Hook & Loop Fasteners
4 - Hook
4 - Loop
2 - Standard Caster
Standard Setup
18
CART COMPONENTS
8 - 1¼" Washer
8 - 2" x ¼" Bolt
4 - Cart Cross Piece
2 - Locking Caster
ASSEMBLED CART CONFIGURATIONS
Location for Hook
& Loop Fasteners
TOP
Hole 1
Hole 3
Hole 5
2 - Cart End Piece
For Seated Use
Hole 2
Hole 4
BOTTOM
