Quick Start Guide
D103556X012
Figure 23. FIELDVUE DVC6200 with Position Transmitter or Discrete Switch, Field Wiring Schematic
AO
4 - 20 mA
AI
8-30 VDC
POWERED
AO
4 - 20 mA
DI
MAX 30V
GE61668
POSITION TRANSMITTER
DISCRETE SWITCH
DVC6200 Digital Valve Controllers
January 2017
29
