S/M No. :G6C4R5S001
Service Manual

Microwave Oven

Model: KQG-6C4R5S
KQG-6C5R5S
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center .
Apr. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KQG-6C4R5S and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo KQG-6C4R5S

Summary of Contents for Daewoo KQG-6C4R5S

  • Page 1: Microwave Oven

    S/M No. :G6C4R5S001 Service Manual Microwave Oven Model: KQG-6C4R5S KQG-6C5R5S Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center .

  • Page 2: Table Of Contents

    (e) A microwave leakage check to verify compliance with the Federal performance standard should be per- formed on each oven prior to release to the owner. TABLE OF CONTENTS SAFETY AND PRECAUTIONS..................................2 SPECIFICATIONS ......................................3 EXTERNAL VIEW (KQG-6C4R5S)................................4 INSTALLATION ......................................8 OPERATIONS AND FUNCTIONS................................9 DISASSEMBLY AND ASSEMBLY................................10 INTERLOCK MECHANISM AND ADJUSTMENT...........................20 TROUBLESHOOTING GUIDE...................................21...

  • Page 3: Safety And Precautions

    SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) (1) A broken door hinge.

  • Page 4: Specifications

    SPECIFICATIONS MODEL KQG-6C4R5S / KQG-6C5R5S POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING MICROWAVE 1200 W POWER GRILL 1050 W CONSUMPTION COMBINATION 2200 W MICROWAVE ENERGY OUTPUT 800W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (WXHXD) 465X279X384mm CAVITY DIMENSIONS (WXHXD) 290X220X306mm NET WEIGHT APPROX.

  • Page 5: External View (Kqg-6C4R5S)

    EXTERNAL VIEW (KQG-6C4R5S) 1. OUTER DIMENSION 2. FEATURE DIAGRAM 1 Door seal - Door seal maintains the microwave energy 8 Roller guide - This must always be used for cooking within the oven cavity and prevents microwave leakage. together with the glass cooking tray.
  • Page 6 EXTERNAL VIEW (KQG-6C5R5S) 1. OUTER DIMENSION 2. FEATURE DIAGRAM 1 Door seal - Door seal maintains the microwave energy 8 Roller guide - This must always be used for cooking within the oven cavity and prevents microwave leakage. together with the glass cooking tray. 2 Cover Heater 9 Glass cooking tray - Made of special heat resistant glass.
  • Page 7 3. CONTROL PANEL (KQG-6C4R5S) w Auto cook - Used to cook using a program or to i Start/Express cook - Used to start the oven operation reheat. and also increase the reheat time by 30 seconds. e Micro Power - Used to set power level.
  • Page 8 (KQG-6C5R5S) w Auto cook - Used to cook using a program or to i Start/Express cook - Used to start the oven oper- reheat. ation and also increase the reheat time by 30 sec- onds. e Micro Power - Used to set power level. o Dial knob - Used to set the time and weight.

  • Page 9: Installation

    This appliance is supplied with cable of special type, which, if samaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a Qualified Person. 6. Examine the oven after unpacking for any damage such as: A misaligned door, broken door or a dent in cavity.

  • Page 10: Operations And Functions

    OPERATIONS AND FUNCTIONS This section includes useful information about oven operation. Plug power supply cord into 230V AC 50Hz power outlet. When the STOP/CLEAR is pressed during the oven operation, the oven stops cooking and all information retained. To erase After placing the food in a suitable container, open the all information(except the present time), press the oven door and put it on the glass tray.

  • Page 11: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safety during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 12 1. To remove cabinet 1) Remove three screws on cabinet back. 2) Push the cabinet backward. 2. To remove door assembly 1) Remove a screws which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.

  • Page 13: T2S Trs 4X12 Mfzn

    3. To remove door parts. REF NO. PART CODE PART NAME DESCRIPTION Q'TY REMARK 3511614900 DECORATOR DOOR AS KOR-6Q4R5S 3512209000 FRAME DOOR ABS SG-0760D SG-175 3517009100 BARRIER-SCREEN *O SAN CR-5381 SMOG 3515204100 STOPPER HINGE *T AS KOR-63150S 3511719500 DOOR PAINTING AS KOR-6C0B5S 3517002800 BARRIER-SCREEN *I...
  • Page 14 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ • Loosen two screws on stopper hinge top, and then push the door to contact the door seal to oven front surface.

  • Page 15: T2S Trs 4X12 Mfzn

    5. To remove control panel parts. (KQG-6C4R5S) REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3513408400 KNOB VOLUME ABS SG-175 SG-0760D 3515501550 WINDOW DISPLAY SAN CR-5381 SMOG 3511614200 DECORATOR C-PANEL STS430 T0.5 H/L 3516732300 CONTROL-PANEL ABS SG-175 SG-0760D 3516913500...

  • Page 16: T2S Trs 4X12 Mfzn

    BUTTON FUNCTION-A ABS SG-175 SG-0760D PKBPMSF100 PCB BUTTON MANUAL AS KOR-6Q4R5S PKMPMSF150 PCB MAIN MANUAL AS KQG-6C4R5S 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 7621301011 SCREW TAPPING T2 PAN 3X10 PW MFZN 1) Remove the screw which secure the control panel, push up two snap fits and draw forward the control panel assembly.
  • Page 17 6. To remove high voltage capacitor. 1) Remove a screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
  • Page 18 8. To remove wind guide assembly. 1) Remove a screw for earthing. 2) Remove the noise filter from the wind guide. 3) Remove a screw which secure the wind guide assembly. 4) Draw forward the wind guide assembly. 5) Pull the fan from the motor shaft. 6) Remove two screws which secure the motor shaded pole.
  • Page 19 10. To remove tray motor 1) Remove the coupler in the cavity. 2) Turn the set upside down. 3) Cut the tray motor cover part from the base plate. 4) Remove the tray motor cover. 5) Remove a screw which secure the tray motor. 6) Remove the tray motor.
  • Page 20 Caution In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 12. To remove heater parts HEATER TOP ASSEMBLY : 3512803600 REF NO.

  • Page 21: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. (1) Primary interlock switch When the door is closed, the hook locks the oven door.

  • Page 22: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1) Check earthing before trouble checking. 2) Be careful of the high voltage circuit. 3) Discharge the high voltage capacitor. 4) When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed.
  • Page 23 CONDITION CHECK RESULT CAUSE REMEDY Replace Defective Outlet has Check continuity of magnetron Continuity magnetron proper volt- age Fuse does not Replace blow. Defective line Check continuity of Continuity filter board noise filter board Replace Check continuity of Open power Continuity supply cord power supply cord...
  • Page 24 (TROUBLE 3) No microwave oscillation even though fan motor rotates. CONDITION CHECK RESULT CAUSE REMEDY Check continuity of high microwave Continuity voltage fuse oscillation Replace high voltage fuse Continuity Replace Check continuity if high Defective high voltage capacitor terminals voltage with wires removed transformer Continuity in...
  • Page 25 (TROUBLE 4) The following visual conditions inditions indicate a probable defective touch control circuit or membrane switch assembly 1. Incomplete segments, 1) Segments missing. 2) Partical segments missing. 3) Digit flickering other than normal display slight flickering. 4) " :0" does not display when power is on. 2.

  • Page 26: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000±5cc of potable water.

  • Page 27: Microwave Radiation Test

    2. MICROWAVE RADIATION TEST CAUTION : 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4.

  • Page 28: Component Test Procedure

    3. COMPONENT TEST PROCEDURE • High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. • It is neither necessary nor advisable to attempt measurement of the high voltage. • Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor.

  • Page 29: Wiring Diagram

    WIRING DIAGRAM...

  • Page 30: Printed Circuit Board

    PRINTED CIRCUIT BOARD 1. CIRCUIT CHECK PROCEDURE 1. Low voltage transformer check • The low voltage transformer is located on the P.C.B. • Measuring condition: input voltage : 230V/Frequency : 50Hz Terminal Voltage LOAD NO LOAD 5-6-7 AC 12.6 V AC 14.7 V NOTE 1.
  • Page 31 (KQG-6C4R5S) Measure Point...
  • Page 32 (KQG-6C5R5S) Measure Point...
  • Page 33 3. When there is no microwave oscillation 1) When touching START pad, oven lamp does not turn on. Fan motor does not rotate, but cook indicator in display comes on. (TRAY LAMP) - Check method POINT STATE RELAY 2 ON 5VDC RELAY 2 OFF 12VDC...
  • Page 34 - Check method POINT STATE 1) DOOR OPEN OPEN 5VDC 2) DOOR CLOSED CLOSE CHECK NO HETHOD REMEDY Check the stage(ON, OFF) of the door open monitor Replace door open monitor switch. switch by resistance measurement. 6. When the digital clock does not operate properly. refer to Circuit Diagram.

  • Page 35: Circuit Diagram

    2. P.C.B. CIRCUIT DIAGRAM...

  • Page 36: Location No

    So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center . 3. P.C.B. LOCATION NO. NAME SYMBOL SPECIFICATION PART CODE Q'TY REMARK M315 3514330700 KQG-6C4R5S PCB MAIN BOARD M319 3514330710 KQG-6C5R5S BUZZER BM-20K (BUJEON) 3515600100 C ARRAY 7P(6) 1000PF M 50V 2.54MM...

  • Page 37: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY...

  • Page 38: Pom Black

    So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center . PART CODE PART NAME DESCRIPTION Q'TY 3511725300 KOR-6Q4R5S DOOR AS 3511725320 KOR-6Q5R5S PKCPSWBD50 KQG-6C4R5S CONTROL-PANEL AS PKCPSWF150 KQG-6C5R5S 3512803600 HEATER * T AS KOG-57350S 3510805300 CABINET AS KOR-61152S 7112401011 SCREW TAPPING...
  • Page 39 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Apr. 2005...
