the menu selec-
tion Check For Updates (described below) is tapped.
Source: Select the source of the new firmware files from
the following three selections:
• Internet: Select if the new firmware update is located
on the Internet;
• SD Card: Select if the new firmware update is located
on a secure digital microSD flash memory card, and
you wish to use the microSD Card Slot located on the
side of the IBR-ITAB. Note: The update file must be
placed in a folder named "napco" (case sensitive)
located in the top root directory.
"microSD" card format is also called "TransFlash";
• USB Drive: Select if the new firmware update is lo-
cated on USB memory (such as a thumb drive, portable
hard drive, memory stick, etc.), and you wish to use the
USB Socket located on the side of the IBR-ITAB.
Note: The update file must be placed in a folder
named "napco" (case sensitive) located in the top
root directory.
Check for Updates: Tap to automatically check to see if a
newer version of the IBR-ITAB firmware is available from
the location specified in the "Source" menu item (described
above). If a newer version is available, follow the on-screen
prompts to load the firmware update files, as necessary.
Current Version: Displays the current version number of
the IBR-ITAB firmware.
Napco Market: (Reserved for future use).
Update Logo: Insert a USB thumb drive to add your logo
image to the Home Screen and Keypad Skin. The logo
must be named "logo.png" (case sensitive) and must be lo-
cated in a folder named "dealerLogo" (case sensitive) lo-
cated at the top root directory of the thumb drive. When this
logo is added successfully and later the logo is tapped, the
IBR-ITAB opens its default browser to the webpage speci-
fied in the Update Infopage menu selection, detailed below.
Note: Although the IBR-ITAB searches for the specific file
name "logo.png", the image file itself may be a .png, .bmp
or .jpeg format. However, the file must be re-named "logo.
png".
Update Infopage: Insert a USB thumb drive to add an im-
age that will display website or other corporate information.
The file must be named "dealer.png" (case sensitive) and
must be located in a folder named "dealerLogo" (case sen-
sitive) located at the top root directory of the thumb drive.
When a logo is added to the Home Screen and Keypad
Skin using the Update Logo menu selection (see above)
and this logo is later tapped, the "dealer.png" image file will
appear enlarged on the IBR-ITAB screen.
Dealer Settings > Tablet > Password
Configuration
Allows you to change the password used to access the IBR-
Note: The
